Instructions for „Mistral" erection
_________________________________________________________________________________________________________________
Dear Customer,
Congratulations on your purchase of your new Herzog awning, we wish you many happy
relaxing days ahead. You have purchased a top quality product, manufactured to the highest
standard using optimum materials, which will give you many years of trouble free use.

Specification:

Frame: 2 x Long fibreglass poles (11,0 mm diameter)
1 x Short fibreglass poles (9,5 mm diameter)
Roof & Walls: Roof
2 x Side walls with ventilated window & cover
1 x Front Wall
Accessories: Tent pegs, guy ropes
Caution: Please note that the fibreglass poles, when bent into place, are under
Stress and caution should be taken to prevent damage or injury.

Erection:

Draw the canvas in to the caravan awning rail, ensuring that the awning roof
does not extend down the curve of the caravan roof (a).
Push one of the long fibreglass poles (Ø 11 mm) from the bottom of one of the
transverse pockets (b) until the caravan side is reached. Repeat for second
long pole. Secure the ends of the poles to the adjustable floor tapes (c). The
poles will bend to create a tunnel effect (force is necessary to form the bend).
The ends of the short pole should now be located into the pockets on each
side of the awning near the caravan wall (d). This pole is then fixed to the
awning using the rubber cord, as illustrated below.
