- Page 1 Idea3399 Reference User Manual V2.201911 Boardcon Embedded Design www.boardcon.com...
- Page 2 1.3. Limited Warranty Boardcon warrants this product to be free of defects in material and workmanship for a period of one year from date of buy. During this warranty period Boardcon will repair or replace the defective unit in accordance with the following process: A copy of the original invoice must be included when returning the defective unit to Boardcon.
-
Page 3: Table Of Contents
Your Idea Customize the embedded system based on Content 1 Idea3399 Introduction ........................3 1.1 Summary ..........................3 1.2 Rockchip RK3399 Features ....................3 1.3 Idea3399 Specifications ....................... 5 1.4 PCB Dimension ........................7 1.5 Block Diagram ........................7 1.6 Power meter ......................... 8 1.7 CPU Introduction ........................ -
Page 4: Idea3399 Introduction
RAM, 8GB eMMC, an mPCIe slot for cellular connectivity, and other interactive interfaces geared towards to AI and IoT Applications. Display features include a mDP port, HDMI and MIPI LCD. Idea3399 adopts ALC5651 dual I2S interface audio codec that supports analog/digital input. The 2x USB3.0 Type C can be converted to HDMI/USB3.0/USB2.0. - Page 5 Your Idea Customize the embedded system based on - Arm Mali-T860MP4 GPU up to 4K supply. - High performance OpenGL ES1.1/2.0/3.0, OpenCL1.2, DirectX11.1 etc. - Provide MMU and L2 Cache with 256KB size Power unit • - RK818 on board. - Compatible with multiple mode power supply.
-
Page 6: Idea3399 Specifications
Your Idea Customize the embedded system based on 1.3 Idea3399 Specifications Headphone Gigabit Type-C0 Ethernet Host Type-C1 Power in HDMI Mini DP PWR&Battery MIPI_RX Camera, optional Debug WiFi&BT MIPI_TX/RX UART1/SPI0 Camera,optional WiFi antenna Reset MIPI Power AI-Audio IR Recover UART3... - Page 7 Your Idea Customize the embedded system based on · Supports AFBC (ARM Frame Buffer Compression) Memory 4GB LPDDR4 iNAND 8GB eMMC Power DC 5V/3A or 3.7V Li-Battery Ethernet 1000M High performance Ethernet (RTL8211E), RJ45 interface MINI DP 1x mini Display Port 1x USB2.0 Host, 2x USB3.0 Type C HDMI HDMI 1.4 and 2.0, support 4K, 1080P, 720P, 480P resolution...
-
Page 8: Pcb Dimension
Your Idea Customize the embedded system based on 1.4 PCB Dimension 1.5 Block Diagram Socket AI Unit MEMS Camera 1 Camera 2 3G/4G MIPI LCD Download TYPE C 1 TYPE C 0 MIC Array 3850 O 13850 13MP 13MP mPCI-E Socket RX/T USB 2.0 TYPE C 1... -
Page 9: Power Meter
Your Idea Customize the embedded system based on 1.6 Power meter Operation Electric Power Temperature Connected devices current °C 5V power Power, 10.1-inch MIPI panel Power, SD card, play 4K video, U-disk, USB Mouse, debug serial, Ethernet, 10.1-inch MIPI panel, headphone, 5V@3A Android7.1.2 27 - 32... - Page 10 Your Idea Customize the embedded system based on Pin Definition Alternate Signal Description functions Voltage SDMMC card command output and SDMMC_CMD GPIO4_B5 3.0V response input SDMMC card detect signal SDMMC0_DET_L GPIO0_A7 1.8V (10K Pull SDMMC_D0 SDMMC card data input and output GPIO4_B0 3.0V SDMMC_D1...
- Page 11 Your Idea Customize the embedded system based on SPI1RX /RXD4 SPI1_RXD SPI serial data input 1.8V /GPIO1_A7 SPI2CS CIF_PDN0 CIF power ON/OFF 1.8V /GPIO2_B4 I2C2_SCL I2C serial clock line (Need pull GPIO2_A1 1.8V I2C2_SDA I2C data line (Need pull GPIO2_A0 1.8V SPI2TX I2C6_SCL...
