SENTRY GUARDING SYSTEM 600 GUARDING Installation Manual

Advertisement

Quick Links

This Installation Manual is provided as an assembly guide for the Sentry Guarding System. Refer to the
Design Guide for recommended layouts for various job site conditions. The product may be unstable
during installation until fully assembled. Proper safety measures must be taken at all times. Product may
fail and void warranty if installation does not comply with standards, design guide and drawings.
Sentry Guarding System has been designed and tested to comply with:
AS/NZS 4024.3610 - Safety of Machinery - Conveyors.
Equipment Required:
Tools
• 17mm ring spanner
• Riveter Blindnut Kit (M10)
• Rivet Gun
• 6mm Hex Key
POST ASSEMbLY
Step 1
Install M10 Rivet nut using Blindnut Riveter.
Step 2
Tighten mild steel shoulder bolt M10 x 12 x 50LG /
Stainless Steel shoulder bolt (Part No: SGS10-12-50SS)
to 44.7Nm using hex key.
Note: Mild Steel shoulder bolt should be hot dip
galvanised in place with post.
GUARDING ASSEMbLY
b
A
Step 1
Step 2
Engage all bracket hooks
Insert all four mesh
onto wire mesh B and
locking tabs into allocated
swing bracket to align
slots.
with the side of the mesh
panel.
AS/NZS
STRENGTH
EASY
4024.3610
TESTED
INSTALLATION
Personal Protective Equipment
• Safety Glasses
• Protective Gloves
• Safety Footware
Step 3
Secure mesh locking tabs
using 6.4 stainless steel
rivets (Ø4.8mm, 6.4mm
grip).
MODULAR
COST SAVING
SYSTEM
UP TO 30%
GUARDING SYSTEM
INSTALLATION MANUAL
600, 900, 1200 GUARDING
Safety & General
Information
Post Configurations:
Single layout
90° layout
Step 4
Step 5
Slide top tab of latch
Screw M10 bolt with
assembly between wire
spring washer, half way
mesh and bracket.
into latch assembly.
Locate front washer on
front face and secure with
6.4 stainless steel rivets.
A PRODUCT OF
Patented Design
180° layout
T - layout
