Summary of Contents for EunSung HydraBeauty
- Page 1 Operator Manual...
- Page 2 This manual is copyrighted with all rights reserved. This manual may not be copied in whole pages or in part reproduced such as graphic, electronic, mechanical, including photocopying, typing, or information retrieval systems without written permission of EUNSUNG GLOBAL. The system specifications and the information contained in this manual book are subject to change without notice.
-
Page 3: Table Of Contents
3.2 Components 4. Installation of the product 4.1 Outlines 4.2 Handpiece installation 4.3 Handpiece decomposition 4.4 installation of the body & solutions 4.5 Cleaning & replacement for solution filters 4.6 installation of the body & waste container 4.7 Power supply HYDRABEAUTY... - Page 4 6. Maintenance 6.1 Outlines 6.2 Cleaning 6.3 Storage 6.4 Checking before reporting the fault 7. Warranty 7.1 Outlines 7.2 Guarantee for free 7.3 Exclusions within free warranty period 7.4 Compensatory guarantees 8. Product specifications 9. Customer services / Sales HYDRABEAUTY...
-
Page 5: Product Overview
1. Product overview General subjects The system for Hydrabeauty is designed to meet the international standard for medical devices, so it is secure, rugged, and easy to use. Please keep the basic maintenance list such as handpiece tip replacement, proper cleaning and so on. -
Page 6: Safety Precautions
Remove the power plug and keep it clean for a long time when not in use. This may cause an electric shock, a short circuit or a fire. If the device has flooded, unusual sounds, burning smells, or smoke, turn off the power immediately before calling the service center. HYDRABEAUTY... -
Page 7: Fire Risk Precautions
Procedures are performed with reference to the proposed procedural guidelines for this equipment, but the results may vary depending on the patient's condition and the procedure environment. Please set the procedure value and apply the procedure technique with sufficient consideration of the patient's condition before perform the procedure HYDRABEAUTY... -
Page 8: Product Composition
3. Product composition 3.1 Product structure Screen LCD Aqua handpiece tip EP handpiece Aqua handpiece Peeling handpiece Control lever Cover Solution (Inside) -Rear side– Solution4 (Cleansing mode) & Bulk waste basket - Front side - HYDRABEAUTY... -
Page 9: Components
⑦ Aqua tip small(10ea/1pack) ⑩ Empty solution bottle ⑧ User manual ⑨ Fuses ⑪ Handpiece cap(Extra) 500ml * 4ea(Extra) ⑫ Peeling ⑫ Solution filters handpiece filter ⑬ Power cable *4ea(Extra) (100ea/1pack) NOTE Each component is available through contact Eunsung Global Corp.(TEL: 02-514-9713) HYDRABEAUTY... -
Page 10: Outlines
4. Product installation 4.1 Outlines 1. This device must be installed by an educated or licensed person in Eunsung Global Corp. 2. Before installation the device, taking into consideration its position and space, and at appropriate distances from the device or other medical device that generates heat 3. - Page 11 Clean the hand piece cables after the solution 2 procedure using the " C " cleaning mode before do the solution 3 procedure. After all procedures (after all 3 solutions ), clean the handpiece again with cleansing mode and store it. HYDRABEAUTY...
- Page 12 When replacing the peeling tip, turn the tip counterclockwise to remove it and match the tip exactly to the connector part. Please install or replace the filters and tips correctly, refer to the pictures below. - Remove peeling tip- - Filter - Ready to use - replacement - HYDRABEAUTY...
