RKI GX-6000 Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

GX-6000
Operator's Manual
Part Number: 71-0362
Revision: M
Released: 2/26/20
www.rkiinstruments.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GX-6000 and is the answer not in the manual?

Questions and answers

Related Manuals for RKI GX-6000

Summary of Contents for RKI GX-6000

  • Page 1 GX-6000 Operator’s Manual Part Number: 71-0362 Revision: M Released: 2/26/20 www.rkiinstruments.com...
  • Page 2 Typical calibration frequencies for most applications are between 1 and 3 months, but can be required more often or less often based on your usage. GX-6000 Operator’s Manual...

  • Page 3: Table Of Contents

    Turning On the GX-6000 ........
  • Page 4 Performing a Bump Test ..........89 GX-6000 Operator’s Manual...
  • Page 5 Updating the Language Setting (LANGUAGE)....... 153 Updating the Lunch Break Setting (LUNCH BREAK) ......153 GX-6000 Operator’s Manual...
  • Page 6 Start Up, Bar Hole Mode ..........181 Turning on the GX-6000, Bar Hole Mode ......181...
  • Page 7 Performing a Bar Hole Test ........184 Turning Off the GX-6000, Bar Hole Mode ......186 Appendix E: Using the GX-6000 in Inert Mode .
  • Page 8 Measuring Mode ............242 Turning off a GX-6000 with an 11.7 eV Sensor ......242 Calibrating the 11.7 eV PID Sensor .
  • Page 9 Not tested in oxygen enriched atmospheres (above 21%). NOTE: RKI Instruments, Inc. recommends that you refer to ISA-RP12.13, Part II-1987 or an equivalent international recommended practice for guidance in the use of combustible gas detection instruments.

  • Page 10: Chapter 1: Introduction

    Chapter 1: Introduction Overview This chapter briefly describes the GX-6000 gas monitor. This chapter also describes the GX-6000 Operator’s Manual (this document). Table 1 at the end of this chapter lists the specifications for the GX-6000. About the GX-6000 Using an advanced detection system consisting of up to six gas sensors, the GX-6000...
  • Page 11 When using the GX-6000, you must follow the instructions and warnings in this manual to assure proper and safe operation of the unit and to minimize the risk of personal injury.

  • Page 12: Specifications

    40.0 ppm * When calibrating the GX-6000 with the Auto Calibration or the Single Calibration method, the calibration gas value must be equal to or higher than the alarm 1 setting. See “Updating the Alarm Point Settings (ALARM POINTS)” on page 150 for instructions to change the alarm points if necessary for the desired calibration gas value.
  • Page 13 • VOC zero filter (included for instruments with a low range PID sensor, a 10.0 eV/ benzene PID sensor, an 11.7 eV PID sensor or any PID/IR CO combination) • Dehumidifier filter (included for instruments with an 11.7 eV PID sensor) GX-6000 Operator’s Manual Chapter 1: Introduction • 13...

  • Page 14: About This Manual

    Approximately 400 g (14 oz.) About this Manual Although the GX-6000 can support up to 6 sensors, this manual specifically describes an instrument with the four standard sensors and a PID sensor. See the appendices for descriptions of other sensors.

  • Page 15: Chapter 2: Description

    A clear plastic window is located on the front of the case. The battery pack and flow chamber are located on the back of the GX-6000. The inlet filter holder is located on the top of the GX-6000 case.

  • Page 16: Control Buttons

    A computer’s infrared port or an IrDA/USB cable connected to a USB port can be used to download data saved by the GX-6000 to a computer using the GX-6000 Data Logger Management Program. See the GX-6000 Data Logger Management Program operator’s manual for data logging and downloading instructions.

  • Page 17: Buzzer

    GX-6000 because of flow rate reduction. Flow Chamber The flow chamber is on the back of the GX-6000 and is held in place by four Phillips screws. The flow chamber seals to the rubber sensor gasket which seals to the sensor faces inside the GX-6000 and routes flow from the pump to the sensors and to the exhaust port (on the top of the GX-6000 case).

  • Page 18: Filters

    LCD. PID Sensor Two types of PID sensors can be used with the GX-6000, a low range (higher sensitivity) sensor and a high range (lower sensitivity) sensor (see Table 1 for specifications). The PID sensor is a cylindrical sensor with a diffusion opening on the front and 3 pins on the back.

  • Page 19: Inlet Filter Holder

    The filter holder is a clear plastic dome shaped piece on the top of the case. A male quick connect fitting is located on the inlet filter holder. This is the GX-6000’s inlet fitting. The filter holder may be removed by turning it counterclockwise and pulling it away from the case.

  • Page 20: Included Accessories

    A protective rubber boot can be installed over the GX-6000. Wrist Strap A wrist strap is included with the GX-6000 and can be attached to the right or left wrist strap installation feature on the GX-6000 case. Sample Hose and Probe A 3 foot sample hose with an attached probe is standard with the GX-6000.

  • Page 21: Screen Protector

    Screen Protector The clear screen protector can be installed over the GX-6000’s LCD to prevent it from getting scratched. Remove the GX-6000’s rubber boot. Orient the GX-6000 so that the LCD is as horizontal as possible. Clean the LCD with rubbing alcohol.

  • Page 22: External Dilution Fitting

    Figure 3: VOC Zero Filter External Dilution Fitting A 1:1 external dilution fitting is available for the GX-6000. It is designed to mate with the inlet fitting and accept the sample hose and probe. The fitting is made with brass and nickel plated brass and is appropriate for use with the four standard gases.
  • Page 23 Slide the charger(s) along the DIN rail into the desired position. Install the end clamps on the left and right side of the charger or bank of chargers to prevent sliding. DIN Rail Clamp Figure 7: Clamp Installation GX-6000 Operator’s Manual Chapter 2: Description • 23...
  • Page 24 Remove the clamps by pushing on the bottom of the clamp and pulling on the top of the clamp. b. Slide the charger(s) off the DIN rail. Figure 10: Charger Removal 24 • Chapter 2: Description GX-6000 Operator’s Manual...

