FD smart Instructions Manual

Electric car
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DUAL-DRIVE POWER
REAL WORKING DOORS
COLOURFUL LIGHTS
ELECTRIC CAR INSTRUCTIONS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the smart and is the answer not in the manual?

Questions and answers

Summary of Contents for FD smart

  • Page 1 DUAL-DRIVE POWER REAL WORKING DOORS COLOURFUL LIGHTS ELECTRIC CAR INSTRUCTIONS...

  • Page 2: Specifications

    CONTENTS 1.SPECIFICATIONS 2.PARTS LIST 3.DECOMPOSITION CHART 4.ASSEMBLE STEPS 5.CHARGING 6.USAGE METHOD 9 ~ 11 7.REMOTE CONTROL INSTRUCTION 12~13 8.FAILURE ANALYSIS 9.MAINTENANCE AND REPAIR 10.MAINTENANCE RECORDS SPECIFICATIONS Thank you for purchase products, is always pursuit of excellence, design and produce comfort & safe children riding toys continually, accompany your children's happy &...
  • Page 3 PAETS LIST Car body*1 Windshield*1 Steering wheel*1 Rear wing*1 Left support of rear wing*1 Right support of rear wing*1 Wheel*4 Wheel cover*4 Seat*1 M5 Cap nut*1...
  • Page 4 PAETS LIST washer*2( Double-motors version ) M5*35mm Machine screw*1 washer*3(single-motor version） Screw 4*12mm 8mm*2 Charger*1 (used to lock the seat) Remote control *1...

  • Page 6: Assemble Steps

    ASSEMBLE STEPS Assembling of car must be operated by adult. Choking hazard-small parts.not allow children to touch and play! Please check the quantity of all parts before assembling. Please keep the PP bag carefully.choking hazard,prohibit children to play it! Tools of assembling: screwdriver,scissors(not included) 1 .Assemble wheels: ①Place the car upside down on a flat surface.
  • Page 7 M5×35mm Machine screw*1 M5 Cap nut*1 ③Remove the rubber cover of the ④Insert the windshield into place of the steering rod end, connect the steering car body and press down until a "snap” wheel terminal to the terminal of the car is heard.
  • Page 8 CHARGE Safety Warning of Battery •Charger, accumulator and dry battery are not toys, prohibit children to play. •Rechargeable battery must be charged by guardian. •Battery must be placed in right polarity. •Please take out battery if do not use for long time. •Power terminals can not short circuit.
  • Page 9 Special prompt! •Suggest charging for 4-6 hours before the first time using, but do not exceed 10 hours. •While the car running speed obviously slowdowns, it means the power of accumulator is low, please charge in time. •It is the best to charge 8-12 hours after using, but do not exceed 16 hours.

  • Page 10: Usage Method

    USAGE METHOD WARNING! To prevent accidents: •This product can only be assembled by adult. Small parts may be bring danger, children are prohibited to touch or play them! •Children may be hurt by sharp edges and points of parts, prohibit children to join assembling.
  • Page 11 •Ensure your children ride this product in safe environment, such as in house、 garden or playground. •Be careful that this product only suit for hard and flat place, for ensure safety, it is prohibited to ride in unsafe environments below: a.Gutter rive、grassplot、step、incline or rugged ground、flooded road.
  • Page 12 FUNCTION DIAGRAM Warning!To avoid damaging the gear box and motor,please ensure the car is completely stopped before change gear. Memory card slot Power button USB port Music Mode Horn button Pedal Music buttons Horn button Rocking mode/Sport mode switch and Light switch (This function is only for high Forward Gear switch...

  • Page 13: Remote Control Instructions

    REMOTE CONTROL INSTRUCTIONS Only guardian can use the remote controller, not allow children to touch it. Brake Lights Radio indicator Forward/ Turn left/Turn right Backward Frequency UM-3“AA”1.5V Speed UM-3“AA”1.5V Battery cover The controller use 2 x AA battery (not included). 1.Loosen the screw on battery cover by cross screwdriver, and open the battery cover.
  • Page 14 Safety Warning of Usage 1.When use remote control function, the distance from adult to the car can not exceed 10 meters. 2.Only the guardian can use the remote controller, not allow children to touch or use it. 3.Please read the instructions before use remote control, and take empty testing.

  • Page 15: Failure Analysis

    FAILURE ANALYSIS Problem: The car can not run Reason: The accumulator plug-in unit or wire loose and drop. Ensure the accumulator plug-in unit has connected correctly, wire does not loose. Reason: The accumulator is broken. Please contact agent or manufacturer. Reason: The circuit is damaged.

  • Page 16: Maintenance And Repair

    MAINTENANCE AND REPAIR •Before playing, patents must check whether the main parts are in good condition, whether the accumulator,charger,wire,male plug,outer shell and other parts are damaged; whether the screws are loosen; is their any hidden danger? Stop using if any damage is found, until completely repaired.

  • Page 17: Maintenance Records

    MAINTENANCE RECORDS Purchase Remarks date Customer Name: Tel: Address: Purchase time: Invoice NO: Date:...
  • Page 18 Supervised by Guangdong Fengyuan Toys Industry & Commerce Co., Ltd Manufacturer: Fengda Toys Industry & Commerce Co., Ltd Address: Development Avenue, Economic Development Zone, Hubei Province Website: https://www.fdtoys.cn Customer Service Hotline: 400-8754-388...