- Page 12 Your Idea Customize the embedded system based on PCIE_PERST# Power reset GPIO4_D5 3.0V GPIO4_C5 3V_GPIO4_C5 GPIO 3.0V /SPDIF_TX 3V_GPIO4_D2 GPIO 3.0V GPIO4_C6/PW TOUCH_RST_L Touch screen reset 3.0V PCIE_CLKREQ 3V_GPIO4_D0 GPIO 3.0V HDMI_CEC HDMI CEC signal GPIO4_C7 3.0V 3V_GPIO4_D3 GPIO 3.0V 3V_GPIO4_D1 GPIO 3.0V...
- Page 13 Your Idea Customize the embedded system based on MIPI CSI negative differential data MIPI_TX/RX_D1N 1.8V line transceiver output MIPI CSI positive differential clock MIPI_TX/RX_CLKP 1.8V line transceiver output MIPI CSI negative differential clock MIPI_TX/RX_CLKN 1.8V line transceiver output MIPI CSI positive differential data MIPI_TX/RX_D2P 1.8V line transceiver output...
- Page 14 Your Idea Customize the embedded system based on MIPI DSI negative differential data MIPI_TX_D1N 1.8V line transceiver output MIPI DSI positive differential data MIPI_TX_D1P 1.8V line transceiver output MIPI DSI negative differential data MIPI_TX_D0N 1.8V line transceiver output MIPI DSI positive differential data MIPI_TX_D0P 1.8V line transceiver output...
- Page 15 Your Idea Customize the embedded system based on TYPEC0_TX1N Transmitter serial data - 1.8V TYPEC0_TX1P Transmitter serial data + 1.8V TYPEC0_TX2P Transmitter serial data + 1.8V TYPEC0_TX2N Transmitter serial data - 1.8V TYPEC0_DP USB 2.0 data DP 1.8V TYPEC0_DM USB 2.0 data DN 1.8V TYPEC0_RX2N Receiver serial data -...
-
Page 16: Peripherals Introduction
Your Idea Customize the embedded system based on Capacitor on eDP_TX3P eDP data lane output + 1.8V core board Capacitor on eDP_TX3N eDP data lane output - 1.8V core board Capacitor on eDP_TX2P eDP data lane output + 1.8V core board Capacitor on eDP_TX2N eDP data lane output -... -
Page 17: Audio I/O (J9, J8)
VCC_SY Main power input VDD5V DC5V 2.2 Audio I/O (J9, J8) The Idea3399 adopts Realtek ALC5651, provides stereo audio output (J9, PJ327E, 3.5mm Jack). In addition, an AI-Audio interface(J8) is also provided. Features Low power ⚫ Integrated ADC and DAC ⚫... -
Page 18: Usb Host (Usb1)
Ground ROUTP Right channel output LOUTP Left channel output 2.3 USB Host (USB1) Idea3399 provides 1x USB2.0 Host to connect USB mouse, U disk, USB camera, or other USB devices. supports hot-plug. Feature Compatible with USB Host2.0 specification ⚫ Supports high-speed (480Mbps), full-speed (12Mbps) and low-speed (1.5Mbps) mode ⚫... -
Page 19: Hdmi Out (J5)
Customize the embedded system based on 2.4 HDMI OUT (J5) Idea3399 HDMI2.0 supports maximum 4Kx2K display, and it also enables HDMI/LCD audio and video synchronization output. The HDMI interface is the regular 19pins HDMI type A, with width 13.9mm and thickness 4.45mm. - Page 20 Your Idea Customize the embedded system based on RX2+ RX2- VBUS SBU1 VBUS TX1- TX1+ VCONN TX2+ TX2- VBUS SBU2 VBUS RX1- RX1+ USB Type-C plug pinout end-on view Signal Description Signal Description Ground Ground TYPEC0_TX1P Transmit serial data + TYPEC0_TX2P Transmit serial data + TYPEC0_TX1N...
