Tritech Seanet Series Manual Supplement

Sonar aux mdl gyro
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Seanet System
Sonar Aux MDL Gyro
Supplement
The electronic version of this document is the controlled copy.
Therefore all printed versions of this document are uncontrolled.
Supplied by
Issue 2
TIL – Eng – Spec – 064
Seanet System - Sonar Aux MDL Gyro

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Seanet Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tritech Seanet Series

Summary of Contents for Tritech Seanet Series

  • Page 1 Seanet System Sonar Aux MDL Gyro Supplement The electronic version of this document is the controlled copy. Therefore all printed versions of this document are uncontrolled. Supplied by Issue 2 TIL – Eng – Spec – 064 Seanet System - Sonar Aux MDL Gyro...
  • Page 2 COPYRIGHT © Tritech International Ltd The copyright in this document is the property of Tritech International Limited. The document is supplied by Tritech International Limited on the understanding that it may not be copied, used, or disclosed to others except as authorised in writing by Tritech International Limited.

  • Page 3: Table Of Contents

    Tritech International Ltd Seanet System- Sonar Aux MDL Gyro Table of Contents Handling of Electrostatic-Sensitive Devices ............5 Safety Statements ....................7 Technical Support ....................7 INTRODUCTION...................... 8 CONFIGURING SEAKING COMMS BOARD FOR AUX SERIAL I/O ....9 OPTON1: ARCNET SONAR WITH RS-485 AUX PORT ........11 OPTON2: RS-232 SONAR WITH RS-485 AUX PORT ........

  • Page 4: Handling Of Electrostatic-Sensitive Devices

    Tritech International Ltd Seanet System- Sonar Aux MDL Gyro Handling of Electrostatic-Sensitive Devices Attention Observe Precautions for handling Electrostatic Devices Caution Handling of Electrostatic-Sensitive Devices Certain semiconductor devices used in the equipment are liable to damage due to static voltages.
  • Page 5 Seanet System- Sonar Aux MDL Gyro Warranty Statement Tritech International Limited herein after referred to as TIL TIL warrants that at the time of shipment all products shall be free from defects in material and workmanship and suitable for the purpose specified in the product literature.

  • Page 6: Safety Statements

    The name of the organisation which purchased this system is held on record at Tritech International Ltd. Details of new software and hardware packages will be announced at regular intervals.

  • Page 7: Introduction

    Chassis Ground ‘AUX’ Port Face View N.B. +VDC Supply (Pin 3) = ‘Main’ Port Input (Pin3) The standard mating connector for the Aux Port is a Tritech 6-pin. Issue 2 TIL – Eng – Spec – 064 Page 8 of 15...

  • Page 8: Configuring Seaking Comms Board For Aux Serial I/O

    Tritech International Ltd Seanet System- Sonar Aux MDL Gyro CONFIGURING SEAKING COMMS BOARD FOR AUX SERIAL I/O 1. Before opening the Sonar head to access the Comms board jumpers, using the 'Seanet Setup' utility program configure the following check box settings. These are needed to enable the 'Aux' port;...
  • Page 9 Tritech International Ltd Seanet System- Sonar Aux MDL Gyro From here press the Baud Rates Button... …Check Baud rates on Async 1 (AUX) match the device output (default Digiquartz output is 9600 baud). 2. Now change the jumper settings on the Comms board inside the Head. In the SeaKing head, this must be a COMDV3/FV3, COMGV3/V5 or a COMV5 Mod-A board.

  • Page 10: Opton1: Arcnet Sonar With Rs-485 Aux Port

    Tritech International Ltd Seanet System- Sonar Aux MDL Gyro OPTON1: ARCNET SONAR WITH RS-485 AUX PORT CONNECTION DIAGRAM I) COMD(F)V3 SONAR PCB Power and Power and ArcNet RS-485 Comm's Comm's COMM'S SURFACE MAIN [Pin5 Altimeter Analogue link through] 232 ON/OFF...

  • Page 11: Opton2: Rs-232 Sonar With Rs-485 Aux Port

    Tritech International Ltd Seanet System- Sonar Aux MDL Gyro OPTON2: RS-232 SONAR WITH RS-485 AUX PORT CONNECTION DIAGRAM I) COMD(F)V3 SONAR PCB Power and Power and RS232 RS-485 Comm's Comm's COMM'S SURFACE MAIN [Pin5 Altimeter Analogue link through] 232 ON/OFF...

  • Page 12: Opton3: Arcnet Sonar With Rs-232 Aux Port

    Tritech International Ltd Seanet System- Sonar Aux MDL Gyro OPTON3: ARCNET SONAR WITH RS-232 AUX PORT CONNECTION DIAGRAM I) COMD(F)V3 SONAR PCB Power and Power and ARCNET RS-232 Comm's Comm's COMM'S SURFACE MAIN 232 ON/OFF II) COMGV3 / COMV5 III) COMV5 Mod A...

  • Page 13: Opton4: Rs-232 Sonar With Rs-232 Aux Port

    Tritech International Ltd Seanet System- Sonar Aux MDL Gyro OPTON4: RS-232 SONAR WITH RS-232 AUX PORT CONNECTION DIAGRAM I) COMD(F)V3 SONAR PCB Power and Power and RS-232 RS-232 Comm's Comm's COMM'S SURFACE MAIN 232 ON/OFF II) COMGV3 / COMV5 III) COMV5 Mod A...

  • Page 14: Software Settings

    Tritech International Ltd Seanet System- Sonar Aux MDL Gyro SOFTWARE SETTINGS Once the Sonar head has been correctly configured with the Gyro connected, power up the system and run the main SeaNet application software. N.B. Ensure that the SeaNet Setup program is closed down first.
