Automation Technology FebriScan User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
th
April 28
, 2020
AT-Automation Technology GmbH
FebriScan
USER GUIDE
Page 1 of 49

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FebriScan and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Automation Technology FebriScan

  • Page 1 April 28 , 2020 AT-Automation Technology GmbH FebriScan USER GUIDE Page 1 of 49...

  • Page 2: Table Of Contents

    April 28 , 2020 Content GENERAL NOTES......................4 Copyright .............................. 4 Disclaimer ............................. 4 Trademarks ............................4 SAFETY INSTRUCTIONS ....................4 Symbols and Notes ..........................4 Warning Symbols and Safety Instructions ..................4 Further Symbols ............................ 5 USER INSTRUCTIONS ....................6 Installation Instruction ..........................
  • Page 3 April 28 , 2020 IrCamera..............................37 Blackbody ..............................39 SERVICE INFORMATION ..................40 Contact ............................... 40 Service and Support .......................... 40 WARRANTY CONDITIONS ..................40 Warranty Period ..........................40 1-year manufacturer's warranty on IRSX series products.............. 40 Extended Warranty ..........................40 RETURN POLICY .......................

  • Page 4: General Notes

    General Notes Copyright  AT-Automation Technology GmbH, 1998-2020. This user guide is protected by copyright and all rights are reserved. No part of this document and no part of the software shall be reproduced, distributed, edited or translated into another language or computer...

  • Page 5: Further Symbols

    April 28 , 2020 Read the operating instructions before using the system.  Make sure that the operating staff has read the operating instructions and understood the contents!  Observe the safety instructions.  Observe the locally applicable safety and accident prevention regulations.

  • Page 6: User Instructions

    April 28 , 2020 User Instructions Installation Instruction Mobile Package The Mobile Package is designed to enable you to use the system in a large variety of locations. Its compact design allows the system to be set up and dismantled quickly. The system can be easily transported in the transport case in a vehicle or shipped as required.
  • Page 7 April 28 , 2020 The first layer contains the following listed components A. Calibration certificates for camera and blackbody B. Monitor C. Sticker and sign set D. Mouse and keyboard E. Blackbody with control unit Page 7 of 49...
  • Page 8 April 28 , 2020 The second layer contains the following listed components F. Monitor stand with holder G. Micro HDMI to HDMI cable H. Power supply unit with USB-C for the embedded visualization PC Power supply unit with M12 round connector for the infrared camera J.
  • Page 9 April 28 , 2020 System Setup The system setup is divided into 4 steps. We recommend doing the installation with two persons. Step 1: Tripod Set up the two tripods and make sure that you have a secure stand. To do this, unfold the tripod legs and lock them at the central locking screw.
  • Page 10 April 28 , 2020 Wing screw Central fixing screw Page 10 of 49...
  • Page 11 April 28 , 2020 Step 3: Positioning the tripods and floor stickers Place the two tripods so that the lens of the camera and the blackbody lens are facing each other. Now determine the distances between the individual components using a suitable measuring device.
  • Page 12 April 28 , 2020 320mm Page 12 of 49...
  • Page 13 April 28 , 2020 Step 4: Establishing the cable connections and system setup Attach the control unit of the blackbody to the corresponding tripod. Use the velcro fasteners on the back to attach the component. Place the monitor, keyboard and mouse on a suitable table or pedestal near the infrared camera.
  • Page 14 April 28 , 2020 Power supply unit with USB-C connection Micro HDMI to HDMI to connect the monitor Power supply unit with Micro USB to After you have connected all cables of the system, plug all power supply units and power cables into the supplied socket strip and connect this to a supply connection.
  • Page 15 April 28 , 2020 As an alternative, you have the possibility to watch the setup and initial setup of the system in the short video provided. Page 15 of 49...

  • Page 16: Integration Package

    April 28 , 2020 Integration Package This system variant is suitable for all users who want to install a fixed installation in buildings, access areas or passageways. Due to the easy integration possibility in existing network infrastructures, you will be able to display and access the administration area and visualization of the system data at different terminals or office workstations.
  • Page 17 April 28 , 2020 System Setup The system setup is divided into 2 steps. We recommend doing the installation with 2 persons. Step 1: Blackbody and infrared camera Both components are equipped with threaded holes or mounting plates to allow safe and stable integration into existing building entrances or general passageways.
  • Page 18 April 28 , 2020 Screw connection Step 2: Positioning and floor stickers Since the cameras of all system variants are preconfigured to achieve an optimum measuring result, the distances to be maintained between the individual components are identical. Please refer to the chapter "Step 3: Positioning the tripods and floor stickers" of the mobile package for the corresponding data.