  • Page 25: Chapter 3: Operation

    Leak Check Mode instructions. See pg.180 for Bar Hole Mode instructions. Start Up This section explains how to start up the GX-6000, get it ready for operation, and turn it off. NOTE: The screens illustrated in this section are for a standard 4-gas + high range PID unit.
  • Page 26 GX-6000 automatically resumes accumulating the peak and TWA readings. The GX-6000 will also continue to keep track of operating time including the operating time from the last time the GX-6000 was used. See “Time in Operation Screen” on page 54 for more information about how the GX-6000 tracks the operating time.
  • Page 27 Buzzer sounds double pulsing None tone Action • Option A, Perform calibration: The GX-6000 cannot be used until • Option A, Perform calibration: a successful calibration is per- To perform a calibration, press Press and release POWER/ formed. Press and release and release POWER/ENTER.
  • Page 28 Buzzer sounds double pulsing tone None tone Action • Option A, Perform bump test: The GX-6000 cannot be used until • Option A, Perform bump test: Press and release POWER/ a successful bump test has been To perform a bump test, press ENTER to perform a bump performed.
  • Page 29 4:07 BATTERY VOLTAGE 4.5V BATTERY TYPE ALKALINE LATCHING The Active Gases Screen appears for a few seconds indicating which channels are active and their target gas. SMART 1 Isobutylene %LEL 10.6 eV GX-6000 Operator’s Manual Chapter 3: Operation • 29...
  • Page 30 (ID DISPLAY)” on page 152), the User ID Screen appears for a few seconds, followed by the Station ID Screen. 4:07 4:07 USER ID STATION ID KIMBERLY TANK 5 If ID DISPLAY is set to OFF, these screens will not appear. 30 • Chapter 3: Operation GX-6000 Operator’s Manual...
  • Page 31 11 . If the GX-6000 experiences a sensor failure during start up, a screen indicating which sensor failed appears and the buzzer sounds a double pulsing tone once per second. In the example below, the CH sensor has failed. SENSOR...

  • Page 32: Performing A Demand Zero

    Performing a Demand Zero Before using the GX-6000, it is recommended to set the fresh air readings for the target gases by performing a demand zero. This will set the CH S, CO, and PID channels to zero and the OXY channel to 20.9%.

  • Page 33: Measuring Mode, Normal Operation

    If CONFIRMATION is set to ON in the Maintenance Mode menu (see pg.155), the GX- 6000 beeps periodically to confirm that it’s operating. Monitoring an Area Start up the GX-6000 as described above in “Start Up” on page 25. It is now in Measuring Mode. 4:07 20.9...

  • Page 34: Using Optional Sample Hoses

    Using Optional Sample Hoses The standard sample hose for the GX-6000 is 3 feet long. Optional samples hoses and probes with longer hoses are available from 5 - 50 feet in 5 foot increments (see pg.130). If you are considering using a hose and probe with a longer hose, keep in mind that a longer hose will increase the GX-6000’s response time and the flowrate may decrease...
  • Page 35 2.78 • The GX-6000 provides the catalytic combustible sensor with some protection against exposure to high levels of combustible gas which can damage the sensor. It does this by turning off the combustible sensor power temporarily when it determines that an over scale (more than 100 %LEL) concentration of combustible gas is present that may damage the sensor.

  • Page 36: Voc Detection

    Minimize the sensor’s exposure to these gases as much as possible. If exposure occurs, allow the instrument to draw fresh air and confirm that the readings return to fresh air values. 36 • Chapter 3: Operation GX-6000 Operator’s Manual...

  • Page 37: Snap Log Mode

    The third screen displays the year, month, day, and time of the snap log. The fourth screen displays the current gas readings. NOTE: If the GX-6000 detects an alarm condition while in Snap Log Mode, it will automatically exit Snap Log Mode and return to Measuring Mode. You may then reenter Snap Log Mode and take snap logs while the instrument is still in alarm.
  • Page 38 DISP/LOCK button. The unit will immediately return to the Measuring Mode Screen. The data recorded in Snap Log Mode can be viewed in Display Mode. See pg.60 for more information. 38 • Chapter 3: Operation GX-6000 Operator’s Manual...

  • Page 39: Measuring Mode, Alarms

    Alarm Indications The GX-6000 buzzer will sound an alarm, the LEDs will flash, and the vibrator will pulse when any sort of alarm condition or failure is encountered. NOTE: If an alarm condition occurs while you are in Display Mode, the GX-6000 will automatically bring up the alarm screen instead.
  • Page 40 Man Down Warning 1 • Alarm LED arrays flash once per Single pulsing tone once second The WARNING 1 TIME per second defined in Maintenance Mode has passed since the instrument detected movement. 40 • Chapter 3: Operation GX-6000 Operator’s Manual...

