163732
Miter
Gauge
System
Instruction
Manual
WARNING: Read entire manual for important safety, assembly,
operating procedures, adjustments, maintenance and storage
instructions before using the miter gauge.
WoodRiver is distributed by Woodcraft Supply, LLC.
For Technical Product Support Call 800-535-4486. For A Free Catalog Or To Find
Your Local Woodcraft Store, Visit woodcraft.com Or Call 800-225-1153.
Advertisement
Table of Contents
Summary of Contents for Woodcraft Wood River 163732
- Page 1 WoodRiver is distributed by Woodcraft Supply, LLC. For Technical Product Support Call 800-535-4486. For A Free Catalog Or To Find Your Local Woodcraft Store, Visit woodcraft.com Or Call 800-225-1153.
- Page 2 SAFETY INSTRUCTIONS Read and understand the operation and applications described in this instruction manual as operating a miter gauge and a table saw can be dangerous. Heed all safety instructions and warnings, and DO NOT operate this Miter Gauge if you do not fully understand its use and limitations. DO NOT modify this Miter Gauge in any way, and REMEMBER that your personal safety is YOUR responsibility.
- Page 3 Miter Gauge System Figure 1 Handle (1) Fence (1) Flat Nylon Washer (1) Flat PVC Washer (3) Knurled Knob (2) Miter Gauge (1) Lock Knob (1) Flip-Stop (1) T-Bolt (1) Ruler Tape (1) Square Nut (2) Pointer Bracket (1)
- Page 4 Parts Figure 2 Carefully unpack Miter Gauge and all loose items. Figure 2 illustrates parts supplied with the Miter Gauge. Handle Fence & Ruler Tape Flat Nylon Washer Flat PVC Washer (3) Knurled Knob (2) Miter Gauge Assembly Lock Knob Flip-Stop T-Bolt Square Nut...
- Page 5 STEP 3: Knurled Bolts & Nuts Figure 5 Figure 5 Place a Flat PVC Washer (D) over the threads of each of the Knurled Knobs(E), and push through the vertical slots on the upright surface of the Miter Gauge Assembly (F). Loosely thread a Square Nut (J) onto the Knurled Knob (E) on the other side of the Miter Gauge Assembly (F).
- Page 6 OPERATION Figure 9 Angle Cuts Use the spring-loaded plunger and pin to set common angles for segmented turning. For angles without detents, make sure to fully tighten the Handle (A) at the intermediate angle. Make sure the Fence (B) is adjusted away from the blade.
- Page 7 Crosscuts Figure 11 Use the spring-loaded plunger and pin to set the miter gauge to 0º (zero). Tighten the Handle (A) to make sure the miter gauge stays at zero. Make sure the Fence (B) is adjusted away from the blade. Hold the material tightly against the Fence (B) when making crosscuts.
- Page 8 Please keep your dated proof of purchase for warranty and servicing purposes. REPLACEMENT PARTS To order parts, please contact Woodcraft Technical Service at 1-800-535-4486. Please use the indicated letter listed in this manual for all part orders where applicable. NOTE TO USERS This instruction manual is meant to serve as a guide only.
