- Page 1 Transmitter, Receiver, Charging Cradle Model: myon m320 USER MANUAL...
- Page 2 Address changes and minor corrections. myon AG 28.04.2014 Added device verification procedures; added mains plug instructions; updated FCC information; technical data addendums; corrections. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 2 of 37...
- Page 3 Technical changes reserved. As a result of further technical development, illustrations and technical data may differ. myon AG makes no warranties, express or implied, as to the quality and performance of this product including but not limited to, any implied warranty of applicability for other than research uses by qualified individuals.
-
Page 4: Table Of Contents
6 Turning off the device............................22 6.1 Transmitters................................22 6.2 Receiver..................................22 6.3 Charging cradle................................22 7 Checks...................................23 7.1 Verification procedure for the correct functioning of the equipment................23 Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 4 of 37... - Page 5 10.5.1 Federal Communications Commission (FCC)......................35 10.5.2 Statement of Declaration of Conformity........................36 10.6 For customers within all other countries........................36 11 Safety and usage guidance...........................37 Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 5 of 37...
-
Page 6: Important Information
Other combinations, accessories and consumable parts may only be used if they are specifically designed for the intended application and do not affect performance, and safety requirements. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 6 of 37... -
Page 7: Power Supply Safety
In particular, adhesive tape or similar substances must not be attached to the charging contacts of the transmitter or the charging cradle slots' contacts. Please note that myon offers special fastening straps (P/N PA0003 ... PA0009) for the purpose of affixing the transmitter securely to the body. -
Page 8: Preface
The medical practitioner and/or user always has to decide on the basis of the general condition of the patient or subject whether or not the intended application is reasonable. Further information is Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 8 of 37... -
Page 9: Possible Combinations
EMG electrodes) must also be observed. Potential electromagnetic or other interference that occurs between the product and other products may lead to disturbances or malfunctions. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 9 of 37... -
Page 10: System Overview
• Mains power supply • Country specific mains plug • Device's power supply plug with mechanical reverse voltage protection Image 4: Power supply Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 10 of 37... -
Page 11: Power Supply Leads With And Without Ferrite
Power supply leads with and without ferrite Please note that although both types of power supplies are basically identical, for regulatory purposes, m320 charging cradles require the use of a power supply with a ferrite additionally attached to its lead (see Image 5). -
Page 12: Transmitter
If this doesn't help, resetting of the device may be required. A reset must not be carried out without prior advice by the myon support team. To perform a hard-reset carefully insert the tip of a ball pen into the opening on the side of the transmitter housing and gently press and hold down the reset micro switch for about 5 seconds. -
Page 13: Receiver
• 4 LED function indicators (4 more are on the other side of the device) • External power supply Image 9: Charging cradle Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 13 of 37... -
Page 14: Led Function Indicators
Empty charging slot / transmitter not properly inserted: If a charging slot is empty, the respective charging slot indicator LED will not light up. The Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 14 of 37... - Page 15 Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 15 of 37...
