Malibu - 2 Drawer 3 Door Robe
Assembly Instructions -
Dimensions
Width - 110cm
Depth - 49.5cm
Height - 181cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
257/6109
238/5792
249/4298
257/7861
268/8554
248/7803
MADE IN
BRITAIN
Issue 4 - 03/09/14
Advertisement
Summary of Contents for Argo Malibu 257/6109
- Page 1 Malibu - 2 Drawer 3 Door Robe Assembly Instructions - 257/6109 Please keep for future reference 238/5792 249/4298 257/7861 268/8554 248/7803 Dimensions Width - 110cm Depth - 49.5cm MADE IN Height - 181cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 4 - 03/09/14...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 76kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Shelf (D2843A) (339 x 476mm) Back Rail (D2847A) (716 x 92mm) Left Side Right Side Upright...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Tools required Eye protection (when using a Rule Spirit Cross-head hammer or drill) level screwdriver Electric drill (only use when drilling Step Square Scissors...
- Page 6 Assembly Instructions Step 3 Note: The locking nuts can be on either surface of the drawer sides. Make sure that the small groove is on the inside, as shown. Attach the drawer sides to the drawer fronts Push the left drawer sides and right drawer sides onto the back of the drawer fronts...
- Page 7 Assembly Instructions Step 6 Attach the handles Attach 2 handles each of the drawer fronts using screws Note: Do not overtighten the screw. Step 7 Fit the wedgefixes Turn the drawer assemblies over and slide 4 wedgefixes into the front and back grooves, as shown, and tighten up the screws.
- Page 8 Assembly Instructions Step 9 Prepare the upright Push a rail holder into the upright Make sure that it is fitted straight, in line with the panel edges and then secure with screw Finished Place 2 runners front edge the upright as shown.
- Page 9 Assembly Instructions Step 11 Prepare the top and base Tap 2 wooden dowels into the top and the Finished base front edge Finished front edge Step 12 Fit the top and base to the upright One at a time, push the and base onto the upright secure each one with...
- Page 10 Assembly Instructions Step 13 Prepare the right side Fit 3 hinge plates onto the right side , making sure that the slot is facing towards the Finished finished front edge. front edge Step 14 Fit the right side Push the right side onto the assembly and secure it with 4 screws...
- Page 11 Assembly Instructions Step 16 Prepare the left side Place 2 runners the left side Finished shown. Slide back the front edge top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into...
- Page 12 Assembly Instructions Step 18 Fit the left side Push the left side onto the assembly and secure it with 8 screws Finished front edge Step 19 Fit the back panels The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that...
- Page 13 Assembly Instructions Step 20 Secure the backs and fit the 4 plastinails Tap the nail screws through the back holders Note: These can and down between also be round the backs into the back edge of the divider. Keep tapping the nail screws until the back holders...
- Page 14 Assembly Instructions Step 22 Fit the drawers Starting with the bottom drawer, slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer wrap with the 2nd 'threaded' holes in the runners Working from the inside of the drawer, insert 2 screws...
- Page 15 Assembly Instructions Step 24 IMPORTANT Carefully choose which hole you need Drill a handle hole in to drill in each of the 2 small doors each small door Important: Please follow these instructions ONLY drill this hole carefully. in 1 small door Lay the 2 small doors down onto a smooth surface.
- Page 16 Assembly Instructions Step 25 Fit doors and handles Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 17 Assembly Instructions Step 26 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 18 Assembly Instructions Step 27 Attach bracket to top To prevent possible overbalancing, we recommend that this unit is secured to a suitable wall by use of the bracket fitted to the top of the unit. Fixings are not supplied, as they will need to suit Top of Unit the wall type and the length of screw will...
- Page 20 ALR3024...
