Summary of Contents for Snowbear 324-128
- Page 1 324-128 Drop Kit Installation Instruction ® P a g e SnowBear Drop Kit Installation - 324-128...
- Page 2 Assembly tool list Ratcheting Wrench 3/4" Socket (x2) OR 3/4"Open Ended/Box Wrench (x2) ® P a g e SnowBear Drop Kit Installation - 324-128...
- Page 3 Instruction INSTALLATION: The SnowBear® Drop Kit is designed to quickly and easily install on your SnowBear® SP115 Plow Assembly. If installed on your vehicle, the plow assembly does not need to be removed. The 2" Hitch Receiver weldment can remain while the installation is performed.
- Page 4 This will allow the Winch Arms to disengage the Lower A-Frame Weldment pins. A-Frame Weldment is free to drop. Winch Motor Assembly Bracket 1/2"-13 Hex Bolts & Nuts Lower A-Frame Weldment ® P a g e SnowBear Drop Kit Installation - 324-128...
- Page 5 Winch Arm & Receiver Weldment Right Step 4: Install A-Frame Weldment into one of the two lower holes on the Drop Kit Plate on the side installed. Drop Kit Plate Holes ® P a g e SnowBear Drop Kit Installation - 324-128...
- Page 6 Hardware Kit) and tighten completely. Tighten all hardware at the Winch Motor Assembly. Winch Arm & Winch Motor Assy Hardware 1/2"-13 x 2" Hex Bolts & Nuts Drop Kit Plate Drop Kit is installed and ready for use. ® P a g e SnowBear Drop Kit Installation - 324-128...
