- Page 1 EM4483 - MPEG4 Network IP Camera...
-
Page 2: Table Of Contents
7.1 Installing the NVR software ................15 7.2 Schedule recordings ..................15 8.0 Frequently asked questions ................. 17 9.0 Service and Support .................... 18 1.0 Warranty conditions The warranty period of five years applies to all Eminent products, unless stated... -
Page 3: Introduction
2.1 Functions and features The EM4483 is an IP camera, which is able to produce an outstanding image and is also equipped with a microphone and MPEG4 compression technology. These features allow you to view and listen to high quality images and sounds made by the camera through the Internet or your own network. -
Page 4: Explanation Of The Camera
Use this screw hole to connect the mounting stand to the camera. (12) Power Here you can connect the power adapter to the camer 3.0 Preparing the camera Before you can start using the EM4483 IP camera, you will need to set it up for your... -
Page 5: Connecting The Camera
Click ‘All Programs’. Click ‘EM4483 Network IP Camera’. Click ‘EM4483 MPEG 4 Master’. The program MPEG4 Master will open. Click the ‘Search’ button. An IP address will appear in the left field. Enter a name for the camera in the ‘Name’ field. -
Page 6: Logging In To The Camera
ENGLISH If you want to assign an IP address to the camera yourself, select ‘Fixed’ in the ‘IP Address’ field. Enter the preferred IP address in the ‘IP’ field. Example: If your router uses the IP address 192.168.0.1, then change the IP address of the camera to 192.168.0.100. -
Page 7: Setting Up The Camera For Your Wireless Network
ENGLISH Click the third button from above, depicting a wrench (Settings). 10. Enter ‘admin’ in the ‘Username’ field. 11. Enter the password you set in chapter 3.3, step 12 in the ‘Password’ field. 12. Click ‘Ok’. Note! The default password of the camera is ‘admin’. Enter this password if you did not set a password as described in paragraph 3.3, step 12. -
Page 8: Using The Camera In Combination With A Em4050 Wlink Wireless Router
3.6 Using the camera in combination with a EM4050 wLINK Wireless Router As an example we will explain how to use the EM4483 in combination with an Eminent EM4050 wLINK Wireless Router. Now that the camera is set up for your network, the image of the camera can also be viewed using an internet connection. -
Page 9: Other Camera Settings
ENGLISH Now that the port for the camera has been opened, anyone can view the images of your camera using the Internet by following the instructions below: Open your Internet browser (for instance Internet Explorer, Netscape or Firefox). Enter the WAN IP address (which you received from your provider) in the address bar. -
Page 10: Adjusting The Sound Quality
4.2 Adjusting the sound quality Because the EM4483 is equipped with a built-in microphone, it is also possible to accompany the sent videos with sounds. This option is be enabled by default. To set the quality of the audio signal you can click the tab ‘Audio’... -
Page 11: Using Motion Detection
3.4, steps 1 through 4 and through the Internet as described in chapter 3.6. 5.0 Using motion detection The EM4483 is equipped with built-in motion detection which allows the device to be used as a security camera. It is possible to let the camera send an image to an FTP server or e-mail address the moment a movement is detected. -
Page 12: Sending An Image To An E-Mail Address
12 | ENGLISH Enter the IP address you set in chapter 3.3 in the address bar of the browser (for instance 192.168.0.100). Press the enter button or click ‘Go to’. The opening screen is shown. Click the third button from above, depicting a wrench (Settings). Enter ‘admin’... -
Page 13: Saving Images
6.0 Saving images The EM4483 allows you to make screenshots of the view of the camera. You can also record images and sound to a video file. This makes it possible to see what happened at the location where the camera is mounted, after the events took place. Be warned... -
Page 14: Recording, Saving And Viewing Videos
14 | ENGLISH To view the new screenshot, use Windows Explorer to browse to the location you specified in step 10 (for example C:\Camera). Here you will find the new file. Double click the file to view the contents. 6.2 Recording, saving and viewing videos First you will need to specify the location where you wish to save the recorded videos to. -
Page 15: Network Video Recorder Software
ENGLISH 7.0 Network Video Recorder software The EM4483 camera is supplied with the so-called ‘Network Video Recorder’ (NVR) software. This allows you to save the video images of the camera to the hard disk of a computer, or to make permanent recordings to a hard disk. - Page 16 16 | ENGLISH Click ‘Start’. Click ‘All Programs’. Click ‘NVR’. Click ‘NVR’ again. The NVR software will be started. Click the fifth button from above (Schedule Settings). A new screen will appear. This screen displays a calendar, divided in weekends (pink color) and week days (yellow color).
-
Page 17: Frequently Asked Questions
17 | ENGLISH Settings’, recording for this date will be triggered by motion detection instead of the time schedule. In the left menu, in the field below ‘Apply Settings To’, you will need to choose the camera to which this schedule will be applied. Then click the ‘Apply Settings To’... -
Page 18: Service And Support
A. You can use these to mount the camera to (for instance) the wall or the ceiling. 9.0 Service and Support This users manual has been carefully written by Eminent’s technical experts. If you have problems installing or using the product, please contact support@eminent-... - Page 19 To ensure your safety and compliance of the product with the directives and laws created by the European Commission you can obtain a copy of the Declaration of Conformity concerning your product by sending an e-mail message to: info@eminent- online.com. You can also send a letter to: Eminent Computer Supplies P.O.