-
Page 21: Minidp (J7)
Hot plug detect differential output - Ground MDP_VCC DC 3.3V 2.7 Ethernet (JP1) Idea3399 adopts RTL8211E as the Ethernet chip. RJ45 connector (offset). Feature Supports 10/100/1000-Mbps data transfer rates with the RGMII interfaces ⚫ Supports both full-duplex and half-duplex operation ⚫... -
Page 22: Poe (J32)
Your Idea Customize the embedded system based on Signal Description Signal Description Bi-directional Bi-directional transmit/receive pair A transmit/receive pair A Bi-directional Bi-directional transmit/receive pair B transmit/receive pair C Bi-directional Bi-directional transmit/receive pair C transmit/receive pair B Bi-directional Bi-directional transmit/receive pair D transmit/receive pair D Ground Ground... -
Page 23: Uart1/Spi0, Uart3 (J13, J12)
Your Idea Customize the embedded system based on Signal Description Signal Description SPI1_CSn0 SPI chip select VDD5V DC 5V 2.10 UART1/SPI0, UART3 (J13, J12) Signal Description Signal Description VCC3V3_SYS DC 3V MDI1-_SPI0-CSn0 Chip select Transmitter serial MDI0+_UART1-TX MDI2+_SPI0-CLK Serial clock data MDI0-_UART1-RX Receiver serial data... -
Page 24: Mipi_Dsi(Con1)
MIPI DSI negative MIPI DSI positive MIPI_TX_D3N differential data line MIPI_TX_D3P differential data line transceiver output transceiver output 2.13 MIPI Camera (CON4, CON5) Idea3399 features two 26-pin MIPI connectors. Boardcon only provides driver for CON4. - Page 25 Your Idea Customize the embedded system based on 9 11 13 15 17 19 21 23 25 8 10 12 14 16 18 20 22 24 26 CON4 Signal Description Signal Description VDD5V DC 5V VDD5V DC 5V Ground Ground VCC3V3_SYS DC 3.3V VCC3V3_SYS...
-
Page 26: Debug (J4)
MIPI CSI positive MIPI_TX/RX_D3N differential data line MIPI_TX/RX_D3P differential data line transceiver output transceiver output 2.14 Debug (J4) Idea3399 provides an online debug serial port (UART2). It is used to connect PC and board with the USB-to-serial TTL232 serial cable. -
Page 27: Sim (Con2, P2)
Your Idea Customize the embedded system based on Signal Description Signal Description UART serial data UART2DBG_T UART serial data UART2DBG_RX input output Ground 2.15 4G & SIM (CON2, P2) The 4G module adopts the standard PCI Express® MiniCard form factor (MiniPCIe) and provides global network coverage on the connectivity of LTE. -
Page 28: Sata (Con3)
Your Idea Customize the embedded system based on Not connect Ground Ground Not connect Ground Not connect Not connect Not connect Not connect Ground Ground HOST1_DM Host data DN Ground HOST1_DP Host data DP 3GVCC DC 3.3V Ground 3GVCC DC 3.3V LED_RED Ground Not connect... - Page 29 Your Idea Customize the embedded system based on Ground PCIE_3V3 DC 3.3V Not connect Not connect Not connect Not connect Ground Connect to led Not connect PCIE_3V3 DC 3.3V Not connect PCIE_3V3 DC 3.3V Ground PCIE_3V3 DC 3.3V Not connect PCIE_3V3 DC 3.3V Not connect...
-
Page 30: Micro Sd (J1)
Your Idea Customize the embedded system based on Ground PCIE_3V3 DC 3.3V Ground PCIE_3V3 DC 3.3V Ground 2.17 Micro SD (J1) The Micro SD card is used as an external storage device. Support hot-plug. Signal Description Signal Description SDMMC_D2 SDMMC_D3 SD/MMC data2 SD/MMC data3 SD/MMC command... - Page 31 Your Idea Customize the embedded system based on - PCM for audio data Complies with Bluetooth Core Specification Version 4.1 with provisions for supporting ⚫ future specifications. With Bluetooth Class 1 or Class2 transmitter operation. Supports extended synchronous connections ⚫ view Signal Description...
-
Page 32: Rtc (Bt1)
The backup battery (3V) is used to ensure the RTC (frequency 32.768KHz) is still able to work after power off. Cell model: CR1220. Signal Description Signal Description VCC-RTC 3V battery Ground 2.20 Infrared Receiver(U3) Idea3399 features a small Infrared Receiver, with central frequency 38KHz. Signal Description Signal Description PWM3_IRIN IR in Ground VCC3V3_SYS DC 3.3V... -
Page 33: Product Configurations
Customize the embedded system based on 3 Product Configurations 3.1 Standard Contents Qty. Item Description (PCS) Idea3399 board Standard Content (4GB RAM, 8GB eMMC) TF Card / CD-ROM Android BSP, Documents, tools, Schematic Drawing, Datasheets Ethernet cable Serial Cable CP2102 USB Cable USB3.1 Type-C...
