- Page 1 BG-EPTZ-AF AI 4K UHD Video Conference Camera User Manual...
-
Page 2: Table Of Contents
Content ATTENTION ..........................1 FAST INSTALLATION ...................... 2 1.1 C ........................2 AMERA NTERFACE 1.2 C ........................2 AMERA PERATION PRODUCT OVERVIEW ....................3 2.1 P ........................ 3 RODUCT NTRODUCTION 2.1.1 Dimensions ........................... 3 2.1.2 Accessories ........................... 3 2.2 M .......................... -
Page 3: Attention
Attention This manual introduces functions, installation and operations for the camera in details. Please read this manual thoroughly before installation and use. 1. How to Use To prevent damage to this product or any product connected to it, this product can only be used within the specified range. -
Page 4: Fast Installation
1. Fast Installation 1.1 Camera Interface Figure 1.1 camera interface 1. camera lens 3. built-in MIC 5. positioning hole 2. bracket 4. tripod fixing hole 6. USB 3.0 output interface 1.2 Camera Operation 1) Product Installation: Fix the device on LCD screen, top of computer; directly put it on desk or on tripod mounting. -
Page 5: Product Overview
Packing List 2.2 Main Features The BG-EPTZ-AF is a new 4K UHD ePTZ video conference camera. It is built with AI functions, which can automatically frame all people in the meeting and make them at the middle of the scene. It also has perfect functions and superior performance, which adopts advanced ISP processing algorithms so as to provide vivid images with evenly clear brightness, strong color layering, high resolution, and fantastic color rendition. -
Page 6: Technical Specifications
Easy to Use: No need to download driver; USB Plug and play. Wide Applications: Personal video conferencing, enterprise video conferencing, unified collaboration and etc. 2.3 Technical Specifications Model Number BG-EPTZ-AF Camera Parameter Image Sensor 1/2.5-inch 4K CMOS Sensor Effective Pixels 8.28MP 16:9... -
Page 7: Interface Instruction
≥50dB USB Feature Windows 7(1080p at the most), Windows 8.1, Windows 10 ; macOS™ 10.10 or Operation Systems higher, Linux (Require to support UVC.) Video Compression YUY2, MJPG, H.264, H.265 format Audio over USB3.0 Support USB communication UVC, UAC protocol PTZ control Support EPTZ Hardware... -
Page 8: Application Instruction
3. Application Instruction 3.1 Remote Controller 3.1.1 Keys Instruction 1. Standby Key（not supported currently） After 3s long press, the camera will be in standby mode. Long press 3s again, the camera will self-test again and back to HOME position. Note: If preset 0 is set, there is no operation within 12s, camera head will automatically point to the specified preset 0 position. -
Page 9: Applications
Enter / exit the OSD menu or return to the previous menu 11. Address Setting 【*】+【＃】+【F1】:Camera Address No.1 【*】+【＃】+【F2】:Camera Address No. 2 【*】+【＃】+【F3】:Camera Address No. 3 【*】+【＃】+【F4】:Camera Address No. 4 12. Key Combination Functions 1) 【#】+【#】+【#】:Clear all presets 2) 【*】+【#】+【6】:Restore factory defaults 3) 【*】+【#】+【9】:Flip switch 4) 【*】+【#】+【4】:Menu set to English 5) 【*】+【#】+【3】:Menu set to Chinese... - Page 10 1. Preset setting: to set a preset position, the users should press the “【SET PRESET】” key first and then press the number key 0-9 to set a relative preset, Note: 10 preset positions in total are available by remote controller. 2.
-
Page 11: Menu Setting
【*】+【＃】+【F1】:Camera Address No.1 【*】+【＃】+【F2】:Camera Address No. 2 【*】+【＃】+【F3】:Camera Address No. 3 【*】+【＃】+【F4】:Camera Address No. 4 3.2 MENU SETTING 3.2.1 Main Menu When use MJPG/ H.264 / H.265 compression , press 【MENU】 key to display the menu, using scroll arrow to point at or highlight the selected items. MENU ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝... - Page 12 Dual: open/close Auto Zoom: open/close, sensitivity 0-7 Exposure Setting Move the pointer to EXPOSURE in the Main Menu, click the 【HOME】and enter the (EXPOSURE SET) as follows: EXPOSURE ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Mode Auto Flicker 50Hz G.Limit [↑↓]Select [← →]Change Value Mode : Auto, Manual, Shutter priority, Iris priority and Brightness priority. EV : On/Off (only available in auto mode) Compensation Level: -7~7 (only available in auto mode when EV is ON) BLC: ON/OFF for options (only available in auto mode)
- Page 13 COLOR ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ WB Mode Auto RG Tuning BG Tuning Saturation 100% AWB Sensitivity High [↑↓]Select [← →]Change Value WB Mode: Auto, Manual, One Push, 3000K, 3500K, 4000K, 4500K, 5000K, 5500K, 6000K, 6500K, 7000K RG Tuning: -10~10 (only available in Manual mode) BG Tuning: -10~10 (only available in Manual mode) Red Gain: 0~255 (only available in Manual mode) Blue Gain: 0~255 (only available in Manual mode)
- Page 14 Gamma: default, 0.45, 0.50, 0.55, 0.63 DCI: Dynamic Contrast: Off,1～8 6. Focus Setting Move the pointer to FOCUS in the Menu, click the【HOME】and enter the (FOCUS) as follows: FOCUS ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Focus Mode Auto AF-Zone Center AF-Sensitivity [↑↓]Select [← →]Change Value Focus Mode: Auto, manual, one-push AF-Zone: Up, middle, down, overall AF-Sensitivity: High, middle, low...
-
Page 15: Maintenance And Troubleshooting
VERSION ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Cam Version 1.0.2 2019-11-28 Focus Version 1.0.6 2018-8-21 [↑↓]Select [← →]Change Value [↑↓]选择 [← →]修改 9. Restore Default Move the pointer to RESTORE DEFAULT in the Main Menu, click 【HOME】and enter RESTORE DEFAULT as below: RESTORE DEFAULT ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Restore Default? [↑↓]Select [←... - Page 16 a. Check whether USB cable connected well and power indicator light is ON. b. Whether the machine could do self-check after restarted. c. Restart PC d. Check whether the camera is well recognized by PC 2) No image sometimes Check the USB cable quality and whether connected well. 3) Image dithering when zoom-in or zoom-out a.
-
Page 17: Warranty
5. Warranty BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*! Taking advantage of this program is simple: 1. -
Page 18: Mission Statement
6. Mission Statement BZBGEAR manifests from the competitive nature of the audiovisual industry to innovate while keeping the customer in mind. AV solutions can cost a pretty penny, and new technology only adds to it. We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank. -
Page 19: Copyright Statement
7. Copyright Statement All the contents in this manual and its copyright are owned by the company. No one is allowed to imitate, copy, or translate this manual without the company’s permission. This manual contains no guarantee, standpoint expression or other implies in any form. Product specification and information in this manual is for reference only and subject to change without notice.
