RIGID DOCK SHELTER
S-900DD DRYDOCK
RAIN SEAL SYSTEM
SERCO STEEL
Installation Instructions
S-420
W/ INTEGRATED
GALVANIZED STEEL FRAMING
4Front Engineered Solutions, Inc.
W183 S8253 Racine Avenue
Muskego, WI 53150
Tel: (262) 679-6200
Fax: (262) 679-6210
FORM NO:
PART NUMBER: T31645
Do not install this product unless you read and
understand the Warnings and Installation
Instructions contained in this manual. Failure to
do so could result in serious injury or death.
®
4F-420-DD-INT-9/16
Advertisement
Table of Contents
Summary of Contents for Serco S-420
- Page 1 4Front Engineered Solutions, Inc. W183 S8253 Racine Avenue Muskego, WI 53150 Tel: (262) 679-6200 Fax: (262) 679-6210 S-420 RIGID DOCK SHELTER W/ INTEGRATED S-900DD DRYDOCK ® RAIN SEAL SYSTEM SERCO STEEL GALVANIZED STEEL FRAMING Installation Instructions FORM NO: 4F-420-DD-INT-9/16 PART NUMBER: T31645...
- Page 2 SERCO S-420 RIGID FRAME DOCK SHELTER W/ INTEGRATED S-900DD DRYDOCK RAIN SEAL SYSTEM Serco S-420 Rigid Dock Shelters with the integrated S-900DD® Rain Seal System are custom built for each application. Installation procedures are the same for all S-420/ S-900DD Dock Shelters regardless of size.
- Page 3 ! IMPORTANT ! IF BUILDING WALL SURFACE IS IRREGULAR, DAMAGE TO SIDE AND HEAD FRAME COVER MATERIAL CAN OCCUR AS ANCHORING FASTENERS ARE TIGHTENED. USE SHIMS AS REQUIRED TO COMPENSATE FOR IRREGULARITIES. TIGHTEN FRAME TO WALL CAREFULLY. 4. Attach side frames to steel supports using ¼” bolt, spinlock nut and 1-½” fender washers (provided) through pre-punched hole in top of steel support.
- Page 4 6. Attach wiper seal head frame mounting angles to truck shelter head frame. Position mounting angles as shown with long leg of angle against ends of head frame. Fasten #10-16 x ¾” TEK screws through holes in long leg of head frame bracket into side of head frame. These screws will be removed and re-installed through side cover fabric later in the installation process.
- Page 5 9. Attach foam wiper pad to wiper seal head frame stop plate. Position back of wiper seal head frame on the ground and secure from tipping over. Mark a reference line on the front of the stop plate that extends between the top corners of head frame.
- Page 6 10. Connect wiper seal head frame to truck shelter head frame. Remove banding from bottom of wiper seal head frame. Loosen TEK screws closest to the ends of the head curtain mounting angle to provide clearance for the wiper seal mounting angle. Slide wiper seal head frame onto mounting angles. Fasten to shelter head frame using (6) TEK screws in a minimum of three (3) areas (center and approx.
- Page 7 15. Attach draft pads. Bottom of pad should be level with dock floor. Attach to inside of side frame with aluminum angle over fabric flap using TEK screws in two locations. Insure snug fit of draft pad to frame. 16. Caulk shelter head and side members at wall around the outside edges. Caulk between truck shelter and wiper seal head frames and across front of wiper seal head frame behind stop plate.
- Page 8 EXPRESS OR IMPLIED, WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF, AND THERE IS NO WARRANTY OF MERCHANTABILITY OR OF FITNESS FOR A PARTICULAR PURPOSE. DryDock, Serco, SnapBack, Ultra Dock Shelter, Ultra Seal, and WeatherAll are registered trademarks of 4Front Engineered Solutions, Inc. Serco Steel is a trademark of 4Front Engineered Solutions, Inc.
