APR2060DB-K2.1 Demo Board
APR2060 DB-K2.1 is suitable for APR2060-K2.1 supporting fixed 1/2 messages & volume
control mode.
How to set up :
1. Connect the speaker & the power ( 6V, 4batteries )
2. Move the DIP SW to your required 1 or 2 sections rec & playback.
( Default : 2 sections mode & 12KHz sample rate )
2 sections
20sec/each section(M2-M3)
** Please note to remove the power & wait for 3-5 seconds then connect the power again
before you want to change the DIP SW to the other section mode.
User Guide
1 section
40sec/ M2
1/3
aPR2060 K2.1
MAR 20 2014