  • Page 19: Portal Package

    April 28 , 2020 Portal Package Please check for completeness by using the list provided in the scope of the delivery. Scope of delivery A. Mounting frame B. Side panel (top left) with infrared camera and user monitor C. Side panel (bottom left) with multiple socket strip D.
  • Page 20 April 28 , 2020 Calibration certificates for camera and blackbody J. Power supply unit for monitor K. Butt connector set L. Installation tool M. Monitor with holder and stand System Setup The system setup is divided into 3 steps. We recommend doing the installation with 2 or 3 persons.
  • Page 21 April 28 , 2020 Hole for fixing Positioning Step 2: Installation of the lower side panels Position the two lower side parts according to the following illustration and put on the previously installed mounting frame with the upper side parts. Insert a butt connector set at each of the mounting holes provided in the profiles and fix it with the mounting tool.
  • Page 22 April 28 , 2020 Fixing screw 1060mm Step 3: Floor stickers and cable connections First connect the grey cable of the control electronics on the right side of the portal with the black body and fix the cable with Velcro fasteners along the aluminium profile. Place the floor stickers in such a way that the two foot stickers are in the middle of the camera position and you have enough space to the back without hitting the portal frame.
  • Page 23 April 28 , 2020 Screw connection Plug all power supply units and power cables into the provided socket strip and connect them to a supply connection. Switch on the socket strip as well as the main switch of the control electronics of the blackbody and follow the instructions of the system setup, which is described below: Main switchr The user display must be switched on separately.

  • Page 24: Operation

    Portal and Mobile package After you have set up the system, switch it on. After all connected components have been started; you will be automatically forwarded to the login screen of the FebriScan system. The access data for the different logins are as follows: ...

  • Page 25: System Setup

    To set up the system for operation, log in as user "user". During the following user selection, Select “Operator“. After a short initialization phase, the FebriScan interface will appear. With all system variants, you as the operator can decide whether all information should be made available to the user.
  • Page 26 April 28 , 2020 The system is preconfigured in such a way that only the blackbody needs to be positioned if the installation distances are maintained (see chapter System Setup for Mobile / Integration package). Position the lens of the blackbody in such a way that the round measuring surface, which you can see in the top left of the live image of the camera, appears within the warm area (this appears as an orange dot).

  • Page 27: System Operation

     If an elevated body temperature of a person is detected by Febriscan, it must be verified separately with a clinical thermometer after the measurement. The procedure with persons in whose case an increased body temperature was detected is the responsibility of the respective system operator.
  • Page 28 April 28 , 2020  Ask the user to position his head within the vertical measuring surface.  Inform the user that the glasses must be taken off and hair or coverings in front of the eyes must be removed so that the inner areas of the eyes and the forehead can be seen.

  • Page 29: System Administration

    To change the preset system parameters, log in as user "administrator" immediately after the system start (see chapter 3.2.1) or click on the FebriScan icon in the upper left corner to return to the login screen. The following options are available for navigation within the FebriScan App.
  • Page 30 April 28 , 2020 On the left side of the page you can see the cameras field of view. The last image captured by the camera is always displayed. By clicking on the camera symbol below you have the possibility to take a snapshot. This is very helpful if you want to adjust the measuring surfaces to the persons to be measured.
  • Page 31  Job Manager Here you have the possibility to create individual measurement parameter sets (jobs) or to load preconfigured ones. The FebriScan system is equipped with two preset jobs, which is pre-activated depending on the purchased system variant.  Visualization and configuration In addition to the color display of the result image, you have the possibility to influence the image position, temperature scale or emmissivity.
  • Page 32 Once you have made your selection, you will return to normal measurement operation. Settings In the Settings section you have the possibility to adjust the global settings of the camera and the FebriScan system. Page 32 of 49...

  • Page 33: Automation Interface

    April 28 , 2020  Network – Network settings of the camera  Http Server – Access settings of the camera web server  Regional – Regionale country settings  User – User account management  Update – System updates ...

