TP-Link WR820N(EU) Quick Installation Manual

Quick Installation Guide
300Mbps Wi-Fi Router
*Images may differ from actual products.
If your internet connection is through an Ethernet
cable directly from the wall, instead of through a
modem, connect the Ethernet cable to the router's
WAN port, and skip steps 1, 2, and 3.
Configure the router
1. Connect your computer to the router (Wired or Wireless)
Wired
Turn off the Wi-Fi on your computer and connect it to the router
via an Ethernet cable.
Wireless
Connect your device to
the router's Wi-Fi using
the SSID (network name)
and Wireless Password
printed on the label at
the bottom of the router.
Power adapter
Connect the
power adapter
to the router.
Verify that the
continuing with the configuration.
2. Launch a web browser, and enter http://tplinkwifi.net or
http://192.168.0.1 in the address bar. Create a password
to log in.
Note: If the login window does not appear, please refer to FAQ > Q1.
Wireless Password/PIN:XXXXXXXX
SSID:TP-Link_XXXX
Router
LED turns solid on before
http://tplinkwifi.net
New Password:
Confirm Password:
Let's Get Started
Important
Power off the modem, and
remove the backup battery if it
has one.
Turn on the modem and then wait
about 2 minutes for it to restart.
Modem
Connect the powered-off modem to the
router's WAN port via an Ethernet cable.
3. Follow the step-by-step instructions to set up the internet connection.
Note: If you are not sure of the Connection Type, please click AUTO DETECT or contact
your ISP (Internet Service Provider) for help.
Tether App
The TP-Link Tether app provides a simple, intuitive way to
access and manage your router. Scan the QR code to
download Tether from the Apple App Store or Google Play.
Flip the page over to know more.
