JVC LT-32EX38 Quick Setup Manual

Quick Setup Guide
This HD Quick Setup Guide is intended to help you connect your TV to your HD signals.
Important Notes
• Please read the "Important Safety Precautions" and "Warnings" sections in your users guide before
you begin using your TV.
www.jvc.com
• Please visit or call customer service at
problem with your TV, or to order additional cables or wall mounts.
Make sure you have the following
1 Remote Control
POWER
SLEEP SUB CH V.STATUS SOUND
1 2 3
Two AA
4 5 6
7 8 9
TUNE RETURN+/TV
Batteries
0
V1 V2 V3 V4
MUTING
CH+ V5
VOL FAV. VOL
– +
CH–
ML/MTS DISPLAY C.C. ASPECT
MENU BACK GUIDE
OK
Battery Installation
RM-C1291
TV
Satellite / Basic Cable / Cable Box / DVR / DVD Connections
Note:
• Refer to your optional device's users guide for the best way (if applicable) to connect them as well as "Connecting Your Devices" in your TV users guide.
HDMI
DVI to HDMI
(with Composite Audio
Cables)
Component
(Y, Pb, Pr, L, R)
*Coaxial 75 Ω (VHF/UHF)
S-Video
*Composite (V, L, R)
* Coaxial Cable can receive over-the-air or unscrambled cable HD (ATSC/QAM)
transmissions when connected directly to the TV (not through a VCR/DVD).
1-800-252-5722
if you encounter a
1 Users Guide
1 Television
1 Quick Setup Guide
POWER
1
HDMI to HDMI Cable connection - BEST
1
DVI to HDMI Cable and Audio L/R Cable connection - BETTER
2
Component Cable and Audio L/R Cable connection - GOOD
3
Over-The-Air Antenna - OK
* Component is best used for analog signal.
* Analog composite is better than analog coaxial.
Connecting to an HD Signal
Notes:
• Please choose only one connection type.
• You cannot view HD quality signals with Composite or S-Video cables (Y/C).
Composite Cables
Analog Audio Only
Back of the TV
Component Cables
Y P P
B R
VIDEO OUT AUDIO OUT
CABLE or SATELLITE BOX
General Note:
• Refer to your cable or satellite provider for more detailed information about their services, equipment and service costs.
LCT2340-001A-A
0607FAI-II-IM Some channels may be unavailable if you are using DVI or HDMI connection.
Outside Cable Wire
or
HD Satellite Dish
DVI AUDIO OUT
CABLE IN
L
75Ω
Coaxial Cable
for
INPUT 3 INPUT 4 INPUT 5
AUDIO
/ INPUT 1
OUT
S-VIDEO AUDIO
Y VIDEO Y VIDEO VIDEO
P L P L L L
B B
P R P R R R
R R
Audio L/R Cables
Outside Cable Wire
or
HD Satellite Dish
CABLE IN
75Ω
L R
Coaxial Cable
CABLE or SATELLITE BOX
DVI OUT HDMI OUT
R
DVI – HDMI
Cable
OR
HDMI – HDMI
Cable
75 Ω DIGITAL AUDIO INPUT 1 INPUT 2 PHOTO VIEWER /
(VHF/UHF) OPTICAL OUT SERVICE
Back of the TV
Outside Antenna
or
Unscrambled Cable
