Tomberlin 90021-17 Installation Instructions

These instructions provide the installer with an
overall procedure for mounting the Bag Rack Kit to
the Tomberlin E-Merge E2 or E4.
Affected Models:
Tomberlin E-Merge E2 SE/LE/SS
Tomberlin E-Merge E4 LE
Legend:
Caution indicates a hazardous situation which,
if not avoided, could result in minor or
moderate injury.
NOTICE: Please read the following instructions
carefully and completely before beginning. It is
important to have an understanding of the
overall instructions as each step is completed.
Parts Required:
Prior to assembly and mounting, please verify all
parts are present.
please contact us at 844-EMERGE2 (363-7432).
Instruction #761283-01
If missing any components,
Installation Instructions
Parts Listing:
ITEM Description
Label, 6" x 4"
1*
Assembly, Frame, Bag Rack
2
Assembly, Cradle, Bag Rack
3
Bracket, Basket Holder
4
Spacer, ¾"OD x .438" ID x .800"
Long
5
6* Box, Shipping
Sweater Basket
7
Screw, ¼ - 20 x ¾" SS
8
Washer, ¼", SAE, Flat, Black
9
Fastener, PushPanel, ¼" x 11/16"
10
x 5/8"
11* Instruction Sheet (This Document)
12 Washer, M8 x 16mm, Flat, SS
13 Washer, M8, Split Lock, SS
Screw, M6 – 1.0 x 40mm, SS
14
Washer, M6 – 12mm, Flat, SS
15
Nut, M6 – 1.0 mm, Nylok, SS
16
Screw, M8 – 1.25 x 80mm, SS
17
Cap Plug, ¾" Sq., Black
18
* Item not shown in drawing
Bag Rack Kit for E-Merge
Part # 90021-17
