ASIT T10 Manual

Network Equipment สำ หร ั บ กล ้ อ งวงจรป ิ ด
อุ ป กรณ์ ท ดสอบภาพ CCTV Tester 4 in 1
(AHD, TVI, CVI, CVBS)
HD TESTER
Real HD stream coaxial tester
Real HD stream coaxial tester
HD Tester Manual
ASIT-T10
HD TESTER

1. General

The new HD monitoring test, support AHD, TVI, CVI, CVBS
video format, the largest support 5 million pixels, Coaxial call
camera OSD menu. Support PTZ 485 control, DC 12V power
output, audio test, VGA input, HDMI input, cable test, coaxial
cable test, LED lighting and other functions.
Product Funtions:
Video signal testing：Compatible with AHD, TVI, CVI,
CVBS video test
● 5.0 inch 800 (RGB) x480 resolution. PAL/NTSC (Auto
adapt).
● PTZ control：RS485 control, Porter 1200 ~ 115200bps,
compatible with PELCO-D / P protocol
● Image generator
Multi-format video OUT port image generator, sending a
variety of standard (e.g. PAL, NTSC) color graphics section
● Output DV12V/1A power out,supply temporarily power
for the camera
● USB2.0 interface provides 5V / 1A emergency power
output
● audio signal input：tester whether sound normal
● Enhanced UTP cable / BNC cable test, with indicator
light, the test distance can reach 100-150 meters
● VGA input： VGA support 1024 * 768,1280 * 1024
resolution，VGA access need to enter the menu to select VGA
mode
● HDMI input：HDMI support 480I / P, 576I / P, 720I / P,
1
