JYEBAO SMA3200PA-0085/4*f Manual

SMA3200PA-0085/4*f
Typical VSWR
Part Number
SMA3200PA-0085/4*f
Typical PHASE (DEGREES)
Part Number
SMA3200PA-0085/4*f
Parts
Retainer Ring Beryllium Copper
Gasket
Hex Nut
Insulator
Collet Body Beryllium Copper
Adjustment Nut
Contact Pin Beryllium Copper
Body
Solder Barrel
Coupling Nut
Weight:
Suitable Cables:
This part number complies with RoHS.
Notice: JYEBAO reserves the right to make modifications deemed appropriate.
SMA Plug Phase Adjustable
30.3
(1.193)
1~4Ghz 5~11Ghz 12~18Ghz
1.1 1.15
1Ghz 2Ghz
4º 8º
10Ghz 11Ghz 12Ghz
40º 44º
Material
Tin-Zinc-Copper-Alloy 100 Over Copper 50
Silicon
Brass Tin-Zinc-Copper-Alloy 100 Over Copper 50
Teflon
Gold 4 Over Nickel-Phosphorous Alloy 80 Over Copper 20
Brass Tin-Zinc-Copper-Alloy 100 Over Copper 50
Gold 4 Over Nickel-Phosphorous Alloy 80 Over Copper 20
Brass Tin-Zinc-Copper-Alloy 100 Over Copper 50
Brass Tin-Zinc-Copper-Alloy 100 Over Copper 50
Brass Tin-Zinc-Copper-Alloy 100 Over Copper 50
2.35
3Ghz 4Ghz 5Ghz 6Ghz
12º 16º 20º 24º
13Ghz 14Ghz 15Ghz
48º 52º 56º 60º
Plating (Micro-inch)
50Ω
7Ghz 8Ghz 9Ghz
28º 32º 36º
16Ghz 17Ghz 18Ghz
64º 68º 72º
