SWorkz S35-4E Instruction Manual

SWorkz S35-4E Instruction Manual

1/8 off road brushless power pro buggy

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S35-4E and is the answer not in the manual?

Questions and answers

Summary of Contents for SWorkz S35-4E

  • Page 2 We also included the new special middle brace system. The new S35-4E comes with a lower shock layout in front and rear and the construction of the shocks is adapted to that new optimized layout. The fixed shock spring plates will make it almost impossible to lose them anymore.
  • Page 3 Contact your local hobby shop or SWORKz distributor for all claims and questions. Claims must be well documented. All Claims are subject to expert...
  • Page 4 7-33 Blank Set-up Sheet 34-36 S35-4E Key No. List 37-38 S35-4E Spare Part No. List 38-39 S35-4E Option Part No. List End cover This radio controlled racing car is not a toy! This high-performance R/C model is recommended for ages 14 and older.
  • Page 5 R e q u i re d Equ ip me nt fo r O p erat io n Radio Gear Stick Type Receiver ESC system Steering servo Wheel & Trigger Type Breshless Motor Charger and LiPo Battery Tools Recommended Long nose pliers Side cutter 1.5mm Paint...
  • Page 6 The SWORKz S35-4E is a high performance radio controlled model which needs to be operated with caution and common sense. The S35-4E Pro Kit is not intended for children under the age of 14 without adult supervision. SWORKz shall not be held liable for any loss or damages, whether direct, indirect, act of nature, arising from the abuse or misuse of this product or any other product required while operating this model.
  • Page 7 101004 610023 Washer 3.5X10X0.2mm 328001 101004 101004 328001 101004 338025 328001 101004 Fill the differentials with oil up to 80% above the satellite gears. Put the SWORKz Diff. Oil 7000cps for the front Diff. and 3000cps for the rear Diff.
  • Page 8 M3x12mm FH/ST HEX Screw 338025 S35-3W Bevel Gear Shaft 610020 101004 101004 Washer 3.5X10X0.2mm 101004 328001 330025 328001 101004 Fill the differentials with oil up to 101004 above the satellite gears. Put the SWORKz Diff. Oil 7000cps for the center Diff.
  • Page 9 Pro Tip: Before installing the M5x4 set screw (104010), remember to clean the set screw and center driver joint (330661A) first. Then apply TLC on the set screw. 338023 106019 338011 106019 104010 M5x4mm Set Screw (Flat Bottom) 228001(#8 #9) 330661A 2503261A 108001...
  • Page 10 Pro Tip: Before installing the M5x4 set screw (104010), remember to clean the set screw 330781 and center driver joint (330661A) first. Then apply TLC on the set screw. 106019 108001 338011 330661A 106019 M3x12mm FH/ST HEX Screw 228001(#8 #9 #10) 104010 M5x4mm Set Screw (Flat Bottom) 338049...
  • Page 11 108008 M3x35mm FH/ST HEX Screw 101020A 3mm Countersunk Washers (GM) 228001(#5 #6 #7) 338056 338058 228001(#5 #6 #7) 118008 101020A 338056 S35-4 Series Lower Arm Hinge Pin (68.5mm) 2503261A Pop in the Stabilizer Guide. 104004 M3x3mm Set Screw 104004 104004 115008A (2.3mm) 115035A (2.2mm)
  • Page 12 104005 M3x4mm Set Screw 106013 M2.5x8mmH ex Socket OH/TPScrew 106013 104005 Note: The aluminum front upper arm holder (338057) can offer either 0° or + -1° kick-up for your front upper arm suspension. You may use the inserts 228001(#13) to get 0° kick-up or 228001(#12) to get +-1°...
  • Page 13 Pro Tip: The S35-3 Front Upper Arm Adjust Inserts can give different steering adjustments (Ackerman). Put all inserts behind the front upper arms, you will get faster steering response. Otherwise put all inserts in front of the upper arms, 108001 you will get more stable steering response.
