Page 1 Rack Mounting Guide Table of Contents Overview Front Panel LED Indicators Rail Installation Rail Package Installing inner slides Installing outer slides Installing slide assemblies to the Rack Chassis installation Removing Chassis from the rack https://www.idrive.com/bare-metal-recovery/...
Page 2 3. Attach the slide to the chassis with two M4 flat head screws and repeat the steps from 1 to 3 to install the left inner slide to the left side of the chassis. https://www.idrive.com/bare-metal-recovery/...
Page 3 Slide assemblies (-outer slides with long & short brackets attached) Secure the Slide M5 screws & washers assemblies to the rack with screws and washers Note: Depending on your rack structure, short brackets might not be required to attach to the outer slide. https://www.idrive.com/bare-metal-recovery/...
Page 4 Removing Chassis from the rack Release the locking clips that are circled on the rails to remove the chassis from the rack, as shown in the figure below. Hooks M4 Screw Square Hole s M4 Screw https://www.idrive.com/bare-metal-recovery/...