  • Page 41: Responding To Alarms

    Reset or silence the alarm as necessary or allowed. Table 7 below summarizes resetting and silencing alarms for all ALARM LATCHING and ALARM SILENCE combinations that are possible. See pg.151 and pg.151 for further descriptions of these parameters. GX-6000 Operator’s Manual Chapter 3: Operation • 41...
  • Page 42 WARNING: An over range condition may indicate an extreme combustible gas, toxic gas, or oxygen concentration. Confirm a normal condition with a different GX-6000 or with another gas detecting device. CAUTION: High off-scale readings may indicate an explosive concentration. PRUDENCE: Des lectures élevées hors échelle peuvent indiquer une concentration explosive.
  • Page 43 Take the Model GX-6000 to a non-hazardous area and replace or recharge the batteries as described on pg.104. The GX-6000 is fully functional during a low battery warning. However, only a limited amount of operating time remains, approximately 1 - 2 hours. The amount of time depends on how often the LCD backlight is used and how often the unit is responding to alarm conditions.
  • Page 44 Attempt to change the date using the DATE menu item in Maintenance Mode. See pg.141. If the date cannot be set correctly, contact RKI Instruments, Inc. as soon as possible. Responding to System Failure Alarms If a system failure occurs, the system failure screen will display an error code as...

  • Page 45: Data Logging

    The GX-6000 features the ability to log data to its internal memory and download it to a computer via the infrared communications port on the front of the unit. It logs gas readings in Measuring Mode, alarm data, and calibration data.
  • Page 46 300 hours 10 minutes 600 hours For a complete description of the Data Logger Management Program and procedures for downloading data to a computer, see the GX-6000 Data Logger Management Program Operator’s Manual. 46 • Chapter 3: Operation GX-6000 Operator’s Manual...

  • Page 47: Chapter 4: Display Mode

    Chapter 4: Display Mode This section describes using the GX-6000 in Display Mode. See Table 10 below for a list of Display Mode’s menu items, a short description of each item, and the page number for further description. Table 10: Display Mode Items...

  • Page 48: Pid Gas Name Screen

    Turning the instrument off and on does not change this setting. If there are 2 PID sensors installed in your GX-6000, the PID Gas Name Screens will appear in Display Mode in the following order regardless of their position in the flow system: 10.0 eV/benzene, 10.6 eV, 11.7 eV.
  • Page 49 GX-6000. The chemical formula is displayed next to the gas number. The response factor relative to isobutylene is listed on the second line. The gas name is listed on the third line.

  • Page 50: Peak Screen

    (lower for oxygen), the peak reading is cleared, or the GX-6000 is turned off. The lunch break feature enables the GX-6000 to save peak readings when it is turned off so it can continue them when it is turned on again. See “Turning On the GX-6000” on page 25. PEAK 15.0...

  • Page 51: Stel Screen

    OFF, the TWA is cleared when the GX-6000 is turned off. If LUNCH BREAK is set to ON, the GX-6000 will remember TWA readings when it is turned off so it can continue them when it is turned on again. See pg.25.

  • Page 52: View Alarm Settings Screen

    ENTER button. The Full Scale Settings screen will appear showing full scale settings for each channel. Use the AIR and SHIFT (PANIC) buttons to scroll through the Warning, Alarm, STEL, and TWA settings. 52 • Chapter 4: Display Mode GX-6000 Operator’s Manual...
  • Page 53 The buzzer, LED’s, and vibration will activate. Press and release the POWER/ENTER button again to stop the simulated alarm. Press and release the DISP/LOCK button to return to the View Alarm Settings Screen. GX-6000 Operator’s Manual Chapter 4: Display Mode • 53...

  • Page 54: Time In Operation Screen

    If LUNCH BREAK is set to ON, the time in operation will only be reset if you do not choose to resume the peak and TWA measurements when the GX-6000 is turned on in the Lunch Break Screen described in Step 3 on page 26. If you choose to resume the peak and TWA measurements during startup, the GX-6000 will include the time in operation when the unit was last turned off in the current time in operation.

  • Page 55: Log Time Remaining Screen

    The LOG CLEAR screen asks if you want to clear the data logger memory. DISP LOG CLEAR YES :ENTER NO :DISP EXIT :RESET To continue through Display Mode without clearing the log data, press and release the DISP/LOCK button. GX-6000 Operator’s Manual Chapter 4: Display Mode • 55...
  • Page 56 The unit will display the following screen as it clears the data. DISP LOG CLEAR CLEAR When the instrument has cleared the data, it will return to the LOG CLEAR screen in Display Mode. 56 • Chapter 4: Display Mode GX-6000 Operator’s Manual...

  • Page 57: Pump Off Screen

    Pump Off Screen WARNING: The GX-6000 is not a gas monitoring device while the pump is off. NOTE: The item appears in Display Mode only if the PUMP OFF DISP menu item in Maintenance Mode is turned ON. The factory setting for PUMP OFF DISP is OFF.

  • Page 58: Select User Id Screen

    This screen only appears in Display Mode if the ID DISPLAY item in Maintenance Mode is set to ON. Use this screen to select a user ID from the user ID list in the GX-6000’s memory. The current user ID is displayed. A user ID can be up to 16 characters long. The GX-6000 can store up to 128 user IDs.

  • Page 59: Select Station Id Screen

    This screen only appears in Display Mode if the ID DISPLAY item in Maintenance Mode is set to ON. Use this screen to select a station ID from the station ID list in the GX-6000’s memory. The current station ID is displayed. A station ID can be up to 16 characters long.

  • Page 60: Viewing Snap Logger Data

    The Snap Logging Screen allows you to view data from previous snap logs. For information on how to use the snap logging feature, see “Snap Log Mode” on page 37. DISP REC. DATA DISP YES :ENTER NO :DISP EXIT :RESET 60 • Chapter 4: Display Mode GX-6000 Operator’s Manual...
  • Page 61 To scroll through the data by viewing the snap log ID number, press and release POWER/ENTER. To return to the Snap Logging Screen, press and release the DISP/LOCK button. GX-6000 Operator’s Manual Chapter 4: Display Mode • 61...

