Mounting instructions for Merika® toilet sleeve
with a side connection Merika 11112, 11113 and 11114
Note in the mounting that the sewer
pipe for the toilet seat
must be cut by the floor surface.
A toilet sleeve that suits
for toilet seats with
S-locks and skirted
toilet seats.
Eccentric 38 mm.
Parts of the toilet
sleeve
Merika 1111_03
Seal
Merika
1991, 1992
and 1993
The opening
tool for the side
connection
Merika 11112,
11113 and 11114
Toilet sleeve
Merika 11112_02
Accordion seal
Toilet sleeves
side conn.
Merika no.
size
11112
32 mm
11113
40 mm
11114
50 mm
Opening tools
Merika no.
size
1991
32 mm
1992
40 mm
1993
50 mm
HVAC no.
5758262
5758263
HVAC no.
3311417
3311425
