User guide
(standard guide for Ultimate models)
(Art.-Nr. HDTS01)
HDTS trampoline measurement system
General informations ......................................................................................................................................... 2
General data ...................................................................................................................................................... 3
Parts list ............................................................................................................................................................. 3
Assembly instructions ....................................................................................................................................... 4
Certificate ........................................................................................................................................................ 21
1
Eurotramp - Trampoline Kurt Hack GmbH
Advertisement
Summary of Contents for Eurotramp HDTS trampoline measurement system
-
Page 1: Table Of Contents
User guide (standard guide for Ultimate models) (Art.-Nr. HDTS01) HDTS trampoline measurement system General informations ............................2 General data ..............................3 Parts list ................................3 Assembly instructions ............................4 Certificate ................................ 21 Eurotramp - Trampoline Kurt Hack GmbH... -
Page 2: General Informations
• Microsoft Visual C++ 2015-2019 Redistributable Glossary • ToF: Time of Flight • HD: Horizontal Displacement • SYN: Synchronicity • IM: Individual Mode • SM: Synchronized Mode • FP: Force Plate • USB-Box: USB-Master Eurotramp - Trampoline Kurt Hack GmbH... -
Page 3: General Data
Standard for Eurotramp Ultimate models (Adapter for other models available) • If the trampoline is not from Eurotramp, a stability plate adaptor can be purchased. • This User Guide is especially for Qira V2.0.x. Some features may be similar in other versions. The current Qira software can always be downloaded from the Eurotramp website, under the following link: www.eurotramp.com/de-en/products/accessories/hdts/product-downloads/... -
Page 4: Assembly Instructions
Connect force plates 1 and 2 (3 and 4 respectively) with a blue ethernet cable using the inner ports. Connect force plates 2 and 3 with a green ethernet cable using the outer ports. Make sure to lead the cables around the pins as shown in the picture to prevent damage Eurotramp - Trampoline Kurt Hack GmbH... - Page 5 Install the cables under butt connectors (trip hazard and risk of damage); • Fix USB-Box to the table or on the ground; • Protect Ethernet-cables between trampoline and judge’s table (for example: lay under mats and flooring). Eurotramp - Trampoline Kurt Hack GmbH...
- Page 6 Settings menu. If the trampoline you are using is not listed, enter the distances between midpoints of the floor protection of your trampoline. Finally, continue with the self test to ensure the system’s function. Eurotramp - Trampoline Kurt Hack GmbH...
- Page 7 Self Diagnosis shows the status of the connected hardware. In this example Qira receives measures from each forceplate of trampoline 1 and no values from trampoline 2. In this state the system is ready to record routines on trampoline 1. Use for initial System-check and troubleshooting. Eurotramp - Trampoline Kurt Hack GmbH...
- Page 8 Right-Click in the window and click show details to present pressure-values (P), tara-values (T) and net-values (N =P-T) for each forceplate. Program interface The application is structured in four major areas: Current state Configuration Competition organization Results Eurotramp - Trampoline Kurt Hack GmbH...
- Page 9 The software measures and evaluates horizontal displacement as well as time-of-flight or synchrony in the state ROUTINE. • REVIEW state is intended for checking and approving results. Press space to iterate between the four states. Eurotramp - Trampoline Kurt Hack GmbH...
- Page 10 The automatic trampoline detection takes up to five seconds to switch the active trampoline. The transition to the next state is initiated by pressing the spacebar as soon as the athlete shows the first ele- ment of the routine. Eurotramp - Trampoline Kurt Hack GmbH...
- Page 11 X key (5). Either confirming or dismissing the results leads to a transition to the READY state. All necessary steps to measure a routine are covered. The next chapters describe advanced functions like confi- gurations, save-modes and structuring a competition. Eurotramp - Trampoline Kurt Hack GmbH...
- Page 12 Feature for recording events taking place in executing Qira. Creates a logfile in storage path. b) Athlets/Events (Athleten/Veranstaltungen) (Shortcut: F4) • Set Athletes and Events for Auto-Save Function (File) • Not compatible with Auto-Save Function (Database) Eurotramp - Trampoline Kurt Hack GmbH...
- Page 13 Enable the Auto-Save Function (File). Set a storage path for the result-files. The Athletes and Events crea- ted in “Athletes/Events“ (F4) can be selected as part of the filename. Add Date, Time or increasing Num- bers to the filename. Eurotramp - Trampoline Kurt Hack GmbH...
- Page 14 Network Settings for system communication – under development. e) Single Drop Test Function for system development – records a single landing position. f) Font Settings for font and font size (default: Arial, 10). Eurotramp - Trampoline Kurt Hack GmbH...
- Page 15 Shows current database file and path; existing DB file; • Browse and load another existing DB file; • Merge current and another DB file without a • Browse and save the current DB file; duplicate. Eurotramp - Trampoline Kurt Hack GmbH...
- Page 16 Structure (Shortcut: F4) a) Create Event • Confirm information-input with „Add“-button; • Confirm changes with „Replace“-button; • Delete incorrect input with „Delete“-button. b) Select Event Select an event in „Structure“ on the Qira mainscreen. Eurotramp - Trampoline Kurt Hack GmbH...
- Page 17 Select gender and type of competition. (Shortcut: CTRL+A) d) Create Athletes • Create athlete with „Add“-button; • Create next athlete; • Confirm changes with „Replace“-button; • Delete athlete with „Delete“-button; • Add Information and select gender. Eurotramp - Trampoline Kurt Hack GmbH...
- Page 18 Create Groups (Shortcut: CTRL+G) • Add group with „Add Group“-button; • Delete incorrect input with „Delete Group“-button. • Select group from dropdown-menu „Group“ . Eurotramp - Trampoline Kurt Hack GmbH...
- Page 19 Name of athlete is shown on the selected trampoline • Record routine for this athlete • „X“ beneath the name cancels athlete Show results afterwards • Double click on athlete in sidebar; • Single click on routine in sidebar. Eurotramp - Trampoline Kurt Hack GmbH...
- Page 20 If you have any questions, contact us any time: Eurotramp-Trampoline Kurt Hack GmbH Zeller Straße 17/1 | 73235 Weilheim Tel. +49 (0)7023 - 9495-0 | Fax +49 (0)7023 - 9495-10 welcome@eurotramp.com | www.eurotramp.com Eurotramp - Trampoline Kurt Hack GmbH...
-
Page 21: Certificate
Eurotramp - Trampoline Kurt Hack GmbH...