  • Page 62: Peak Bar Screen

    Press and release the POWER/ENTER button to save the setting and return to the Peak Bar Screen. To return to the Peak Bar Screen without saving any changes, press and release the DISP/LOCK button. 62 • Chapter 4: Display Mode GX-6000 Operator’s Manual...

  • Page 63: Gas Display Screen

    With the Gas Display Screen showing, press and release the POWER/ENTER button. The available choices will appear. DISP GAS DISP DISPLAY ALL SCROLL AUTO SCROLL MANUAL GX-6000 Operator’s Manual Chapter 4: Display Mode • 63...

  • Page 64: Lcd Flip Screen

    (PANIC) buttons to display the desired setting. Press and release the POWER/ENTER button to return to the LCD Flip Screen. To return to the LCD Flip Screen without saving any changes, press and release the DISP/LOCK button. 64 • Chapter 4: Display Mode GX-6000 Operator’s Manual...

  • Page 65: Combustible Sensor Protection Screen

    NOTE: If the catalytic LEL sensor is disabled and if the instrument is then turned off and back on, the catalytic LEL sensor will be enabled again. Press and release the POWER/ENTER button to return to the CAT (LEL) SENSOR PROTECTION screen in Display Mode. GX-6000 Operator’s Manual Chapter 4: Display Mode • 65...

  • Page 66: Lcd Background Color Flip Screen

    English. The Language Screen allows the user to change the instrument’s language back to English. DISP LANGUAGE CHANGE TO ENGLISH YES :ENTER NO :DISP EXIT :RESET 66 • Chapter 4: Display Mode GX-6000 Operator’s Manual...
  • Page 67 CONFIRM ? Press and release the POWER/ENTER button again to confirm the change. To return to the Language Screen without changing the instrument’s language to English, press and release the DISP/LOCK button. GX-6000 Operator’s Manual Chapter 4: Display Mode • 67...

  • Page 68: Chapter 5: Calibration Mode

    Perform a span adjustment on one channel at a time using single calibration • Perform a bump test NOTE: You can set up the GX-6000 to alert you during the startup sequence when calibration is due. See pg.143. CAUTION: BEFORE EACH DAY’S USAGE, SENSITIVITY IN THE %LEL RANGE...

  • Page 69: Calibration Supplies And Equipment

    10% - 16% oxygen. • A demand-flow regulator to provide adequate sample gas flow NOTE: RKI Instruments, Inc. recommends that you dedicate a regulator for use with chlorine (Cl ) gas and that you do not use that dedicated regulator for any other gases, particularly hydrogen sulfide (H •...

  • Page 70: Calibrating Using The Auto Calibration Method

    (high range PID only) or an RKI 4-gas cylinder and an RKI PID cylinder and is the quickest and easiest method to calibrate the GX-6000. See Table 16 on page 130 for available cylinders. Make sure your calibration cylinder is appropriate for the PID detection range.
  • Page 71 Attach the VOC zero filter to the inlet fitting or probe. The filter does not have a preferred flow direction. c. Let the instrument draw through the VOC zero filter for 1 minute before continuing. GX-6000 Operator’s Manual Chapter 5: Calibration Mode • 71...
  • Page 72 %LEL SINGLE CAL NORMAL MODE 10 . If the VOC zero filter was used, remove the filter from the GX-6000’s inlet fitting or probe. Reinstall the plugs on each end of the filter. 72 • Chapter 5: Calibration Mode GX-6000 Operator’s Manual...

  • Page 73: Performing A Span Adjustment

    Install the demand flow regulator onto the 4-gas or 5-gas calibration cylinder. Connect the sample tubing to the demand flow regulator. Install the sample hose and probe on the GX-6000 inlet fitting. Make sure the probe’s two halves are tightened firmly together to avoid leaks that can affect the calibration.
  • Page 74 If you do not want to continue with the concentration adjustment, press and release the DISP/LOCK button to return to the Auto Cal Menu. NOTE: The RKI 4-gas cylinder typically contains 12% O by volume. When using the auto calibration method, be sure to set the “O2” auto calibration value to agree with the concentration listed on the cylinder’s label, not zero.
  • Page 75 13 . Press and release the POWER/ENTER button. The instrument returns to the Auto Cal Menu. 14 . Use the AIR and SHIFT (PANIC) buttons to move the cursor next to GAS SELECT. AUTO AUTO CAL CONCENTRATION GAS SELECT ESCAPE GX-6000 Operator’s Manual Chapter 5: Calibration Mode • 75...
  • Page 76 If you do not want to proceed with the calibration, press and release the DISP/LOCK button to return to the Gas Select Screen. If you do want to continue with the calibration, proceed to the next step. 76 • Chapter 5: Calibration Mode GX-6000 Operator’s Manual...
  • Page 77 17 . Connect the tubing from the demand flow regulator to the rigid tube on the probe. Allow the GX-6000 to draw gas for one minute. 18 . Press and release the POWER/ENTER button to set the span adjustment for each channel to the programmed values.
  • Page 78 If SEN LIFE ALERT is set to ON (factory setting) and if a sensor is in a sensor life warning condition, the following screen appears. The buzzer and LEDs activate in a double pulsing pattern. Press and release POWER/ENTER to acknowledge the sensor life warning. SEN LIFE WARNING 78 • Chapter 5: Calibration Mode GX-6000 Operator’s Manual...
  • Page 79 24 . If the 4-gas calibration passed, the PID Gas Select Screen displays. If the 4-gas calibration failed, use SHIFT (PANIC) to display the PID Gas Select Screen. AUTO GAS SELECT GX-6000 Operator’s Manual Chapter 5: Calibration Mode • 79...
  • Page 80 If you are using a PID only calibration cylinder: a. Connect the tubing from the regulator to the rigid tube on the probe. Allow the GX-6000 to draw gas for one minute. b. Press and release the POWER/ENTER button to set the span adjustment for the PID channel to the programmed value.
  • Page 81 31 . If the PID channel passed calibration and if no sensors are in a sensor life warning condition or if SEN LIFE ALERT is set to OFF, the following screen sequence occurs. AUTO 4:07 CAL MODE AIR CAL AUTO CAL PASS SINGLE CAL NORMAL MODE GX-6000 Operator’s Manual Chapter 5: Calibration Mode • 81...
  • Page 82 Press and release POWER/ENTER to acknowledge the sensor life warning and continue to the Gas Select Screen. SEN LIFE WARNING The PID Gas Select Screen displays. AUTO GAS SELECT 82 • Chapter 5: Calibration Mode GX-6000 Operator’s Manual...

