Congratulations on your purchase of the Dust Right Vortex
you'll be ready to start cleaning in no time.
Please read these instructions completely before starting to assemble your Dust Right Vortex
the process will make the steps easier to understand. Please follow all steps carefully.
User
Instructions
! Follow these simple assembly instructions and
™
. Familiarity with
™
Advertisement
Summary of Contents for Dust Right Vortex
- Page 1 ! Follow these simple assembly instructions and ™ you’ll be ready to start cleaning in no time. Please read these instructions completely before starting to assemble your Dust Right Vortex . Familiarity with ™ the process will make the steps easier to understand. Please follow all steps carefully.
- Page 2 PARTS lIST - DUST RIghT VoRTex ™ Quantity A Vortex Lid ™ B Vortex Canister ™ C 36" Flexform Hose ™ D Threaded Hose Fittings E Upper Chip Separator Port F Lower Chip Separator Port G Casters...
- Page 3 Triangle indent Fig. 1 Fig. 2 Fig. 3 - Underside of lid shown Fig. 4 Assembly 3. Snap Vortex Lid (A) onto Vortex Canister (B). ™ ™ 1. Snap the five casters (G) into the corresponding 4. Thread both hose fittings (D) to either end of sockets on the bottom of the canister. Fig. 1. Flexform ™ hose (C). Note: Threading is reversed on these fittings. 2. Position the Lower Chip Separator Ports (F) underneath the lid with the indents on the Lower 5. Insert one end of the Flexform hose (C) into ™ Port aligned with the indents on the lid. Fig. 2. Be Chip Separator Port (E) and the other end into your sure the Lower Ports are pointing in opposite shop vacuum. Fig. 4. directions. Fig. 3. Then Thread the Upper Chip Note: Either end can be used as the input or Separator Port (E) to the Lower Port (F), sandwiching output ports. the lid (A) in between.
- Page 4 Existing shop vac hose or 2 ⁄ " shop hose Flexform ™ hose Clean up Shop Power tool wand Vortex ™ canister Fig. 5 6. Insert one end of your existing shop vacuum hose in the open Vortex port, and attach the other end to your ™ power tool dust port or a shop cleanup handle/wand. Fig. 5. Tip: Some shop vac hose fittings are slightly under ⁄ ". In this case a couple wraps of tape will make a tighter fit. Fig. 6. 7. For best results, do not fill past the fill line on the Vortex ™ bucket. Fig. 7. Shop vac hose Tape Dust Right Vortex Troubleshooting ™ Too much dust and dirt is getting to your Fig. 6 vacuum’s filter: 1. Small amounts of dust and fine dust will appear in your vacuum’s filter. This is normal. 2. Check for air leaks. Even a small leak can Fill line affect performance.
