OV1015 |
Part No. 84981
OV1015
HEIGHT ADJUSTABLE WORKSTATION
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OV1015 and is the answer not in the manual?

Questions and answers

Summary of Contents for OMT-Veyhl OV1015

  • Page 1 OV1015 | Part No. 84981 OV1015 HEIGHT ADJUSTABLE WORKSTATION USER GUIDE...
  • Page 2 Transform your home and office into true ergonomic workspaces. The OV1015 height adjustable workstation has clean, modern lines and is simple to use. OV1015 provides electric height adjustability, single or dual monitor support, VESA mount capability, integrated wire management, BIFMA compliance and all steel construction.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS User Guide: OV1015 TABLE OF CONTENTS Parts Diagram Workstation Unit Hardware Kit Safety Information Assembly Instructions 8-15 Operation Initialization and Reset Handswitch Operation Troubleshooting Unit Errors Handswitch Errors Technical Data Standards & Certifications Customer Service Warranty & Returns This manual explains how this sit-stand workstation is assembled, used, and maintained.
  • Page 4: Parts Diagram

    PARTS DIAGRAM User Guide: OV1015 OV1015 PARTS DIAGRAM PARTS Qty/Package 1. Clip Cord Manager 2. M6x1.0 20mm Button Head Screw 3. M6x1.0 10mm Flat Head Screw 4. M6x1.0 12mm Flange Button Head Screw 5. M8x1.25 20mm Flat Head Screw 6. M6x1.0 12mm Thumb Screw...
  • Page 5: Hardware Kit

    PARTS DIAGRAM User Guide: OV1015 HARDWARE KIT CONTENTS PARTS Qty/Package 1. Clip Cord Manager 2. M6x1.0 20mm Button Head Screw 3. M6x1.0 10mm Flat Head Screw 4. M6x1.0 12mm Flange Button Head Screw 5. M8x1.25 20mm Flat Head Screw 6. Bumper Pads 5mm Allen Wrench 8.
  • Page 6: Safety Information

    To reduce the risk of death, serious injury, or property damage, read and follow this safety information and the provided instructions when assembling this product. Do not change or replace components and accessories provided by OMT-Veyhl. INSTALL ONLY ON STABLE WORK SURFACES Install on stable surfaces with entirety of legs and motor box supported.
  • Page 7 SAFETY INFORMATION User Guide: OV1015 DO NOT OVERLOAD DESK To prevent workstation from tipping or collapsing, make sure the tray is not overloaded by the weight of objects on tray. Evenly distribute load; excess loads near edges can reduce stability and lead to tip over.
  • Page 8: Assembly Instructions

    The assembly of the workstation to be made in accordance with this manual. Changes to the workstation or improper use may affect the safety, function, and life of your product. This manual is for the OV1015 Height Adjustable Workstation. ASSEMBLY OVERVIEW 1.
  • Page 9 ASSEMBLY INSTRUCTIONS User Guide: OV1015 ATTACH RUBBER PADS TO MOTOR BOX AND FEET Attach two of the provided rubber pads to the corresponding bottom flanges on the motor box. Attach two rubber pads to the underside of the forward-facing section of each foot.
  • Page 10 ASSEMBLY INSTRUCTIONS User Guide: OV1015 Internal parts removed for better view ASSEMBLE THE FEET TO THE MOTOR BOX Lay column assembly on it’s back as shown in diagram above. Insert the base feet tabs into the corresponding slots on the column base. Insert angled feet into column base as shown.
  • Page 11 ASSEMBLY INSTRUCTIONS User Guide: OV1015 ASSEMBLE TRAY TO COLUMN With the column assembly still on its back, attach the desktop tray to the column assembly by setting the tray between the base feet. Using the M8x1.25 20mm flat head screws and the 5mm Allen wrench, secure the tray to the column assembly.
  • Page 12 ASSEMBLY INSTRUCTIONS User Guide: OV1015 ATTACH THE MONITOR BRACKET TO THE COLUMN Using the M6x1.0 10mm flat head screws provided in the hardware kit, attach the monitor mounting bracket to the column using one of the four attachment positions. Make sure to test the location of the bracket before installing and use the attachment position that best fits your height requirements.
  • Page 13 ASSEMBLY INSTRUCTIONS User Guide: OV1015 MOUNT THE MONITOR TO THE MONITOR BRACKET Single Monitor: Line up the four slots on the monitor mounting bracket with the VESA spaced mounting holes on the back of your monitor. Using four M4 screws that came with your monitor, secure the monitor to the mounting bracket.
  • Page 14 ASSEMBLY INSTRUCTIONS User Guide: OV1015 (DUAL MONITOR ONLY) INSTALL THE MONITORS Slide the monitors onto the dual monitor mounting bracket via the openings in the previously attached X brackets. Position the monitors in the desired locations and secure in place using the provided M6 thumb screws. Be sure not to over tighten the thumb screws (only 6-7 turns should be sufficient to lock the monitors in place).
  • Page 15 Do not over-tighten (hand-tightening is sufficient). Top flange of wire management bracket can be bent by hand if it doesn’t sit flush with the back side of the column. CONNECT TO POWER Enjoy your new OV1015 Height-Adjustable Tabletop Workstation! OV1015 | 15...
  • Page 16: Operation

    OPERATION INFORMATION User Guide: OV1015 OPERATION INFORMATION INITIALIZATION/RESET The workstation may need to be initialized/reset after any of the following: - After assembly - After disconnection from the power supply - After any impact on the tray. To initialize/reset, you will need to move the workstation to the lowest position by holding the DOWN button of the handswitch until the column reaches the lowest position.
  • Page 17: Troubleshooting

    OPERATION INFORMATION User Guide: OV1015 TROUBLESHOOTING UNIT ERROR SOURCE SOLUTION No power supply Plug in the power cord or check the connection Workstation on the control box does not move No connection or a loose Verify the plug connection of the motor cable...
  • Page 18: Technical Data

    TECHNICAL DATA User Guide: OV1015 TECHNICAL DATA GENERAL CONTROL BOX Power supply 120 VAC ±10% / 60 Hz Standby power consumption, primarily <0.3 W Operating temperature 0-35°C Protection class IP 20 Maximum power output 216VA/24V Maximum tray capacity 35 lb.
  • Page 19: Standards & Certifications

    CUSTOMER SERVICE User Guide: OV1015 CUSTOMER SERVICE If you have any problems with PHONE: 1-616-738-6688 your product, please contact FAX: 1-616-738-6682 our service department. STANDARDS & CERTIFICATIONS The drive system is tested according to the following standards: CSA C22.2#68 Issued: 2009/09/01 Ed: 7 (R2014) Motor-Operated Appliances (Household and Commercial);...
  • Page 20 OV1015 USER GUIDE Part No. 84981 Rev 021618...
