Myriad Design – Altoids Piezo DI – Construction Guide
1. The package should include the following items. If any of the items are missing from the package,
please contact
sales@stompville.co.uk
Designation
PCB
R1, R5, R6
R2
R3
R4
R7, R8
R9, R10
R11
R12
R13
R14
R15
R16
C1, C6
C2
C3
C4, C5, C9, C12,
C13
C7, C8
C10, C10, C11,
C11
C14
D1, D2, D3, D4
D5
Q1, Q2
U1
U2
LED1
-
J1, J2
SW1
-
-
-
-
-
-
-
-
-
1
Altoids is a trademark of the Wrigley Company. Their rights are hereby acknowledged.
2
Some resistors may be 4-band and some 5-band. See: http://stompville.co.uk/ResistorColourCodes.pdf
2. It is assumed that you have some experience of soldering and building of simple kits and are
confident to build or modify effects pedals. If not, there are many relevant tutorials and videos on
V2 December, 2014
:
Description
1
Altoids
Piezo DI - printed circuit
board
1/8W resistor - 10k
1/8W resistor - 10M
1/8W resistor - 4k7
1/8W resistor - 1M0
1/8W resistor - 33R
1/8W resistor - 1k0
1/4W resistor - 10R
1/8W resistor - 180k
1/8W resistor - 120k
1/8W resistor - 220k
1/8W resistor - 150k
1/8W resistor - 3k6
22p ceramic
470p ceramic
47n polyester box
100n polyester box
47u 50V electrolytic
100u 50V electrolytic
10n ceramic
1N4148 diode
BZX55C33V
PF5102 JFET matched pair
LM833 dual op-amp
TC54VN2902EZB voltage detector
3mm red LED
Battery Clip
1/4" stereo jack socket CL11155
push-on push-off switch
8-pin DIL socket
green wire
card with self-adhesive tape/foam
self adhesive foam pad
M3 x 6 pozi pan machine screw
M3 brass nut
label for underside of Altoids tin
template drawing for cutting holes
quick start guide
Page 1 of 6
Marking
APDV4DS06
See Note 2
22
470
47n or .047
100n or .1
10n or 103
1N4148
BZX55C33
PF5102
LM833
54VN2902
