b y v a l c o b a b y
CO-RIDER
Assembly Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VEEBEE CO-RIDER and is the answer not in the manual?

Questions and answers

Summary of Contents for VALCOBABY VEEBEE CO-RIDER

  • Page 1 b y v a l c o b a b y CO-RIDER Assembly Instructions...
  • Page 2 VISUAL PARTS Q’TY VISUAL PARTS Q’TY G. M4 Screw A. Chassis (with M6 screw & nut) H. M6 Screw B. Seat I. M6 Nut J. Multi tool C. Connector K. Open ended D. Steering wheel wrench (with M6 screw & nut) E.
  • Page 3 UNFOLDING THE CO-RIDER STEP 1 1.1 Press button (1) and lift the handle up till it is fully extended. 1.2 Pull the two sections in opposite directions until you hear the centre shaft click into the locked position. MUD GUARD INSTALLATION STEP 2 Attaching the Mud Guard Installed Mud Guard...
  • Page 4 REAR WHEEL : INSTALLATION/REMOVAL STEP 3 For easy installation/removal, - lift Pin (P) - push wheel inside/pull wheel outside - release Pin (P) SEAT ASSEMBLY STEP 4 Insert the seat into the seat post. Fasten it with the M6 Screw(H) and M6 Nut(I).
  • Page 5 STEP 6 CONNECTING CO-RIDER TO THE BABY CARRIAGE 6.1 Wrap the Flexible strap of the Connector (C) around the stroller frame tubing (1). Insert it through the plastic slot (2). 6.2 Turn the knob (3) till it is secure. 6.3 Press the button (5) to release hook (4).
  • Page 6 DISCONNECTING THE CO-RIDER Press button (5) and pull hook to release. Disengage the hook from the ring to separate your Co-Rider from the frame. (Leave the connector attached to the frame for future easy connection and access) Press the lower button (1) and push the front wheel downwards. Press the main upper button (2) and push the handle down.
  • Page 7 SAFETY INSTRUCTIONS • Do not use the Co-rider until your child can sit independently and without assistance. Children must only be allowed to use this product in a seated position. • The Co-rider connector is meant to be connected on the frame at the rear side of the pram.
  • Page 8 For more accessories and further information visit www.veebee.com.au b y v a l c o b a b y...
