- Page 1 Page 1 of 22 3800 Squeegee Assembly 383794 Minuteman Powerboss INC Aberdeen, NC...
- Page 2 Page 2 of 22 MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 3 Page 3 of 22 401006 400301 401007 401008 401008 400301 401006 401007 MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 4 3/8” • Note: Use Arbor press to Press in Pins & Special Tool to set height of pins on Rear of Squeegee Frame. MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 5 Page 5 of 22 Mount PN: 3330589(Weld-3800 SQU TOP PLT RT), PN: 330592(Weld-3800 SQU TOP PLT LT) to casting using: 1) 3400032-SCR-HEX, 3/8- 16X0.75 ZP (2ea) 2) 3400101-Washer-Lock 3/8 Split ZP (2ea) 3) 712562 – BLT-HH ¼- 20X.75 SS (4ea) 4) 712758 –...
- Page 6 Page 6 of 22 • Place rear squeegee PN: 383607-(3800 REAR SQUEEGEE BLADE NEW) on squeegee casting PN:383623 (3800 SQ CASTING MCHD, NEW). MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 7 Page 7 of 22 • Place Rear strap 3330572 (Weld-3800 Squ back strap) on rear squeegee secure with latch 281075- (Squeegee Latch, 2800) MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 8 Page 8 of 22 Secure Rear Squeegee & Strap MODEL:3800 SQUEEGEE to Frame with Latch DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 9 Page 9 of 22 • Place front Squeegee 383606(3800 Front Squeegee Blade, new) on casting 383623 – (3800 SQ Casting Mchd, new) MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 10 Page 10 of 22 • Place front strap 3330591- (Weld-3800 Squ front Strap) on squeegee secure with thumb screw 3401001-SCR-Thumb 3/8-16x1-1-1/2 SS. MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 11 Page 11 of 22 •Place Gasket PN: 383792 (Gasket- Squeegee Mnt Brkt)on Casting PN: 383623 (3800 SQ CASTING MCHD, NEW).
- Page 12 Page 12 of 22 MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 13 4. 712562 – BLT-HH ¼-20x.75 SS 5. 712758 – WSR Helical ¼ SS 6. 383789 – Squeegee Mount Bracket 7. 711507 WSR–Flat .37 X1.12X.06 8. 400109– Clevis Pin 9. 711808 – Cotter Pin – Hair #13 MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 14 Take PN: 3400320 (Hex Nut 5/16 – 18 SS) & Thread on to Right side of Adj Stud • Take PN: 762257 Plt & 762257PLT thread on to Right side of Adj Stud MODEL:3800 SQUEEGEE DATE: 2-18-2003 762022PLT 750689 DOCUMENTED BY: POWERBOSS...
- Page 15 MODEL:3800 SQUEEGEE Page 15 of 22 DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS Assembly 711507 (2) 400711 711808 383424 383425...
- Page 16 LH_ to to PN: 750154 Sg mtg wmt using: • PN:711668(Clevis pin 3/8 X 1”11-141 ) • PN:711509 – (2) (Wsr-Flat .37X1.12x.06) • PN:711808 (Cotter Pin – Hair #13) • PN: 711713(Retaining Ring-E Ext .50) • PN: 711524(Wsr-Wave .52X.87X.01) MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 17 Page 17 of 22 Complete Assembly of 711713 711509 (2) Squeegee Mount Plate •711713-Retaining Ring-E ext .50 •711509-Washer Flat ½ •711544- Washer Helical ¼ •712562- Blt HH- 1/4-20x.75 SS 711544 (4) MODEL:3800 SQUEEGEE DATE: 2-18-2003 712562 (4) DOCUMENTED BY: POWERBOSS...
- Page 18 Page 18 of 22 (2) 430325 –Caster Wheel 2.50 DIA (2)711367 -Nut-Wing 3/8-16 Stpl Jarvis PN; 3-713-000 GS...
- Page 19 Complete Assembly of & (4) ¼-20 SS Flt washer Squeegee Mount Plate Thread PN: 430325(Caster Wheel 250 DIA. Jarvis) into PN: 383789 (Squeegee Mtg Brkt Wmt) secure with PN: 711367 (Nut-Wing 3/8-16 Stpl) MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 20 • Mount Squeegee to plate to 711524 casting using • (2) ea. PN: 220249 Bolt 711713 with ½ - 13 X .75 & • (2) ea. PN: 711578 Plt Wsr Brass 712091 MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
- Page 21 Page 19 of 22 712091-Shoulder Blt 3/8 X 1.5 712507 – Wsr-Flat.37X1.12x.06 3400336-Washer 832015-Spacer 808829 – Wheel Truck Flat3/8”SS .38x.5x.14...
- Page 22 Page 22 of 22 MODEL:3800 SQUEEGEE DATE: 2-18-2003 DOCUMENTED BY: POWERBOSS...