-
Page 16: Operation
5 Operation Parts included in shipment The myon system is shipped in a durable carrying case. Depending on your individual system configuration, you may find a varying number of parts and accessories as part of your shipment in the carrying case: •... -
Page 17: Device Installation
Do not dismantle any cable that will not be connected. If cables have already been dismantled that will not be connected, re- Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 17 of 37... -
Page 18: Charging Of Transmitters
LED is lit constantly. See Section 4.3 for details. Charging transmitters: Step 1 Charging transmitters: Step 2 Charging transmitters: Step 3 Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 18 of 37... -
Page 19: Conduction Of Measurements
Capturing and transmission of sensor signals • With the steps described in Section 5.5.1 the wireless connection is established and the device is ready to start measuring. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 19 of 37... -
Page 20: Transmitters With Emg Sensor Cable
• Affix the transmitters securely to the body near to each pair of electrodes. Consider using myon's special re-usable fastening straps (P/N PA0003 ... PA0009) for quick and easy re- adjusting of the transmitters position. Make sure that you do not touch any accessible contacts of connectors and patient simultaneously. -
Page 21: Receiver
As a rule of thumb, the transmitters should be positioned as much lateral on the body as possible and ideally within a line of sight with the receiver. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 21 of 37... -
Page 22: Turning Off The Device
6.3 Charging cradle To turn off the charging cradle, disconnect the charging cradle's external power supply from the mains. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 22 of 37... -
Page 23: Checks
◦ BF001: Ensure that the system is configured and connected according to this manual. ◦ BF002: Make sure that only the components that were supplied by myon as part of your shipment are used, such as the D-sub cable, power supplies, etc. -
Page 24: Check Of Installation And Wiring
The transmitter's LED must not blink. ◦ IW004: Connect the analog output port of the receiver with the supplied myon D-sub cable to a suitable analog-to-digital converter (see Section 5.3 for details). -
Page 25: Check Of Transmitter's Sensor Cable Integrity
(a slight amount of noise in the output signal however, is normal). ▪ CI006: No relevant positive or negative offset from 0 V must occur. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 25 of 37... -
Page 26: Solving Problems
• Make sure that you are using fresh electrodes from a recently opened package and that the expiry date has not been exceeded. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 26 of 37... -
Page 27: Technical Description
Excluding EMG sensor cable and sensor, if not specified otherwise. Including EMG sensor cable. Selectable by “Model specific options sheet” at the time of ordering. Default. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 27 of 37... -
Page 28: Description Of Interfaces
United States of America: Part 15 of the FCC Rules Description of interfaces The interface layout may differ if myon systems have been specifically adapted to your individual requirements. Individual systems will include a pin assignment sheet showing the mapping of the individual output pins. Contact your local sales agency if you need further assistance. -
Page 29: Models With Analog Emg Output For More Than 16 Channels
The pin assignment of the male DSub25 connector is shown in the following figure. Image 12: Male DSub25 connector. View from outside into connector. For all myon m320 systems that have been shipped later than 1 May 2012 , the following colour code for the single wires of the respective DSub cable applies. -
Page 30: Technical Support
9.3 Technical support In the following paragraphs more in depth information about the myon m320 system and how it works in detail is provided. The information provided however, is neither complete nor is it mandatory to operate the system as intended. - Page 31 ( 2,5V) on the affected channel. ± Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 31 of 37...
-
Page 32: Regulatory Information
Class II equipment, according to IEC 60601-1 10.4 For customers within the European Economic Area For additional information a regulatory fact sheet for the myon m320 device is available from the manufacturer upon request. 10.4.1 Restriction of the Use of certain Hazardous Substances in Electrical and Electronic Equipment (RoHS) myon m320 hardware is fully RoHS-compliant. -
Page 33: Registration, Evaluation, Authorisation And Restriction Of Chemicals (Reach)
Please contact myon AG or your local sales agency for information about myon's acceptance of returned goods at product's end-of-life. WEEE-Reg.-No. -
Page 34: Declaration Of Conformity
10.4.4 Declaration of Conformity Declaration of conformity myon AG, Sonnenrain 75, 6103 Schwarzenberg, Switzerland declares under our sole responsibility that the devices, listed hereafter; • myon m320 system consisting of ◦ myon m320 transmitters (Model m320TXA, Type PT0001) ◦ myon m320 receiver (Model m320RX, Type PR0006) ◦... -
Page 35: For Customers Within The United States Of America
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 35 of 37... -
Page 36: Statement Of Declaration Of Conformity
10.5.2 Statement of Declaration of Conformity 10.6 For customers within all other countries Please contact myon AG for information. Date: 28.04.2014 LaInMa-EU-m320 - Instructions manual (full version, english) - 20140428 - V1.7.odt Page 36 of 37... -
Page 37: Safety And Usage Guidance
We have made every effort to ensure that we have provided you with a safe and robust product. For your safety and to ensure that your myon m320 continues to meet your expectations and requirements, take note of the following guidance: •...