  • Page 14 106002 M3x10mm Hex Socket OH/TP Screw 228006 338050 108001 M3x12mm FH/ST HEX Screw 106002 108001 PRO TIP: The S35-4 Aluminum Rear Lower Fully Adjustable Toe-In Block (338014) can use 3 types of square inserts to get 1.0/2.0/3.0 3 108008 different toe in angles. Also plus 3 different M3x35mm FH/ST HEX Screw rear lower arm kick up degrees.
  • Page 15 2503261A Pop in the Stabilizer Guide. 104004 M3x3mm Set Screw 104004 104004 115005 (2.8mm) 115006 (2.6mm) 104005 M3x4mm Set Screw 106013 M2.5x8mmH ex Socket OH/TPScrew 104005 104005 106013...
  • Page 16 106002 106002 M3x10mm Hex Socket OH/TP Screw Right 338051 330252 2503260-04 330118A Left 330118A 2503264A 330252 2503260-04 Screw and adjust 330118A Knuckle Pivot Ball Nut so as the pivot ball can be moved smoothly. Left 104010 M5x4mm Set Screw (Flat Bottom) 330124 Pin M3.0x16.8mm 210046...
  • Page 17 330117A 330117A 116004 106007 101021 338043 103001 106014 M3 Nut Lock 117003 610019 101021 101021 M3x8xT1mm 338053 115004A 117003 117003 117003 338052 Flange Ball Bearing 3x6x2.5mm 116004 117003 Ball Bearing 6x10x3mm 2501122B 106007 M3x12mm Hex Socket OH/TP Screw(HT) 330114A 103001 103001 2501122B...
  • Page 18 108003 108003 M3x10mm FH/ST HEX Screw 116004 Ball Bearing 6x10x3mm 101019 SHIM 6.0x10.0x0.2mm 101019 116004 338048 116004 338048 Left 104010 M5x4mm Set Screw (Flat Bottom) 210046 330124 Pin M3.0x16.8mm 106009 220022 340016 Right 116006 116006 340016 228001(#17 #18) Ball Bearing 8x16x5mm 330124 103001 106009...
  • Page 19 2503260 (#6 #7) 2503260 (#6 #7) 103001 330782 103001 103001 M3 Nut Lock 330782 330782 Rear Hub Carriers Hing Pin with Nut 2503260 (#6 #7) Shorty Upper Arm Linkage Set-up 22.85 mm 22.85 mm 330123A 228006-5 Rear Upper Sus. Arm Turnbuckles 330123A 330125 2501121C...
  • Page 20 Longer Upper Arm Linkage Set-up 106002 106002 M3x10mm Hex Socket OH/TP Screw 228001 106009 M3x25mm Hex Soket OH/TP Screw 103001 M3 Nut Lock 106009 106002 103001 228001 106009 Shorty Upper Arm Linkage Set-up 103001 108019 103001 228003S(#3) 228003 228003S(#3) 103001 M3 Nut Lock 106003 228003...
  • Page 21 108007 108007 108007 108007 228004 338064 108007 M3x6mm FH/ST HEX Screw 108007 108007 108007 108007 228004 108007 108003 M3x10mm FH/ST HEX Screw Front 108010 Top View M4x10mm FH/ST HEX Screw Rear 108012 M4x16mm FH/ST HEX Screw 2501097B 108012 108010 108003 108012...
  • Page 22 108003 108003 340015 M3x10mm FH/ST HEX Screw 108012 M4x16mm FH/ST HEX Screw 108012 108012 106002 750 BL Motor is not included 106006 106002 104011 3mm hole M3x10mm Hex Soket OH/TP Screw 106006 4mm hole 340018 106008 106008 106008 M3x12mm Hex Soket OH/TP Screw 228007 338066 228007...
  • Page 23 330697 108003 M3x10mm FH/ST HEX Screw 330699B 108010 M4x10mm FH/ST HEX Screw 228007 108003 108010 228006 338038A 106001 228006 338070 M3x10mm Hex Soket OH/TP Screw 338070 1.0mm 228006 108003 M3x10mm FH/ST HEX Screw 338070 228006 104014 101020A 108003 3mm Countersunk Washers (GM) 338070 108003 101020A...
  • Page 24 The 2503221BK Battery Stoper must be suit for different Lipo Battery style. 108006 M3x8mm FH/ST HEX Screw 108006 2503221BK 2503221BK 540001 2503221BK 540001 108006 108006 M3x8mm FH/ST HEX Screw 108006...
  • Page 25 Right 330126A Steering Turnbuckle 2503270 (#3) 330777A 330126A 330777A 2501121C 20mm 106002 106002 M3x10mm Hex Socket OH/TP Screw 106002...
  • Page 26 108003 108006 200603 106008 104009 M3x16mm Set Screw 228006 330694A 106008 106008 M3x12mm Hex Soket OH/TP Screw 104009 101012 330134 228006 108006 101012 M3x8mm FH/ST HEX Screw Assembly Note: According to different brands servo, you can 108003 use different servo hold inserts and screws to M3x10mm FH/ST adjust your servo position.
