Incra Wheel Kit Assembly Instructions

Fig. 1 Wheel Kit
Leg Wheel Bracket (2)

Parts List:

(1) Front Wheel Connector Bracket
(1) Front Wheel Pedestal
(1) Front Wheel Foot Pedal
(1) Front Wheel Caster
(2) Leg Wheel Bracket
(2) Leg Wheel

Step 1. Assemble Leg Wheels.

First, loosley install two sets of
1 /4 " washers in each wheel bracket as shown in Fig. 2.
nuts and
Second, install a rubber wheel in the lower hole on each wheel
bracket using the 1 /4 -20 x 2
1 /4 " thick Nylon washers as shown in Fig. 2.
steel washer and
Be sure that the two 1 /4 " thick Nylon washers are against the hub
of the wheel and positioned INSIDE the wheel bracket. Install,
but do not fully tighten the locking nut on the 2
at this time.
Fig. 2 Assemble Leg Wheels
Leg Wheel Bracket
1 /4
Square Nut
1 /4 -20 x 2
Hex Bolt
1 /4" Thick Nylon Washer
Wheel
Assembly Instructions for the INCRA Wheel Kit
w w w. i n c r a . c o m
Table Stand Legs
Front Wheel Connector Bracket
Leg Wheel (2)
(8) 1 /4 -20 x
(2) 1 /4 -20 x 2
5 /16
(6)
(2) 5 /16
(8) 1 /4 -20 Square Nut
1 /4
(2) -20 Locking Nut
1 /4 -20 x 1 /2 bolts, 1 /4 -20 square
1 /4 hex bolt, 1 /4 -20 locking nut,
1 /4 hex bolts
1 /4" Washer (4)
-20
Hex Bolt (4)
1 /4
Locking Nut
1 /4" Washer
1 /4" Thick Nylon Washer
INCRA Wheel Kit
Wheel Stringer on Table Stand
Leg Wheel (2)
Front Wheel Pedestal
Front Wheel Caster
1 /2 Hex Bolt
1 /4 Hex Bolt
1 /2
-18 x Hex Bolt
-18 x 3 3 /4 Hex Bolt

Step 2. Install Leg Wheels on Legs.

Orientation: When mounting the stand to offset tables, the two
leg wheels should be located under the end of the table WITH
the router cutout in it. For center mount router tables, the two
leg wheels can be on either end of the table.
1 /4 "
Remove the levelers from the two legs on which the wheels will
be installed. As shown in Fig. 3, slide the (2) square nuts and
the long hex bolt head on each wheel assembly into the T-slot
on the leg extrusion. Adjust the vertical position of each wheel
for stability, then firmly tighten all bolts. Tighten the locking nut
enough to remove all side play between the wheel and the
inside of the wheel bracket, but still loose enough for the wheel
to pivot freely.
Fig. 3 Install Leg Wheels
1 /4 -20 x 1 /2
1 /4 -20
Outfeed Wheel
Assembly
Assembly Instructions
Front Wheel Foot Pedal
(6) 5 /16 -18 Hex Nut
(2) 5 /16 -18 Locking Nut
1 /4
(11) " Flat Washer
(4) 1 /4 " Lock Washer
(4) 1 /4 id x 1 /4 Thick Nylon Washer
5 /16 3 /16
(4) id x Thick Nylon Washer
Capture Square
Nuts & Hex Bolt
in T-Slot on Leg
Infeed Wheel
Assembly
1