  • Page 83: Returning To Measuring Mode

    While in the Calibration Mode Screen, move the cursor to the AIR CAL menu item by using the SHIFT (PANIC) button. CAL MODE AIR CAL AUTO CAL SINGLE CAL NORMAL MODE GX-6000 Operator’s Manual Chapter 5: Calibration Mode • 83...
  • Page 84 If you do not want to continue, press and release the DISP/LOCK button and the unit will return to the Calibration Mode Screen. The GX-6000 will indicate that it is adjusting the zero reading for a few seconds and then it will prompt you to release the AIR button.

  • Page 85: Performing A Span Adjustment In Single Calibration

    SINGLE CAL NORMAL MODE ZERO ADJUSTED If the VOC zero filter was used, remove the filter from the GX-6000’s inlet fitting or probe. Reinstall the plugs on each end of the filter. Performing a Span Adjustment in Single Calibration Install the demand flow regulator onto the calibration cylinder.
  • Page 86 SINGLE GAS SELECT Isobutylene Acetone ESCAPE Use the AIR and SHIFT (PANIC) buttons to move the cursor next to the gas you want to use for calibration. Continue to Step 10. 86 • Chapter 5: Calibration Mode GX-6000 Operator’s Manual...
  • Page 87 11 . Connect the tubing from the demand flow regulator to the rigid tube on the probe. Allow the GX-6000 to draw gas for one minute. 12 . If necessary, adjust the reading to match the cylinder concentration with the and SHIFT (PANIC) buttons.
  • Page 88 SINGLE CAL PASS ESCAPE 15 . Disconnect the tubing from the GX-6000’s probe. 16 . Repeat Step 6 through Step 15 for any other channels you want to calibrate. Make sure you use an appropriate calibration cylinder for each sensor.

  • Page 89: Performing A Bump Test

    Install the demand flow regulator onto the calibration cylinder. Connect the sample tubing to the demand flow regulator. Install the sample hose and probe on the GX-6000 inlet fitting. Make sure the probe’s two halves are tightened firmly together to avoid leaks that can affect the calibration.
  • Page 90 If they are not, adjust the bump test gas value(s) be entering the AUTO CAL menu item in Calibration Mode, changing the value(s) there, and reentering the BUMP TEST menu item. 90 • Chapter 5: Calibration Mode GX-6000 Operator’s Manual...
  • Page 91 POWER/ENTER button to return to the Gas Select Screen. See “Troubleshooting” on page 102 to investigate the cause of the failure and replace the failed sensor(s) if necessary. d. Disconnect the tubing from the probe. GX-6000 Operator’s Manual Chapter 5: Calibration Mode • 91...
  • Page 92 The calibration time counted down during a calibration initiated because of a failed bump test is the difference between the gas time and the calibration time defined in the BUMP SETTING menu item in Maintenance Mode. 60CAL 19.0 %LEL 23.0 92 • Chapter 5: Calibration Mode GX-6000 Operator’s Manual...
  • Page 93 POWER/ENTER button to return to the Calibration Mode Menu. 16 . Use the SHIFT (PANIC) button to place the cursor next to the NORMAL MODE menu option, then press and release the POWER/ENTER button to return to Measuring Mode. GX-6000 Operator’s Manual Chapter 5: Calibration Mode • 93...

  • Page 94: Chapter 6: User Mode

    Chapter 6: User Mode Overview This section describes the GX-6000 in User Mode. See Table 12 below for a list of the items found in User Mode, the page that the menu item’s instructions can be found on, and a short description of the menu item.
  • Page 95 The main menu displays. It has 7 menu items. MAINTE USER DATE DATE FORMAT CONFIGURE CH LANGUAGE ROM/SUM PASSWORD START MEASURE Use the AIR or SHIFT (PANIC) button to move the cursor up and down the menu items. GX-6000 Operator’s Manual Chapter 6: User Mode • 95...

  • Page 96: Setting The Date And Time

    Press and release POWER/ENTER. The Date Format screen appears with the current setting flashing. AIR or SHIFT (PANIC) to display the desired setting. Press and release POWER/ENTER to save the setting and return to the main menu. 96 • Chapter 6: User Mode GX-6000 Operator’s Manual...

  • Page 97: Configuring The Channels

    Press and release POWER/ENTER. The available configuration options are shown. The current setting for the channel will be flashing. USER CHANNEL 1 CH4 (HC ) O2 (OX ) H2S (H2S ) CO (CO ) VOC (SM1) ESCAPE GX-6000 Operator’s Manual Chapter 6: User Mode • 97...
  • Page 98 NOTE: If you want to exit to the main menu without saving any channel configuration changes, press and release DISP/LOCK. Press and release POWER/ENTER to save the changes and return to the main menu. 98 • Chapter 6: User Mode GX-6000 Operator’s Manual...