  • Page 27 1/8 ESC is not included 108003 M3x10mm FH/ST 2503221BK 400013 400013 108003 108003 106010 106010 M3x6mm Hex Socket OH/TP Screw 2503221 108007 M3x6mm FH/ST HEX Screw 200193 108007 108007 Receiver is not included 2503221...
  • Page 28 103004 Front 338063(S) Rear 338062(L) Front 338061(S) Rear 338060(L) 338062 330562(F) S35-4 Series BBS System Tiefron Coated Shock Shaft (L) 330563(R) 400020 101011 338063 S35-4 Series BBS System Tiefron Coated Shock Shaft (S) 210058 103004 M2.5mm Nut Lock 330557 228006 210058 Shock Seal Washer 3.5X7X1.0mm Front 400010(S)
  • Page 29 115183 S35-4 Black Competition Front Shock Spring (US3-Dot)(62X1.6X7.75) 330560 228006 330134 400019 Front SWC-115183 Rear SWC-115164 115164 S35 Series Black Competition Front Shock Spring (M3-Dot)(75X1.6X9.0) 330138B 101010A 105006A M3x28mm Cap Screw 338068 101010A 101010A 105013A M3x25mm Cap Screw 105013A 101010A 105006A...
  • Page 30 103003A Flange M3 Nut Lock 103003A 106003 M3x16mm Hex Soket OH/TP Screw 103003A 330243 (Anti-Clockwise) 330243 SWORKz 3x16mm Shock Hex Screw Clockwise 330243 330243 SWORKz 3x16mm Shock Hex Screw Anti-Clockwise 103003A 330243 (Anti-Clockwise) 103003A 330243 105025 228008BK 106025 228008BK 106025...
  • Page 31 330122A Wheel Nut Tires and wheels Tires and wheels are Not included are Not included 330122A 330122A Lipo Batteries Lipo Batteries are not included are not included...
  • Page 32 Use water/washing solution to clean body. Apply window masks as shown. 518003 258001C-E Paint body. 115019 106010 Button Head Screw M3x6mm 106010 115019...
  • Page 33 Race time / Lap: SET-UP SHEET Best lap: Diff. Oil Track Conditions Name: Size: Open Med. Tight Front: Date: Traction: High Med. Center: Track: Surface: Smooth Med. Bumpy Rear: Electric System Tire Motor Gear/Spur Gear: Front Rear ESC Type: Type: Type: A: Standard Pack Battery Type...
  • Page 34 Race time / Lap: SET-UP SHEET Best lap: Diff. Oil Track Conditions Name: Size: Open Med. Tight Front: Date: Traction: High Med. Center: Track: Surface: Smooth Med. Bumpy Rear: Electric System Tire Motor Gear/Spur Gear: Front Rear ESC Type: Type: Type: A: Standard Pack Battery Type...
  • Page 35 Race time / Lap: SET-UP SHEET Best lap: Diff. Oil Track Conditions Name: Size: Open Med. Tight Front: Date: Traction: High Med. Center: Track: Surface: Smooth Med. Bumpy Rear: Electric System Tire Motor Gear/Spur Gear: Front Rear ESC Type: Type: Type: A: Standard Pack Battery Type...
  • Page 36 S35 Series Shock End/Body Mount/Ball Ends Set 2 SW-228006 400005 Shock Spring Adjust Nut O-Ring 4 SW-400005 228007 S35-4E Buggy Series Steering Servo Mount/Center Diff Mount Plastic Parts 1 SW-228007 400006 shock seal O-Ring 8 SW-210058 228008BK SWORKz 1/8 Off Road Formula 2.0 Race Wing (BK) 1 SW-228008BK...
  • Page 37 Pa r t s No. Li st Part No. Part Name Q`ty in Use ltem No. 106006 M3x20mm Hex Soket OH/TP Screw 6 SW-106006 106007 M3x12mm Hex Soket OH/TP Screw (HT) 3 SW-106007 106008 M3x12mm Hex Soket OH/TP Screw 8 SW-106008 106009 M3x25mm Hex Soket OH/TP Screw 6 SW-106009...
  • Page 38 Shock Spring Adjust Nut O-Ring SW-228006 S35 Series Shock End/Body Mount/Ball Ends Set (2Set) SW-400009 Shock Boot (L) SW-228007 S35-4E Buggy Series Steering Servo Mount/Center Diff Mount Plastic Parts SW-400010 Shock Boot (S) SW-228008BK SWORKz 1/8 Off Road Formula 2.0 Race Wing (BK) SW-400013 SWORKz Shock Seal O-ring 2x2.7mm (8PC)
  • Page 39 SWORKz High Performance 5x13x4mm Ball Bearing (Rubber Case)(4PC) SW-108005 M3x14mm FH/ST HEX Screw SW-250050 SWORKz 1/8 Off Road Formula Bulkhead Wing (4PC)/ Front Upper Arm's Wing Set (4PC) SW-108006 M3x8mm FH/ST HEX Screw SW-228003H S35 Series Integrated Wing Mount Set (Hard Material)
  • Page 40 508002 Production No. 36020203...
