All Things Cedar PS48U Manual

Tools Needed: #2 Philips or Robertson screwdriver, wood glue and a ½ wrench.

Package Contents:

(A) Arms...2
(B) Arm Supports...2
(C) Back Posts...3
(D) Seat Supports...3
(E) Scalloped Front Rail...1
(F) Seat Slats...12
(G) Narrow Top Slat...1

Hardware

•
2 ½" screw...8
•
1 ¾" screw...45
•
Carriage bolt...2
•
Lag Screw...3
•
Eye bolt...4
•
Washer...9
•
Hex Nut...6
•
Quick Link...6
•
Chain... (4 pcs)
•
3/8" Spacer... 2

STEP 1. Build Frame

•
Attach the Front Rail (E) to the 3 Seat Supports (D)
¾ inch screws.

STEP 2. Attach Seat Slats

•
Beginning from front of seat use the 3/8 inch spacer to lay out 6 seat
slats across the seat supports and attach using 1¾ inch screws.

STEP 3. Attach Posts

•
Attach the 3 Back Posts (C) to the seat supports using lag screws
and washers.
Porch Swing
(PS48U Unassembled Kit)
using 1
