Summary of Contents for Osada PREMIUM
- Page 1 MASSAGE CHAIR MANUAL PREMIUM...
- Page 2 FUNCTIONS 1. This advanced massage chair gives you a very comfortable and soothing massage on neck , shoulder, back, arms, legs and foot with different massage techniques like kneading, tapping, pressing, knocking and shiatsu. This chair provides comfortable human-touch like massage. At the start, lay f ully back with your head on the pad so it can measure you correctly.
- Page 3 FUNCTIONS 9. The seat comes with gentle squeezing massage powered by air bags on the sides, relaxing the stressed muscle and quickly eliminates tiredness. The legrest and foot massager can be adj usted to any angle. It can be extended or retracted making it suitable for different people to use.
-
Page 5: Table Of Contents
CONTENTS Please read and follow all safety and operating instructions listed in this user manual prior to use. Basic precautions should always be used when operating an electrical appliance. ·-----------· Safety instructions ·-----------· External structure parts ....Internal structure parts ·-----------·... -
Page 6: Safety Instructions
SAFETY INSTRUCTIONS • Please read this manual carefully to make sure the installation and operation of the massage chair is correct. "Safety instructions" are provided in both warning and caution for important safety • information. Both warning and caution are important safety caution, please be more cautious . Warning Serious warning indicates caution- possible death or injury to body. - Page 7 SAFETY INSTRUCTIONS Warning • Osteoporosis patient • People with heart disease including embedded pacemaker or other medical electronic device inside the body; • For pregnant women or people with health issues like spine, bones People who are • Patients with a high fever are forbidden to use this machine. not suitable to •...
- Page 8 SAFETY INSTRUCTIONS .&, Caution To avoid sudden falling. • Pleas e operate the chair when it is flat or on leveled place • Position the chair at least 3 inches from the wall to To make sure the back lying. allow for sufficient space to recline up and down.
- Page 9 SAFETY INSTRUCTIONS • _& Caution • Don't use or store the chair in the wet environment To avoid leakage or like near the swimming pool, or bathroom. electric shock. • Keep the chair and remote control dry at all time. •...
-
Page 10: External Structure Parts
MANUAL CONTROL ■ 1. When powered on, the chair will automatically begin in a preparation • position. When powered off, the chair will go back to its original position . 2. In ON status, press it to enter quick relaxation auto program, there is relative status screen display. -
Page 11: Internal Structure Parts
INTERNAL PARTS Massage head Shoulder air bag Air bag in the arm area Air bag in the side area Air bag in the calf area Legrest air bag Foot air bag Foot roller and shiatsu... -
Page 12: Mechanical Components Diagram
MECHANICAL COMPONENTS DIAGRAM Explosion diagram www.osadaindia.com... -
Page 14: Installation
INSTALLATION I Step1. How to move the chair I 0 Slowly take the chair out of the box. With the help of another person, grab the left and right metal frame of the massage chair. Note Please place the remote on top of the chair seat in order to avoid it getting crushed when placing down the chair. - Page 15 INSTALLATION I Step7. After the assembly After the assembly, please operate the chair in this order: 0 Plug the cable line in the hole a on the power box as shown in the right picture. Hole a connect with one end of cable line.
- Page 17 INSTALLATION Step6. Put the back Set up the cushions on the backrest and connect the two parts with zipper and velcro. Remote Control Pocket Back seat cushion In order to get exact correct body test data for comfortable massage effect, when you sit on the chair, please make the bottom rim of the head pad level with your ears before zippering the said two parts.
- Page 19 INSTALLATION I Step4. How to assemble the left and right armrest 0 Unscrew the M6 screw on the seat frame with a cross screwdriver. @ While pushing down the release button on the fixed hole located in the rear section of the side panel, insert it into the short metal rod sticking out from the top section of the main chair body.
-
Page 20: The Adjustment Before Massage
THE ADJUSTMENT BEFORE MASSAGE Environment Check environment I .&_ Space size for using the chair Caution • A t.least 3 inches from wall. Don't use the chair in wet places like near the swimming pool and bath room to avoid leakage or electric shock. Don't use under the sunlight or near stove or other heating place to avoid upholstery being deteriorated . - Page 21 THE ADJUSTMENT BEFORE MASSAGE How to massage chair Adjustment before massage move ,& Before adjustment Caution • Please make sure the Don't move chair when it's working in massage head in the case of accidents or damage. seat part before sitting on the chair.
-
Page 22: Manual Control
MANUAL CONTROL Wi dth : 11 1 Inte nsi ty :1 I I Power Emergency off Q uick relaxation Auto Menu Confirm button Right Left Down Backrest u p & Legrest up legrest down Legrest up& Legrest down backrest down Zero-Gravity 17 www.osadaindia.com... - Page 24 Press "on/off" button when chair power is on, a buzzer beeps once short it. LCD screen display boot screen, after 2-3 seconds it displays the main interface and enter standby mode. Main interface show massage position, method, time, heating current massage status etc., all information will be updated timely when the chair start working.
-
Page 26: Operation Instruction & Function Illustration
OPERATION INSTRUCTION AND FUNCTION ILLUSTRATION ON/OFF ■ Step 1. Power on 0 Put one end plug of power line into "a" hole. @ Please make sure the controller cord to be inserted into hole "b". 8 Put power plug to socket. Turn on the power switch which is on the power box, massage chair is powered. - Page 27 Press this button on controller, ..._ Legrest can extend or � \_ legrest goes up. Release the retract within a range button, legrest stops moving, of 12 inches. the angle is locked in � this position. � Press this button on controller, Legrest goes down.
-
Page 28: After Massage
AFTER MASSAGE Restoration of massage chair 0 Make sure there are no people or pet or 0 Switch off the power. anything within the range of backrest and legrest. 8 Restore backrest and le g rest to the normal position by controller.(or press 0 Unplug the electricity from the socket. -
Page 29: Clean And Maintenance
CLEAN AND MAINTENANCE Synthetic leather I Plastic parts I General cleaning Dip cloth into neutral detergent, Clean with tidy, soft and dry cloth slightly. squeeze it and clean. � Wipe with water-dipped but (Chemical or medical cleaning squeezed cloth. products are forbidden) 8 Let it dry fully before using it. -
Page 30: Malfunction Guide
MALFUNCTION GUIDE FAQ and troubleshooting Trouble Possible reasons Troubleshooting Check if the control is on or not. Open control switch Have not selected massage function Choose massage function Make sure plug and socket are Check whether the plug and socket are making poor contact. -
Page 31: Technical Data
Armrest:39.68 l b / 61.73 l b I n put vol t age AC 220V, 60Hz Main body 51.18x29.33x49.41 inch Packing size Armrest Safety design Cl a ss 1 44.49x 16.54x 33.86 inch OSADA CHAIR PRODUCT WARRANTY REGISTRATION https://www.osadaindia.com/services/ >I ----... - Page 32 Premium Developed and Distributed by Osada India Gurgaon India Email hello@osadaindia.com You must register warranty at www.osadaindia.com/services/ INSTRUCTION MANUAL Please read this user manual thoroughly prior to MODEL: Osada Premium operating the massage chair. Store this booklet for future reference.
