MIOTTA Home8 TotalShield M1201CUS Quick Start Manual

What's inside:
1 2
1x Gateway 1x Twist HD
Camera
Power
1x
Adapter
Ethernet
1x
Cable
4 5
1x Infrared 1x Fire/CO Siren
Motion Sensor Extender Sensor
Battery Battery
1x 1x
(CR123A) (CR123A)
Double-Sided
1x 2x
Tape
Mounting
Accessories
7
1x External Siren
Mounting
6x
Accessories
Double-Sided
1 x
Tape
Broadband internet connection, iOS or Android phone and home router required.
3. Follow the on-screen
instructions and set up
your account.

Step 3: Activate your system

1 . Select Menu Icon
top left on the App and tap
"Add Device" to activate
system.
2. Find the QR Code Sticker
on the Gateway and follow
the instructions on your
app.
3. When you see the "System
is ready!" message.
Congratulations, your system
setup has completed!
TotalShield
Quickstart Guide
Model No. M1201CUS
3
6x Door + Window
Sensors
Power Batteries
1x 6 x
Adapter (CR123A)
Power Double-Sided
1x 12x
Cable Tapes
6
1x Water Leak
Sensor
Battery
1x
(CR123A)
Double-Sided Mounting
Tapes Accessories
8
2x Arm/Disarm/
Panic Remotes
on

Step 1: Connect to Network

Unpack all of your hardware within 20 feet of your
home router for quick set up.
1 . Connect the
to your router with the
included Ethernet
cable, then power on.
2. Install batteries and plug
in power adapters to
devices and sensors.

Step 2: Set up your smartphone

1 . Go to Wi-Fi settings and
connect your smartphone
to Wi-Fi.
2. Download the Home8 app
from the App Store or
Google Play Store.
V1.0
Step 4: Place Your Devices
Twist HD Camera
Connect the included power
adapter to the
Check the Light indicators,
The left light should be Solid
blue as power on. The right
light should be blink blue if
camera connect to Gateway
successfully.
Door + Window Sensor
Use screws or Double-sided
tape to attach sensor.
Maximum distance between
two part is 1/4 inch .
External Siren
Plug the power line.
Place the siren.
1 Gateway
1
7
5
2 Camera.
3
3 4 8
6
2
1/4"
7