  • Page 99: Updating The Language Setting

    Updating the Language Setting The LANGUAGE menu item allows you to select the language for the GX-6000’s user interface. The available choices are English (factory setting), Japanese, Italian, Spanish, German, French, Portuguese, Russian, and Korean. USER LANGUAGE ENGLISH JAPANESE ITALIAN...

  • Page 100: Turning The Password Function On Or Off

    Press and release the POWER/ENTER button again to return to the main menu. Turning the Password Function On or Off ON: The GX-6000 prompts you for a password when you enter User Mode and Calibration Mode. OFF (factory setting): No password is required to enter User Mode or Calibration Mode.

  • Page 101: Exiting User Mode

    Exiting User Mode From the main menu, place the cursor in front of START MEASURE at the bottom of the menu. Press and release POWER/ENTER. The unit will begin its start-up sequence. GX-6000 Operator’s Manual Chapter 6: User Mode • 101...

  • Page 102: Chapter 7: Maintenance

    Chapter 7: Maintenance Overview This chapter describes troubleshooting procedures for the GX-6000. It also includes procedures for replacing and recharging the batteries and replacing various consumable parts. WARNING: RKI Instruments, Inc. recommends that service, calibration, and repair of RKI Instruments be performed by personnel properly trained for this work.
  • Page 103 (auto 2. Make sure the GX-6000 has been calibration only). properly set up for calibration. 3. Change the charcoal filter. • The charcoal filter is 4.

  • Page 104: Replacing Or Recharging The Batteries

    WARNING: Do not remove the batteries while the GX-6000 is on. Turn the GX-6000 over so that the flow chamber and battery cover are facing up and the LCD is facing down. Push the battery cover latch toward the bottom of the instrument.
  • Page 105 Carefully install the new AA alkaline batteries according to the battery diagram inside the battery compartment. Figure 13: Installing the Alkaline Batteries Close the battery cover and secure the battery cover latch by pushing it up and toward the top of the instrument. GX-6000 Operator’s Manual Chapter 7: Maintenance • 105...

  • Page 106: Replacing The Lithium Ion Battery Pack

    Do not remove the battery pack while the GX-6000 is on. Remove the rubber boot, if installed. Turn the GX-6000 over so that the flow chamber and battery cover are facing up and the LCD is facing down. The battery pack release latch is located on the bottom of the instrument and is closer to the front of the case than the back.

  • Page 107: Recharging The Lithium Ion Battery Pack

    CAUTION: To be used only with lithium ion battery pack p/n 49-1619. Charge only with RKI charger model BC-6000, p/n 49-2182, or RKI charger model BC- 6000DC, p/n 49-2183. Use of other rechargeable batteries or chargers or charging of other rechargeable batteries in the GX-6000 will void the warranty.
  • Page 108 The construction of the charging stations allows them to be chained together but a separate adapter must be used for each charging station. One adapter will not operate more than one charging station. 108 • Chapter 7: Maintenance GX-6000 Operator’s Manual...

  • Page 109: Recharging The Lithium Ion Battery Pack Out Of The Instrument

    The lithium ion battery pack may be charged using the charging station while it is out of the GX-6000. This is useful if spare battery packs are kept in case the pack in the GX- 6000 needs to be charged, but the unit must be used immediately. In this case, a spare charged pack can be installed in the GX-6000 and the dead pack charged in the charging station.
  • Page 110 Make sure the GX-6000 is off. Confirm that the power adapter’s DC output cord is plugged into the charger. If using an AC powered charging station, plug the AC adapter into an electrical outlet. AC Power Supply Power Supply Jack (on...
  • Page 111 Remove the battery pack from the charging station and unplug the charging station’s power cord from the AC outlet. If necessary, reinstall the battery pack as described in Step 7 - Step 8 on pg.106. GX-6000 Operator’s Manual Chapter 7: Maintenance • 111...

  • Page 112: Replacing The Probe's Particle Filter And Hydrophobic Filter Disk

    Replacing the Probe’s Particle Filter and Hydrophobic Filter Disk Inspect the probe’s internal components if you notice that the GX-6000’s pump sounds bogged down or if an unexplained low flow alarm occurs. Replace the particle filter and hydrophobic filter disk if they appear dirty or saturated with liquid. Replace the gasket in the probe if it appears damaged.

  • Page 113: Replacing The H S Scrubber Disk And The Charcoal Filter

    Verify that the GX-6000 is off. Use a small Phillips screwdriver to unscrew the four screws holding the flow chamber to the rest of the GX-6000’s case. Grasp the sides of the flow chamber and lift it away from the rest of the case. The screws are captive screws and will not come out of the flow chamber.
  • Page 114 Failure to install the sensor gasket appropriately may result in inaccurate gas readings. Flow Fitting Connections Gasket Aligning Tabs Figure 24: Sensor Gasket Seating 114 • Chapter 7: Maintenance GX-6000 Operator’s Manual...

  • Page 115: Replacing A Sensor

    Turn the GX-6000 on. b. Plug the inlet with your finger. c. Verify that the GX-6000 goes into low flow alarm. If the GX-6000 does not go into low flow alarm, turn the instrument off and attempt to seat the sensor gasket again.
  • Page 116 If your instrument has a factory installed dummy sensor, ensure that it is still installed correctly. Make sure that the flat side is up and the hollow side is down. 116 • Chapter 7: Maintenance GX-6000 Operator’s Manual...
  • Page 117 12 . To verify that the sensor gasket was inserted properly: a. Plug the inlet with your finger. b. Verify that the GX-6000 goes into low flow alarm. If the GX-6000 does not go into low flow alarm, turn the instrument off and attempt to seat the sensor gasket again.

