JAMFOX
Jamfox® Earbits WS-T2
True Wireless Bluetooth Earbuds + charging Pod
SIMULATION THEORY LLC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Earbits WS-T2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Jamfox Earbits WS-T2

  • Page 1 JAMFOX Jamfox® Earbits WS-T2 True Wireless Bluetooth Earbuds + charging Pod SIMULATION THEORY LLC...
  • Page 2 JAMFOX USER MANUAL Congratulations, and thank you for choosing Jamfox Earbits. This manual will help you operate your wireless stereo earbuds. We recommend that you familiarize yourself with Bluetooth functionality of your mobile phone or other devices before using the earbuds.
  • Page 3 JAMFOX USER MANUAL Accessories Jamfox®...
  • Page 4: Graphical Representation

    JAMFOX USER MANUAL Graphical Representation 1. Touch control button 2. Microphone and LED indicator 3. Ear Tips 4. Charging case 5. Charging case LED indicator 6. Micro-USB Charging Port 7. Earbuds charging status LED indicator In order to get best audio performance, try every ear tips (Small, medium and large) to achieve the correct seal for your ear.
  • Page 5 JAMFOX USER MANUAL Charging The earbuds and charging capsule must be fully charged before first time to use. Note: 1. The LED indicator of the earbuds will flash blue slowly during normal operation. 2. The LED indicator of the earbuds will flash red quickly to remind you the battery is low.
  • Page 6: Power On/Power Off

    JAMFOX USER MANUAL Single headset operation Power on / Power off Manual Power on: Press the touch control button for 2 seconds, the LED light will flash blue, you will hear “power on” prompt. Auto Power on: Open the charging capsule. The LED indicator of the earbuds will flash, you will hear “power on”...
  • Page 7 JAMFOX USER MANUAL Turn on the Bluetooth of the device and find the pairing ID “Jamfox-L/Jamfox-R”, click it to connect, the LED indicator of the Master/Slave will flash once/twice every 5 seconds, the earbud is connected with the Bluetooth device successfully.
  • Page 8 JAMFOX USER MANUAL Once the headset is successfully paired and connected with your mobile phone, you can use it to make a call and listen to music. Answer a call/End a call: Tap the touch control button once to answer the incoming call.
  • Page 9: Power Off

    JAMFOX USER MANUAL Stereo Headset Operation Power on Manual power on: press the touch control button for about 2 seconds, the LED indicator will flash blue and you will hear “power on” prompt. Auto power on: open the charging capsule, both earbuds will power on automatically and both LED indicators of the earbuds will flash blue.
  • Page 10 JAMFOX USER MANUAL Turn on the Bluetooth of the device and find the pairing ID “Jamfox-L”, click to connect, the LED indicator of the Master will turn to flash blue once every 5 seconds and the Slave will keep flashing blue twice every 5 seconds, the earbuds are now connected with the Bluetooth device successfully.
  • Page 11: Play Music

    JAMFOX USER MANUAL Turn on the Bluetooth of the device and find the pairing ID “Jamfox-L”, click it to connect, the LED indicator of the Master will flash blue once every 5 seconds and the Slave will flash blue twice every 5 seconds, the earbuds is connected with the Bluetooth device successfully.
  • Page 12: Low Power Alarm

    JAMFOX USER MANUAL Volume+/Volume- When the earbuds are playing music, double tap the touch control button of the Master to increase the volume and double tap the touch control button of the Slave to decrease the volume. Next song When the earbuds is playing with music, press the touch control button of the Master 2 seconds to the Next song, please release the touch control button once you heard the “Beep”...
  • Page 13 JAMFOX USER MANUAL 2) Double tap the touch control button and the LED indicator will flash red and blue once at the same time, reset the factory setting and the earphone will power off after the operation. Remark: If the Master and Slave clear the paring list at the same time, you have to pairing as first time use then both earbuds can pairing as TWS.
  • Page 14: Specifications

    JAMFOX USER MANUAL Specifications Items Specifications Headset Battery Button Cell 60mAh Earbud Weight 4.7 grams Bluetooth Version V5.0 Working voltage 3.2V-4.2V Microphones sensitivity -40±2db Bluetooth Frequency band 2.4-2.48GHZ Bluetooth range Audio transmission protocols A2DP/HFP/HSP/AVRCP Charging Pod Capacity 400 mAh Weight...
  • Page 15 JAMFOX USER MANUAL Notice Please ensure the earbuds are in pairing mode (LED indicator of the earbud flash red and blue alternately.) or the mobile will not find the relevant pairing ID to connect it. Warm tips You must select a qualified adapter to charge this product. You must charge the Bluetooth headset if it has not been used for more than 3 months.
  • Page 16: Troubleshooting

    JAMFOX USER MANUAL Troubleshooting Problem Reason Solution Starting-up failure low battery charge for the headset No sound after paired wrong paired re-pairing Red light shines during phone low battery warning please charge immediately talking No indicator during charging Headset didn’t put into the check the headset if it’s well...
  • Page 17 JAMFOX USER MANUAL Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