-
Page 13: Handpiece Decomposition
1. Fully loosen the locking screw by turning it to the left and pull out the cable connector. CAUTION Follow the instruction when connecting the cable to the device. Otherwise, it will not operate properly and cause a device malfunction. HYDRABEAUTY... -
Page 14: Installation Of The Body & Solutions
Solution 4 (for clanging mode) is connected separately to the rear of the main body. After you adjust the connection part exactly, turn it counterclockwise to tighten it in order to connect it to the hose. -Solution 4 is installed correctly- HYDRABEAUTY... -
Page 15: Cleaning & Replacement For Solution Filters
Rinse in running water and pat on the flat surface. Drain and reuse. See the illustration below and install the filter correctly Filter equipped appearance (Front side of device) Fit the arrow on the filter facing up. Filter equipped appearance (Rear side of device) HYDRABEAUTY... -
Page 16: Installation Of The Body & Waste Container
O (OFF) and l (ON). -Power on- -Power off- CAUTION The container must be pushed fully into place to exactly coincide with the connecting parts. If not correctly installed, the valve pressure is decreased and may cause the device to be damaged. HYDRABEAUTY... -
Page 17: How To Use
- Is the device secured against movement? - Is the power cable connected properly? 5.2 Precaution before using If the vacuum level is set too high, this can have side effects. Be sure to perform the procedure safely by testing before performing the procedure. HYDRABEAUTY... -
Page 18: Screen & Control Board
-1~3 : Skin treatment -C : Cleansing mode Large waste container level ③ warning indication ④ Peeling handpiece selection button ⑤ EP handpiece selection button ⑥ Procedure time display ⑦ EP level control button ⑧ Start / Stop button ⑨ System management HYDRABEAUTY... -
Page 19: The Way To Use The Device
Adjust the vacuum lever on the control screen to set the vacuum level. Vacuum level can be adjusted during the procedure. Press the ' start/stop ' button to start the procedure. When the treatment is done, press the ' start/stop ' button to finish.. - The screen which has selected diamond peeling handpiece - HYDRABEAUTY... - Page 20 LED's can be selected by repeatedly pressing the ' electroporation selection button ' during the procedure. [4 kinds LED: red, blue, purple, off] When the treatment is done, press the ' start/stop ' button to finish. - The screen which has selected electroporation handpiece - HYDRABEAUTY...
- Page 21 When the treatment is done, press the ' start/stop ' button to finish. - The screen which has selected aqua peeling handpiece - NOTE [Vacuum & Flow Level Guide] 구분 Vacuum Flow 1제 2제 3제 Vacuum / Flow C모드 5(MAX) 5(MAX) HYDRABEAUTY...
- Page 22 -Incorrect- 7. Cleansing mode Hydrabeauty offers auto cleansing mode. Choose the ‘C’ mode on the screen which is aqua peeling. Set the vacuum and solution flow lever to the maximum level and push the start button, then the auto cleansing mode will be started for 1min. At this moment, Aqua handpiece should be covered with cap.
-
Page 23: Large Waste Container
[Water sensor of the container] CAUTION Be careful when you empty the container, since the weight of the waste solution may cause it to drop or spill the waste solution when open it. HYDRABEAUTY... -
Page 24: Maintenance
Cleaning and storing with the power on, will cause serious damage or danger to the device. CAUTION The aqua hand piece tip is disposable and must be discarded after each treatment, and no liability for any problems due to reuse is provided by the Eunsung Global Corp. HYDRABEAUTY... -
Page 25: Checking Before Reporting The Fault
When the container has filled more than 2.4L, there will be Full waste container warning message shown on the screen, and automatically the Unusual device will be stopped. device performance ▪ Check ON/OFF status Faulty power status ▪ Check connection of power cable HYDRABEAUTY... -
Page 26: Warranty
7. Warranty About Warranty 1. Eunsung Global Corp. provides the following assurance for products in accordance with the Consumer Dispute Resolution Criteria by Item (Fair Trade Commission Notice). 2. Describes the free service description and the standard of service charge when using the device normally. -
Page 27: Product Specifications
330 X 425 X 1060mm Weight 32kg 9. Customer services / Sales Producer Manufacturer : Eunsung Global Corp. Country of manufacture : Korea Head office : 120, Gieopdosi-ro, Gagok-ri, Wonju-si, Gangwon-do, Republic of Korea. Tel. +82)33-760-9713 / Fax. +82)33-746-9716 Seoul office :... - Page 28 HYDRABEAUTY...