  • Page 118: Replacing The Hydrophobic Filter And Wire Mesh Disk

    Replacing the Hydrophobic Filter and Wire Mesh Disk Verify that the GX-6000 is off. Locate the clear plastic filter holder at the top of the GX-6000. Grasp the filter holder and turn it 1/4 turn counterclockwise. 4. Pull the filter holder away from the case.

  • Page 119: Pid Sensor Maintenance

    Verify that the GX-6000 is off. Use a small Phillips screwdriver to unscrew the four screws holding the flow chamber to the rest of the GX-6000’s case. Grasp the sides of the flow chamber and lift it away from the rest of the case. The screws are captive screws and will not come out of the flow chamber.
  • Page 120 12 . Hold the lamp in one hand being careful not to touch the lamp window with your fingers. 13 . With the other hand collect a small amount of aluminum oxide powder on a cotton swab. 120 • Chapter 7: Maintenance GX-6000 Operator’s Manual...
  • Page 121 18 . Hold the electrode stack between the thumb and forefinger of one hand and place the window end of the lamp inside the O-ring seal in the electrode stack with the other hand as shown below. Figure 31: Reinstalling the Electrode Lamp GX-6000 Operator’s Manual Chapter 7: Maintenance • 121...
  • Page 122 26 . Insert the flow chamber back into the instrument. 27 . Tighten the flow chamber’s four screws that were loosened in Step 2. 28 . Start up the GX-6000 by pressing and briefly holding the POWER/ENTER button. 122 • Chapter 7: Maintenance...

  • Page 123: Replacing The Pid Sensor's Lamp

    29 . To verify that the sensor gasket was inserted properly: a. Plug the inlet with your finger. b. Verify that the GX-6000 goes into low flow alarm. If the GX-6000 does not go into low flow alarm, turn the instrument off and attempt to seat the sensor gasket again.
  • Page 124 12 . Discard the old PID lamp. NOTE: At this point it is recommended that the finger cots be used on the fingers handling the lamp. Finger cots are included with the lamp cleaning kit. 124 • Chapter 7: Maintenance GX-6000 Operator’s Manual...
  • Page 125 If you feel that the connections did not engage, slightly rotate the sensor back and forth without putting pressure on it until you feel the connections engage. 19 . Push the sensor into the socket until it bottoms out. GX-6000 Operator’s Manual Chapter 7: Maintenance • 125...
  • Page 126 24 . To verify that the sensor gasket was inserted properly: a. Plug the inlet with your finger. b. Verify that the GX-6000 goes into low flow alarm. If the GX-6000 does not go into low flow alarm, turn the instrument off and attempt to seat the sensor gasket again.

  • Page 127: Replacing The Pid Sensor's Electrode Stack

    Replacing the PID Sensor’s Electrode Stack The electrode stack can last for the life of the PID sensor if the GX-6000 is used in a very clean, controlled environment. When used in a heavily contaminated or dirty environment, the electrode stack may only last a month. A contaminated electrode stack will cause a drop in sensitivity which can cause problems calibrating the PID channel.
  • Page 128 If you feel that the connections did not engage, slightly rotate the sensor back and forth without putting pressure on it until you feel the connections engage. 19 . Push the sensor into the socket until it bottoms out. 128 • Chapter 7: Maintenance GX-6000 Operator’s Manual...
  • Page 129 24 . To verify that the sensor gasket was inserted properly: a. Plug the inlet with your finger. b. Verify that the GX-6000 goes into low flow alarm. If the GX-6000 does not go into low flow alarm, turn the instrument off and attempt to seat the sensor gasket again.

  • Page 130: Chapter 8: General Parts List

    Chapter 8: General Parts List Table 16 lists part numbers for the GX-6000’s replacement parts and accessories. Table 16: General Parts List Part Number Description 06-1248RK-03 Calibration kit tubing, 3 foot length 10-1093RK Screw, for flow chamber 13-0112RK Wrist strap...
  • Page 131 Sample hose with integral probe, with hydrophobic filter and particle filter, no scrubber section. Replace “XX” with length in feet. 3 foot hose is standard. Available lengths for the GX-6000 are 3, 5, 10, 15, 20, 25, 30, 35, 40, 45, and 50 feet.
  • Page 132 Anhydrous methanol PID lamp cleaning kit, with electrode stack removal tool, for 11.7 eV PID sensors’ lamps ONLY ES-1821 Carbon monoxide (CO) sensor ES-1827i Hydrogen sulfide (H S) sensor NC-6264A LEL combustible sensor, catalytic OS-BM2 Oxygen sensor 132 • Chapter 8: General Parts List GX-6000 Operator’s Manual...
  • Page 133 Table 16: General Parts List (cont.) Part Number Description PID-001L PID sensor, 0 - 50,000 ppb VOC, improved type PID-002L PID sensor, 0 - 6,000 ppm VOC, improved type GX-6000 Operator’s Manual Chapter 8: General Parts List • 133...

  • Page 134: Appendix A: Maintenance Mode

    Appendix A: Maintenance Mode Overview This appendix describes the GX-6000 in Maintenance Mode. The GX-6000 is factory-set to suit most applications. Update settings in Maintenance Mode only if required for your specific application. Maintenance Mode items and their factory settings are listed in Table 17 below.
  • Page 135 • OFF ESCAPE return to main menu PUMP OFF DISP (pg.152) • ON • OFF ID DISPLAY (pg.152) • ON • OFF BACK LIGHT TIME (pg.152) OFF - 255 SEC 30 SEC GX-6000 Operator’s Manual Appendix A: Maintenance Mode • 135...
  • Page 136 • OFF • LEAK CHECK MODE BAR HOLE MODE • BAR HOLE MODE • LEAK CHECK MODE BAR HOLE TIME (pg.156) • 30 SEC 30 SEC • 45 SEC • 60 SEC 136 • Appendix A: Maintenance Mode GX-6000 Operator’s Manual...
  • Page 137 PASSWORD (pg.162) • ON (0006) • OFF RESTORE DEFAULT (pg.163) restore default settings START MEASURE (pg.164) enter Measuring Mode PID channel’s zero suppression is always 0% regardless of what value is shown. GX-6000 Operator’s Manual Appendix A: Maintenance Mode • 137...

