2M TECHNOLOGY
Face Recognition Access Control
Terminal with Digital
Temperature Measurement Module
2MTHFR-2M
Quick Guide
Version: 1.01
REV05182020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2MTHFR-2M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for 2M Technology 2MTHFR-2M

  • Page 1 2M TECHNOLOGY Face Recognition Access Control Terminal with Digital Temperature Measurement Module 2MTHFR-2M Quick Guide Version: 1.01 REV05182020...
  • Page 2: Packing List

    Packing List Name Unit Digital detection module Screw kit (There are two types and the actual screw kit shall prevail. Screw kit 1: two M4x16 pan head screws, two M4 nuts, and two M3x6 pan head screws; screw kit 2: two M3x6 pan head screws) Power adapter (purchased separately) Special statement User manual...
  • Page 3  Pollution degree of the intended environment: the operational environment should be with less dust to avoid the pollution of blackbody target. (Pollution degree 2) If the euipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. 2 Appearance and Size Appearances and sizes vary with device type.
  • Page 4 3 Structure and Cable Structures and cables vary with device type. The actual product shall prevail. Structure and Cable 1 Temperature sensor 4-pin cable Structure and Cable 2 Temperature Indicator sensor 4-pin cable...
  • Page 5: Device Installation

    4 Bracket Introduction When the digital detection module is used in combination with a face recognition access control terminal or face recognition terminal, a bracket (purchased separately) is required for installation. The bracket is delivered with four M4x11 screws and two M4 wing nuts. Hole description 孔位说明...
  • Page 6: Power Input

    Diameter Selection for Extension Power Cables The device is powered by DC 12V/2A and the lower limit of the operating voltage is DC 9V (12V–25%). 0.8mm 1.25mm 1.63mm Wire Diameter (mm) (20 AWG) (18 AWG) (16 AWG) (14 AWG) Transmission Distance (m) 2 Wiring description The figure below shows the wiring between the digital detection module and...
  • Page 7: Installation Steps

    Installation Steps NOTE! Before installing the digital detection module, connect the cables between the module and a face recognition access control terminal/face recognition terminal by referring to section "Device Wiring" and sections related to the wiring in the quick guide of the face recognition access control terminal/face recognition terminal. 1 Wall mount The figure below shows the process of installing the digital detection module on a wall when the module is to be used in combination with a face recognition access...
  • Page 8 M4 wing nuts The figure below shows the process of installing the digital temperature measurement module on a standing pole when the module is to be used in combination with a face recognition terminal. 1. Remove the black panel. 2. Remove the four screws on the back and two screws at the bottom, and...
  • Page 9: Device Startup

    Device Startup 1 Device power-on After the device is installed correctly, connect the power adapter (provided separately) to the mains supply to start the device. 2 Device configuration Local configuration When the digital detection module is used in combination with a face recognition access control terminal, you can enable the temperature measurement function on the Authentication Scene interface of the face recognition access control terminal.
  • Page 10 Configuration on the Web interface You can also log in to the Web interface of the terminal and choose Setup > Intelligent > Advanced Setting to enable the temperature measurement function. 3 Device operations When the temperature needs to be measured, a person needs to get close to occupy the human shape on the screen and aim the forehead center at the red circle.
  • Page 11 FAQs Failure/ Solution Symptom What 1. Check whether the measurement distance is adequate. The should I do recommended measurement distance is 20–30cm for single if some point series and 50–70cm for matrix series. people's temperatu- 2. Check whether the people get close to occupy the human shape res cannot on the screen and aim the forehead center at the red circle.
  • Page 12 Failure/ Solution Symptom What 1. Check whether a person has behaviors that affect the body should I do temperature, for example, getting out of a hot car, doing when a strenuous exercise, or carrying hot drinks and hot food. If yes, high the person needs to stay in the measurement area calmly and temperatu...
  • Page 13 About This Manual  This manual is intended for multiple product models, and the photos, illustrations, descriptions, etc, in this manual may be different from the actual appearances, functions, features, etc, of the product.  This manual is intended for multiple software versions, and the illustrations and descriptions in this manual may be different from the actual GUI and functions of the software.
  • Page 14 The following are necessary measures for the network security of your device:  Change default password and set strong password: You are strongly recommended to change the default password after your first login and set a strong password of at least nine characters including all three elements: digits, letters and special characters.
  • Page 15  Store or use the device in a proper environment that meets environmental requirements, including and not limited to, temperature, humidity, dust, corrosive gases, electromagnetic radiation, etc.  Make sure the device is securely installed or placed on a flat surface to prevent falling. ...
  • Page 16  Remplacer la batterie par un type incorrect;  Disposer d’une batterie dans le feu ou un four chaud, écraser mécaniquement ou couper la batterie;  Disposer la batterie utilisée conformément à vos règlements locaux ou aux instructions du fabricant de la batterie. Regulatory Compliance FCC Statements This device complies with Part 15 of the FCC Rules.
  • Page 17 802 Greenview Dr. Grand Prairie TX. 75050 USA Toll Free: 1-866-708-5401 Fax: (+1) 972-999-4113 sales@2MTechnology.net...
