Summary of Contents for Xtreme Gameroom Ms Pacman Galaga Pacman
- Page 1 Xtreme Gameroom Ms Pacman Galaga Pacman 60 Classic Arcade Games in 1 Manual Page 1 of 14...
- Page 2 Xtreme Gameroom 41083 Sandalwood Cir Suite L Murrieta Ca 92562 (877) 386-9873 sales@xtremegameroom.com www.xtremegameroom.com Page 2 of 14...
- Page 3 Table of Contents Set Up Operation Sound Adjustment Test Menu Clear High Scores Free Play/Coin Play Game Settings Dip Switch Settings Pinout Maintenance Parts Page 3 of 14...
- Page 4 Game Setup 1. Remove the machine from the box. 2. Remove all packaging material (Do not use a knife this may cause damage to the machine.) 3. Place the machine in the desired location in your home or business. Do not place in direct sunlight.
- Page 5 Operation Coin Play 1. Insert coins. 2. Use joystick to select the game you want to play. 3. Press player 1 Start for a 1 player game or player 2 start for 2 player game. Non-Coin Game Play 1. Press a Player 1 or Player 2 Start button. 2.
- Page 6 Sound Adjustment 1. Place the machine into Test mode. 2. Press the test button in to change screen “See Fig Below”. 3. Volume Adjustment is the last screen so you will need to press the button approximately 60 times. 4. Once in the Volume adjustment screen, use the joystick to adjust the volume up/down. 5.
- Page 7 Test Mode Enter test mode to make adjustments to the programing, volume control, or test the controls. All adjustments are made from the player 1 side of the machine. The player where the start buttons are located is player 1. 1.
- Page 8 9. Press the test button again and the screen changes to the Main programing screen “See Fig Below”. 10. To make changes to the settings Move the joystick Right/Left to the desired settings. Press the button next to the joystick to turn on/off the setting. See Chart Below for Settings.
- Page 9 Dip SW 1 1 coin 1 Credit 1 coin 2 Credit 1 coin 3 Credit 1 coin 4 Credit 2 coin 1 Credit 2 coin 2 Credit 2 coin 3 Credit 2 coin 4 Credit Coin 2 3 coin 1 Credit 3 coin 2 Credit 3 coin 3 Credit 3 coin 4 Credit...
- Page 10 Dip Switches On the Main Computer there is a bank of dip switches. Settings below Dip SW3 Normal Screen Flip Graphics Mode High Score Disabled Saver Enabled System Normal Mode Test Mode Page 10 of 14...
- Page 11 Jamma Pinout Parts Side Solder Side Ground/Common Ground/Common Ground/Common Ground/Common +5 VDC +5 VDC +5 VDC +5 VDC Not Used Not Used +12 VDC +12 VDC Coin Meter 1 Coin Meter 2 Speaker + Speaker - Video Red Video Green Video Blue Video Synk Video Ground...
- Page 12 Maintenance 1. If you need to open the machine for Maintenance you will need to open the top. To do so follow the instruction below. 2. Turn off the machine. 3. Open the coin door. 4. Find with your hands the 2 clamps located inside the machine in the upper right and left side of the machine.
- Page 13 For Parts check our web site www.xtremegameroom.com Parts List Item Part # Picture Glass Top ct-100 Ms Pacman underlay ct-101 Pacman underlay ct-102 Galaga underlay ct-103 Monitor vinyl ct-104 Class Clips ct-105 1” T-Molding ct-106 ¾” T-Molding ct-107 2 Slot Coin Door ct-108 Home Door ct-109...
- Page 14 Cabinet Clamps ct-120 Coin box ct-121 Test Switch ct-122 Cabinet Harness ct-123 Trackball Harness ct-124 Power Supply ct-125 Main Computer ct-126 Power Cord ct-127 LCD Monitor ct-128 Speaker ct-129 Page 14 of 14...
