Table of Contents
1
Basic safety symbol----------------------------------------- 2
Appliance connection -------------------------------------- 2
Safety and warning information--------------------------- 2
Product features--------------------------------------------- 6
Product components---------------------------------------- 7
Installation dimension-------------------------------------- 8
Transport----------------------------------------------------- 9
Place environment ----------------------------------------- 9
Adjust plastic feet------------------------------------------
Before using ------------------------------------------------ 10
Starting and functions setting ---------------------------- 10
Control panel ----------------------------------------------- 10
Feature selection --------------------------------------------11
Freezer compartment settings ----------------------------11
Refrigerator compartment settings ---------------------- 12
Lock/unlock button ----------------------------------------- 12
Open door alarm ------------------------------------------- 12
Refrigerator chamber ------------------------------------- 13
Freezing chamber ------------------------------------------ 14
Storage of foods ------------------------------------------- 15
Energy saving tips ----------------------------------------- 15
Defrosting --------------------------------------------------- 16
Cleaning ----------------------------------------------------- 16
General information --------------------------------------- 16
Normal phenomena --------------------------------------- 17
Trouble shooting ------------------------------------------ 18
Warning ----------------------------------------------------- 19
9
Advertisement
Table of Contents
Related Manuals for ASCOLI ACDW571W
Summary of Contents for ASCOLI ACDW571W
-
Page 1: Table Of Contents
Table of Contents Safety and warning information Basic safety symbol----------------------------------------- 2 Appliance connection -------------------------------------- 2 Safety and warning information--------------------------- 2 Product Introduction Product features--------------------------------------------- 6 Product components---------------------------------------- 7 Installation dimension-------------------------------------- 8 Installation Transport----------------------------------------------------- 9 Place environment ----------------------------------------- 9 Adjust plastic feet------------------------------------------ Operation Before using ------------------------------------------------ 10 Starting and functions setting ---------------------------- 10... -
Page 2: Safety And Warning Information
Safety and warning information Basic safety symbol This guide contains many inportant safety messages. Always read and obey all safety messages. △ This is the safety alert symbol.It alerts you to safety messages that inform you of hazards that can kill or hurt you or others or cause damage to the product.All safety messages will be preceded by the safety alert symbol and the hazard signal word DANGER,WARNING,or CAUTION.These words mean:... - Page 3 Safety and warning information Safety and warning information △ Do not damage the refrigerant circuit. WARNING Refrigerant will cause serious injury when it splashing into the eyes.If it happened please go to hospital immediately. Keep ventilation openings,in the appliance enclosure or in the built-in structure,clear of obstruction.
- Page 4 Safety and warning information Safety and warning information The dedicated outlet should be used . Using several devices at one outlet may cause fire . Install the appliance in a dry , well ventilated room . The appliance should be place close to socket , it is easy to cut off the power supply at the time of the accident .
- Page 5 Safety and warning information Safety and warning information Wait for 5 minutes or longer when reconnecting the plug. It may cause the operation of the freezer to fail. After 5 minutes Do not use the fridge for non-domestic perpose(storing medicine or testing material,blood,using at the ship,etc.) It may cause an unexpected risk such as fire,electric shock,deterioration of stored material or chemical reaction.
-
Page 6: Product Introduction
Product Introduction Product features Energy saving and noise reduction It contains super freeze,energy saving,noise reduction, optimal refrigeration system to achieve. Precise temperature control Microcomputer control system separate to set,control and display the R-temperature and F-temperature,more precise control. Automatic defrosting Special program to reduce the temperature fluctuation of the fridge,it's for keeping food fresh. -
Page 7: Product Components
Product Introduction Product components All figures in this manual are schematic; some features and devices may not be consistent fully with your refrigerator and the specific structure and configuration shall be subject to the actual product. The appearance and specifications of the actual product may differ depending on the model. A Freezer compartment B Refrigerator compartment 1 Freezer door tray... -
Page 8: Installation Dimension
Product Introduction Installation dimension Select a good location to place your appliance where it is flat and easy to use.Avoid placing the unit near heat sources,direct sunlight or moisture. 1655 The figure above is schematic for installation only, not representing the actual product. -
Page 9: Installation
Installation Transport Do not carry the refrigerator horizontally or reversely. Do not carry the refrigerator by holding the door or handle; the refrigerator shall be carried by lifting the bottom. Place environment The refrigerator must be placed on a hard, flat ground; if cushioning is needed, stable, hard, nonflammable cushion blocks shall be used, rather than the foam backing of refrigerator. -
Page 10: Operation
Operation Before Using Remove all packages, including the foam backing at the bottom of refrigerator and the tapes fixing accessories in the box. Place the refrigerator to a proper position, and adjust the feet to level. It is better to clean the refrigerator before use. Remove the film: There is a layer of transparent film on the panel of our product, which can protect products from being scratched in the process of production and transportation, and you can choose to... -
Page 11: Feature Selection
Operation Feature selection Each press of the “Feature” button will cycle through the operating modes. Holiday Mode - the refrigerator will run at 6°c while the freezer will operate at -15°c. Super freezer mode - when super freezer mode is selected, the compressor will operate continuously for 180 minutes after which the freezer will return to the last set operating mode. -
Page 12: Refrigerator Compartment Settings
Operation Refrigerator compartment settings The default temperature of the refrigerator is 5°C. To change the temperature press the “Fridge” button to cycle through the set temperatures. Set temperature Lock/unlock button This product has button lock function. Press the “Lock” button will enable lock mode and the lock icon will be visible. -
Page 13: Refrigerator Chamber
Operation Refrigerator chamber The refrigerator chamber is mainly used to store foods that are preserved for a short time. The refrigerator chamber is suitable for storing fruits,vegetables,drinks and other foods that will be eaten recently. It is suggested to seal foods and then put them into the refrigerator. -
Page 14: Freezing Chamber
Operation Freezing chamber The freezing chamber is used to freeze foods, store deeply frozen foods and make ice cubes. It can preserve foods for a long time. The freezing chamber is suitable for retaining the freshness of foods for a long time. When storing meat, it is suggested to cut the meat into pieces which are easy to take out, and mark the freezing date to prevent foods from exceeding the time limit. -
Page 15: Storage Of Foods
Operation Storage of foods Instructions for storing foods When storing freezing foods, put them to the inside of freezing chamber, other than the bottle rack. Do not put bottled or canned foods into the freezing chamber to CAUTION prevent frost cracking. Before putting hot foods into the refrigerator, cool them to room temperature first;... -
Page 16: Maintenance
Maintenance Defrosting This production has automatic defrosting function, without manual operation. Cleaning Precautions for internal and external cleaning of refrigerator: ■ Before cleaning, always turn off the power switch, disconnect the power plug. ■ During cleaning, make sure that no water will enter the switch, control panel, door lamp and top control box. -
Page 17: Normal Phenomena
Maintenance Normal phenomena Button failure Please check the control board whether the fridge under lock mode.When under lock mode,all buttons can't work. Low voltage,the compressor can't start You should purchase pressurizer of more than 1000W when the area of the appliance installation,that's better to protect your fridge. -
Page 18: Trouble Shooting
Maintenance Trouble shooting... -
Page 19: Warning
Warning △ CAUTION This appliance can be used by children aged from 8 years and above and persons with reduced physical,sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.Children shall not play with the appliance.