  • Page 34: Troubleshooting

    The blackbody status in the The blackbody may no longer Re-adjust the position FebriScan App is permanently be positioned correctly. of the blackbody. on error. The lens of the blackbody is Remove possible...

  • Page 35: Disposal

    PC is switched on and you are logged in. Disposal Like most mechanical and electronic products, this system, of the type FebriScan, is subject to the regulations for environmentally friendly disposal. Please contact the manufacturer if necessary! Page 35 of 49...

  • Page 36: Technical Specifications

    , 2020 Technical Specifications Standards The standards listed below served as the basis for the development and implementation of FebriScan, a measuring system for the detection of elevated body temperature German version: E DIN EN 80601-2-59 VDE 0750-2-59:2017-03: "Medical electrical equipment"...

  • Page 37: Technical Data

    April 28 , 2020  Compliance with the condition shall be proven by verification  Minimum resolvable temperature difference (MRTD / NETD): max. 0.1°C  Image homogeneity: max. 0.2°C deviation over the entire image or over the image section used for measuring the face. Compliance with the condition must be verified by testing Position of the face ...
  • Page 38 April 28 , 2020 Electrical Features Electrical Parameters Input voltage +10 to +24 VDC IRSX-I 336S: 4.0W Power input IRSX-I 640S: 4.2W Interfaces Network plug 8 Pin, A-coded M12 connection Network type 10, 100, 1000 Mbit/s Network Protocols DHCP, DNS, GigE Vision Image Flow Protocols GigE Vision with GeniCam Ethernet image flow...

  • Page 39: Blackbody

    April 28 , 2020 Shock 200g (IEC 60068-2-29) Blackbody Model IrBlackbody (102 800 006) Heater element Silicone heating mat (24VDC / 18.5W) Temperature sensor 3 wire PT100 Control unit Jumo DiraTron 116 Temperature range 25°C – 110°C Accuracy +/- 0.1 °C Electrical Features Electrical Parameters Blackbody Operating voltage...

  • Page 40: Service Information

    Before returning a system component to AT - Automation Technology GmbH for repair or calibration (warranty or non-warranty), a RMA (Return Material Authorization) number must be provided by AT – Automation Technology GmbH. Please get in contact with the AT support to receive a RMA.
  • Page 41 April 28 , 2020 Return address: AT – Automation Technology GmbH Hermann-Bössow St. 6-8 23843 Bad Oldesloe Germany If the system was not purchased directly from AT, please contact your distributor to initiate the RMA process. Page 41 of 49...

  • Page 42: Appendix

    April 28 , 2020 Appendix Technichal Documentation Blackbody Page 42 of 49...

  • Page 43: Control Electronics Blackbody

    April 28 , 2020 Control electronics Blackbody Page 43 of 49...

  • Page 44: Irsx-I

    April 28 , 2020 IRSX-I Page 44 of 49...

  • Page 45: Installation Notes

    April 28 , 2020 Installation Notes Step 1: Installation of the Software Install the irsxSupportPackage on your computer. Depending on your operating system, select the 32 or 64 bit version. Click "Next" in the following dialog boxes. The “Component Selection“ dialog box allows you to add additional libraries.

  • Page 46: Customer-Specific Network Configuration

    Select the camera by right-clicking on the corresponding line and choose "Open Device Website" from the context menu that appears. You will be automatically forwarded to the login screen of the FebriScan system. Please return to the chapter "System Start and Login" and follow the further instructions to activate the system.

  • Page 47: Configuration Of The Access Point

    The following reasons may require a change in the configuration of the access point:  For example, if you have ordered another FebriScan system that is located within the WLAN range of an existing one, unique SSIDs must be assigned for the different systems.

  • Page 48: Integration Of The System Ino The Customer Network

    April 28 , 2020 Remove the line unmanaged-devices=interface-name:wlan0 or put it in a comment. 5. Save the file and restart the computer. Integration of the System ino the Customer Network Ethernet First, change the network settings of the camera and the embedded visualization PC according to the requirements of your existing infrastructure.
  • Page 49 April 28 , 2020 Then connect the Ethernet interface of the embedded visualization PC and the camera to a switch in your company network. WLAN There are basically two different ways to do this: 1. You use the WLAN adapter integrated in the embedded visualization PC. To do this, you must first deactivate the access point (see "Deactivating the access point").
