Wigam PRATIKA PLUS 100-05 Quick Start Manual

PRATIKA-PLUS 100-05
Electronic Programmable Charging Scale

Function Keys

Lb: weight in Pounds
Kg: weight in Kilograms
ZERO: zero reset
SET: enter program weight
▲: Increase program weight
▼: Decrease program weight
GO / HOLD: start charging system / pause the charging system
FORCE: open the solenoid valve to release the refrigerant in the charging hose when the
Charging procedure is over.
ON: power switch
OFF: power off

Specifications

Weight capacity: 100kg / 220lb
Units: Kilograms or Lbs./oz
Resolution: 5g / 0.2oz
Accuracy: ± 0.5%
Operating Temperature: 32℉ to 113℉ (0℃ to 45℃)
Power: 9V alkaline battery and 110 / 220V

Prepare

1. Please remove the scale out of the case.
2. Place the scale on a flat and hard surface.
3. Install a new 9V alkaline battery by removing the battery cover that is located at the back
of the control box.

Weight measurement

1. Switch on the scale by pressing the "ON" button.
2. Select measure unit (kg / lb) by pressing and releasing the "UNIT" button.
3. Press the "ZERO" button and the display will reset to zero.
4. Turn off the scale by pressing the "OFF" button.
