Summary of Contents for HSL-Topferscheiben HSL PROFI S-45
- Page 1 HSL-Töpferscheiben www.hsl-toepferscheiben.de Potter`s wheel - Made in Germany Assembly Instructions Seat framework HSL Profi T/S-45 ... a Product of Johannes-Diakonie Mosbach...
- Page 2 Seat Framework T/S-45 Please send your requests and orders to: HSL-Töpferscheiben Johannes-Diakonie Mosbach Schwarzacher Werkstätten Melanie Wilhelm Schwanheimer Straße 23 D-74869 Schwarzach Telefon: +49 6262 22-402 Fax: +49 6262 22-551 E-Mail: melanie.wilhelm@johannes-diakonie.de Internet: www.hsl-toepferscheiben.de Assembly Instruction - Seat Framework - HSL Profi T-45 / S-45 Stand: 4/2019...
- Page 3 Description: Robust, powder coated steel frame with 4 plastic feet to level the machine. Very stable and individual seat position for a relaxed, ergonomic work position. In our equipment you can also find a fitting PU-seat and more useful accessories like heigth measurements. More information is on our webpage: www.hsl-toepferscheiben.de HSL Töpferscheiben ·...
-
Page 4: Manufacturer's Specifications
1. Manufacturer‘s specifications Device designation: Seat frame for potter`s wheel HSL PROFI S-45 Manufacturer: HSL Töpferscheiben Johannes-Diakonie Mosbach Schwarzacher Werkstätten Schwanheimer Straße 23 D-74869 Schwarzach Tel: +49 6262 22-402 Fax: +49 6262 22-551 www.hsl-toepferscheiben.de Dimension: L x W x H / 700-1030 x 510 x 560 mm... -
Page 5: Assembly And Commissioning
2. Assembly and commissioning Please read the assembly instructions before installation and use of your new potter‘s wheel, and follow the instructions and manufacturer`s recommendations. Retain the assembly instructions. Check package contents for completeness when unpacking. The following items are included in delivery: Base rack (pre-assembled) H-beam Gas pressure spring... -
Page 6: Mounting Accessories
3. Mounting accessories The mounting acessories needed for the HSL Profi T/S45 are provided. The contents of this bag include: 8 x cylinder head bolt M8x20 V2A 10 x spring ring 8.4mm V2A 2 x cap nut M8 V2A 1 x combination wrench, size 13 Allen key, size six, is included in the delivery of the potter‘s wheel Assembly Instruction - Seat Framework - HSL Profi T-45 / S-45... -
Page 7: Step 1: Assembling The Frame
Step 1: Assembling the Frame Attention: When assembling the frame, please tighten the screws only by hand. When the frame is completely assembled, retighten the screws with the related tool. When attaching the Gas spring on the seat support: Check that all components are clean –... - Page 8 Step 2: Mounting of the machine on the seat frame Remove the 4 rubber feet from the machine and store them. Fit the machine as shown in the lower image (page 9) and screw into position. with the 6 x spring rings and 6 x cylin- der head bolts M8x20.
- Page 9 HSL Töpferscheiben · Johannes-Diakonie Mosbach • Schwarzacher Werkstätten · Schwanheimer Straße 23 · D-74869 Schwarzach...
-
Page 10: Safety And Warning
4. Complaint If returned shipment is required, please inform the manufacturer in advance. It is recommended to keep the original packaging for this case. This is necessary to ensure rapid processing of complaints and to ensure that the manufacturer will take over the shipping costs. Please use the Repair advice note which you can download on our website. - Page 11 Equipment* for Profi T/S 45: Height measurement Height: ca. 50 cm Arms: each 30 cm Material: VA Wooden plate with tappets Diameter: ca. 350 mm Material: wood PU-seat with tilt technology for seat framework Diameter: ca. 350 mm Material: PU Attachment: pigeonhole Wooden-seat with tilt technology for seat framework...
- Page 12 Imprint: Johannes-Diakonie Mosbach Schwarzacher Werkstätten Schwanheimer Str. 23 74869 Schwarzach Germany www.johannes-diakonie.de Board of directors: Martin Adel (Vors.), Jörg Huber The Johannes-Diakonie Mosbach is a public corporation and a member of the social service organization Diakonisches Werk Baden. All pictures are copyrighted. Pictures might deviate slightly from the product.
