Summary of Contents for Storm UNIQUE 2.1
- Page 2 Operating manual UNIQUE a Look Solutions product...
- Page 3 Set of Equipment supplied – 1 Unique 2.1 – 1 tank lid with quick connector, silicon tube and air valve filter – 1 canister of UNIQUE-fluid, 2l – 1 manual As an option: – XLR remote for analogue control (delivered without cable) –...
-
Page 4: Table Of Contents
3. Description of the parts 4. Fluid 4.1 General notes 4.2 Changing the fluid canister 4.3 Storage of the fluid 5. Operating the Unique 2.1 5.1 Selecting the location 5.2 Putting into operation 5.3 Switching the device off 5.4 Control choices 5.4.1 Control via DMX 512... -
Page 5: Introduction
finest mist to a thick haze, similar to fog. Therefore the Unique 2.1 is able to fill rooms or halls with a constant haze, creating the right atmosphere and is providing excellent support for lighting effects. -
Page 6: Safety Instructions
2. Safety instructions A fog machine is not a toy! Thus never aim at persons directly and keep a minimum distance of 3 m (9.8 ft) to the nozzle. sensitive to heat. It has to be twice as big as the machine. and objects sensitive to heat. -
Page 7: Description Of The Parts
3. Description of the parts Rear view P 2 5 This machine has been designed to be used with original Look Unique-fluid. Use of other liquids will void the manufacturer's warranty and can be dangerous to your health. Never use cleaner or fragrances with this machine! 230 V~/50 Hz/1500 W UNIQUE Serial no. -
Page 8: Changing The Fluid Canister
3. Description of the parts Tank lid 9: · Brass collar 10: · Tank lid 11: · Brass coupling 12: · Fluid filter 13: · Check valve... -
Page 9: Fluid
4. Fluid 4.1 General notes The ready-to-use UNIQUE-Fluid for use in the Unique 2.1 is available in 2 litre canisters from your local dealer. Fluid also comes in 10 and 25 litre canisters and barrels with 220 litres. Use of other liquids will void the manufacturer‘s warranty and can be dangerous to your health. -
Page 10: Operating The Unique
Important: Do not connect a ducting to the nozzle of the Unique 2.1. If a ducting is connected directly to the machine the haze will be pushed back into it. This may damage the machine. -
Page 11: Switching The Device Off
5. Operating the Unique 2.1 5.3 Switching the device off After 15 Seconds the machine will switch into the post-run- move from upper left to the lower right while the heater is cooling. To cut this process short, the air pump works with full power for a short time and also put all remaining fluid out of the vaporizer. - Page 12 5.4.1 Operating via DMX 512 Connecting the Unique 2.1 to a DMX desk, use the XLR socket [2] beside the control panel. As soon as the machine receives a correct DMX signal, the yellow DMX-LED [19] will be lit.
-
Page 13: Adjusting The Dmx Start Address
The adjusted channel controls the pump, the following one controls the fan. 5.4.2 0 - 10 Volt (+) DC control Connect the Unique 2.1 to an analogue desk or the cable remote which you can get as an option, using the XLR socket at the back of the machine [3]. -
Page 14: Stand Alone Mode
5. Operating the Unique 2.1 5.4.3 Stand alone The Unique 2.1 can be used in the Stand alone mode. In this mode all data for the pump and the fan must be adjusted directly at the machine. 5.4.3.1 Adjusting the pump and fan output a) Press the Mode-button [14] at the control panel until a P and two figures appear on... -
Page 15: Using The Profile
5. Operating the Unique 2.1 With the HDCS, an individual profile for a show can be programmed. Two Levels (Level A and B) with different pump and fan values and different run-times can be program- med (Level A = settings 2, 3, 4 / Level B = settings 5, 6, 7). Also a pre-runtime can be programmed in (setting 1) which tells the machine when it should start to run. - Page 16 5. Operating the Unique 2.1 Pump% Fan% Level A Level B Time Pause Run-Time Level A Run-Time Level B min. 5.4.5 Operating the internal Timer P.0.1 F.0.5 Fig 10: Adjusting the Pause (Wait-Time) Fig. 11: Adjusting the haze time F 7 5 P 1 5 Fig.
-
Page 17: Autostart
If the timer is in operation and you disconnect the machine from the mains cable, the Unique 2.1 will re-start in the Timer-Mode as soon as it‘s reconnected to the mains. To in the Timer-Mode and then press the Enter-button. -
Page 18: Cleaning, Care And Maintenance
During operation the nozzle gets very hot! – Do not let the Unique 2.1 run without any fluid as the pump will run dry. – Check the state of the fluid filter [12] from time to time and clean or replace it when necessary. -
Page 19: Specifications
7. Troubleshooting Trouble: E-4 appears on the LED display Cause: The machine is getting too hot. The heating switches off and the machine cools down. E – 4 Solution: Disconnect the machine from the mains supply for a moment and then re-connect it. Trouble: E-8 appears on the LED display Solution:... -
Page 20: Warranty Conditions
9. Warranty conditions For the haze machine Unique 2.1 Look‘ guarantee is: 1. Free of charge, subject to the following conditions (No. 2 - 6) we will repair any defect or fault in the unit if it is caused by a proven factory fault and has been advised immediately after appearance and within 24 month of delivery to the end user. - Page 21 a Look Solutions product...
