- Page 1 HANDY CALIBRARTOR CA-20 Instruction Manual Please read this manual before using the product and keep the manual handy. Rev. D TEAC Corporation February, 2012...
- Page 2 SAFETY INSTRUCTIONS CAUTION: Read all of these Instructions. Save these Instructions for later use. Follow all Warnings and Instructions marked on the product. 1) Read instructions -- All the safety and operating instructions should be read before the product is operated. 2) Retain instructions -- The safety and operating instructions should be retained for future reference.
- Page 3 SAFETY INSTRUCTIONS 16) Servicing -- Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 17) Damage Requiring Service -- Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a) when the power-supply cord or plug is damaged.
- Page 4 SAFETY INSTRUCTIONS DISCLAIMER TEAC disclaims all warranty, either expressed or implied, with respect to this product and the accompanying written materials. In no event shall TEAC be liable for any damages whatsoever (including, without limitation, damages for loss of business profits, business interruption, loss of business information or other loss) arising out of the use of or inability to use this product.
- Page 5 TEAC grants to you the right to use the SOFTWARE only in combination with the TEAC handy calibrator CA-20. 2. COPYRIGHT All title and copyrights in and to the SOFTWARE and any copies thereof are owned by TEAC or a supplier to TEAC. The SOFTWARE is protected by Japanese copyright laws, international treaty provisions, and all other applicable national laws.
-
Page 6: Table Of Contents
4-1. Install batteries.........................6 4-2. Attach accelerometer .......................6 4-3. Driving ............................7 4-4. Measure ............................8 5. Function ............................10 5-1. Storing Data to CA-20 ......................10 5-2. Data List ...........................10 5-3. Measurement Mode ........................10 5-4. Auto Power Off ........................10 5-5. Time Setting..........................10 5-6. Storing Data to PC ........................11 6. -
Page 7: T1. Overview
The unit shakes the accelerometer, measures output signal from accelerometer, and calculates sensitivity. * CA-20 shakes accelerometer at 159.2 Hz to get sensitivity easily and simply in the field. It is not recommended for high-precision calibration for laboratory or institute use. - Page 8 To get into menu mode, press both UP and DOWN key at once. 4. Enter key Store sensitivity data to PC or CA-20. On menu mode. this works as ENTER key. 5. PC Link Red : Communication mode is set to “Link”...
-
Page 9: Menu Items And Settings
Transfer data to PC Return Return : Factory settings All settings are kept, even if CA-20 is turned off. Typical PCB® accelerometer use 4 mA / 24 V. So please change source current to 4 mA and source voltage to 24 V. -
Page 10: Operations
4. Operations 4-1. Install batteries When CA-20 is used under battery mode, install batteries to the case on bottom. Unfasten screw of battery case. Install four LR-6(AA) alkaline batteries to battery case. Screw Battery pole sign Note: - Operating time depends battery type. -
Page 11: Driving
4-3. Driving - CA-20 starts to shake the base and measure the sensitivity immediately, when turned ON - In case of charge type accelerometer, push select switch ∆ to change charge mode. - In case of IEPE , ICP® type accelerometer, push select switch to change ICP®... -
Page 12: Measure
4-4. Measure Charge mode ICP® mode Alarm Overload 1. Sensitivity Calculated sensitivity is displayed. 2. Unit pC/G (Charge mode), mV/G (IEPE, ICP® mode) 3. Accelerometer type (Charge / Voltage (ICP®) ) Charge (Charge mode), Voltage (IEPE, ICP® mode) 4. Supply voltage, current ICP supply voltage, current... - Page 13 Installed batteries voltage are low, change batteries or connect AC/DC adapter, 8. Over range Sensitivity is too high (maximum sensitivity which CA-20 can calibrate is 196 pC/G or 196 mV/G) * Minimum sensitivity which CA-20 can calibrate is 0.255 pC/G or 0.255 mV/G...
-
Page 14: Function
- Set to “Cut” on PC Link menu and measure the sensitivity. - Push Enter key to store the measured sensitivity. Up to 100 data can be stored to CA-20 unit. During “Full” is displayed, storing data is not available. In this case, delete stored data on CA-20. -
Page 15: Storing Data To Pc
5-6. Storing Data to PC - CA-20 can store measured sensitivity data to pc using data transfer application supplied with CA-20. - Please refer to application manual for the details. 6. Specification Calibration range Charge type accelerometers 0.255 to 196 pC/G IEPE type accelerometers 0.255 to 196 mV/G... -
Page 16: Dimension
7. Dimension... - Page 17 Copyright © 2012 TEAC Corporation. All rights reserved. TEAC CORPORATION 1-47 Ochiai, Tama-shi, Tokyo 206-8530, Japan E-mail: tic_cs@teac.co.jp...
