Access Security Products RD-PN10 Manual

RD-PN10 - Standalone Access Controller and Reader
1 Description & Features
P10 is a waterproof standalone access control, reading EM&HID card, it uses advanced Microprocessor, with high-capacity flash memory for 10000
users. Users can be added and deleted via admin card, very simple to operate. The infrared remote control make the device not only have alarm,
protection, two units interlocked, anti-passback function but also can make two units interlocked, add and delete the user on the remote control key
directly. Besides, it has low power consumption design, anti-theft alarm, door release button etct, all these make it convenient, safe and reliable.
2 Installation, wiring, diagram
Drill the holes according to the distance and the dimension on the back cover, or install the distributing box.
•
Thread the cable through the cable hole, connect wires needed, wrapped Unused wires with insulating tape in case of short circuit
•
Fix the back cover on the wall with special screw
•
Fix the front cover to the back cover with the screws
•
： ： ： ：
Feature
Waterproof Design
Ultralow power consumption
Large capacity
wiegand reader
Connect external reader
two units interlocked
Anti-passback
No. Marks
1 RESET
2 GND
3 D0
4 D1
5 ALARM-
6 OPEN
7 D_IN
8 +12 - 24V
9 GND
10 NO
11 COM
12 NC
Note ： P lease check all wires and install front cover carefully before power on.
Description
Rainproof, moisture proof , durable
Longer working life, more stable performance
10000 card users
Can used as wiegand 26 output reader
Can connect EM/IC/HID wiegand 26 output reader
two units can be interlocked online
Single door or two doors anti-passback
Wiring
Colour Description
Pink RESET
Pink RESET
Green Wiegand output D0
White Wiegand output D1
Gray Alarm
Yellow Exit button
Brown Door contact switch
Red +12 - 24V Input
Black GND
Blue Relay NO end
Purple Relay Com
Orange Relay NC end