  • Page 138: Entering Maintenance Mode

    WARNING: The GX-6000 is not in operation as a gas detector while in Maintenance Mode. Take the GX-6000 to a non-hazardous location and turn it off if it is on. Press and hold the AIR and SHIFT (PANIC) buttons, then press and hold the POWER/ENTER button.
  • Page 139 ENTER button to enter Maintenance Mode. There is no need to enter a password. The password screen appears even if PASSWORD is set to OFF so that a special factory mode can be accessed, if necessary. GX-6000 Operator’s Manual Appendix A: Maintenance Mode • 139...
  • Page 140 Press the DISP/LOCK button while in a screen where you are entering or updating parameters to exit the screen without saving any changes. You can also use the DISP/ LOCK button to back out of submenus and return to the main menu. 140 • Appendix A: Maintenance Mode GX-6000 Operator’s Manual...

  • Page 141: Using Maintenance Mode

    Press and release POWER/ENTER. The Date Format screen appears with the current setting displayed. AIR or SHIFT (PANIC) to display the desired setting. Press and release POWER/ENTER to save the setting and return to the main menu. GX-6000 Operator’s Manual Appendix A: Maintenance Mode • 141...

  • Page 142: Performing A Calibration (Gas Calibration)

    See “Calibrating Using the Auto Calibration Method” on page 70 for instructions to perform an automatic calibration. NOTE: Even if START CAL PASS is set to ON (factory setting), the GX-6000 will not automatically start its warmup sequence. That setting only applies to Calibration Mode operation.

  • Page 143: Updating Calibration Settings (Cal Setting)

    Press and release POWER/ENTER. The CAL SETTING menu appears. Updating the Calibration Reminder Setting (CAL REMINDER) ON (factory setting): The GX-6000 will give an indication at start up if it is due for calibration. The type of indication will depend on the CAL EXPRD setting (see pg.143).
  • Page 144 POWER/ENTER to perform a calibration. CANNOT USE: If the unit is due for calibration, the GX-6000 will give an indication at start up that calibration is past due and will prompt you to press and release POWER/ ENTER to enter Calibration Mode and perform a calibration.

  • Page 145: Updating Bump Test Settings (Bump Setting)

    ON: The BUMP TEST menu item will appear in Calibration Mode. RKI Instruments, Inc. recommends setting BUMP DISP to ON if BUMP REMINDER is also set to ON. NOTE: BUMP DISP must be set to ON to have the GX-6000’s bump test date reset after a successful bump test in an SDM-6000.
  • Page 146 For example, if the CAL TIME is set to 90 seconds and the GAS TIME is set to 30 seconds, if the bump test fails, the GX-6000 will only be exposed to gas for an additional 60 seconds. The available values are 90 seconds (factory setting), and 120 seconds.
  • Page 147 SETTING screen. Updating the Bump Reminder Setting (BUMP REMINDER) ON: The GX-6000 will give an indication at start up if it is due for bump testing. The type of indication will depend on the BUMP EXPRD setting (see pg.148). NOTE: If BUMP REMINDER is set to ON, it is recommended that BUMP DISP also be set to ON so that BUMP TEST appears in Calibration Mode.
  • Page 148 POWER/ENTER to enter Calibration Mode. CANNOT USE: If the unit is due for bump testing, the GX-6000 will give an indication at start up that a bump test is past due and will prompt you to press and release POWER/ ENTER to enter Calibration Mode and perform a bump test.

  • Page 149: Updating Alarm Parameters (Alarm Setting)

    Updating the Auto Start After Successful Bump Setting (START BUMP PASS) ON: If only the standard 4 sensors are installed, the GX-6000 automatically starts its warmup sequence after a successful bump test in Calibration Mode. If any smart sensors (PID, ESS-03, etc) are installed, this parameters has no effect on operation.
  • Page 150 Updating the Alarm Point Settings (ALARM POINTS) This menu item allows you to update one or more alarm points (the reading at which the GX-6000 recognizes the alarm condition). See Table 1 on page 12 for alarm point factory settings.
  • Page 151 ON (factory setting): Pressing and releasing the RESET button silences the buzzer when the GX-6000 is in alarm. The LEDs continue to flash, the vibrator continues to pulse, and the display continues to show the alarm. If you enter Display Mode during an alarm condition, the buzzer will be silenced but the LEDs will continue to flash and the vibrator will continue to pulse.

  • Page 152: Turning The Pump On/Off Display On Or Off (Pump Off Disp)

    Press and release POWER/ENTER. The Back Light Time Screen appears. AIR and SHIFT (PANIC) to adjust the time to the desired setting. Press and release POWER/ENTER to save the setting and return to the main menu. 152 • Appendix A: Maintenance Mode GX-6000 Operator’s Manual...

  • Page 153: Updating The Language Setting (Language)

    Press and release POWER/ENTER to save the setting and return to the main menu. Updating the Auto Zero Setting (AUTO ZERO) This setting allows you to configure the GX-6000 so that a fresh air adjustment takes place automatically as part of the instrument startup sequence. If AUTO ZERO is set to ON, the GX-6000 performs a fresh air adjustment at the end of the startup sequence before entering Measuring Mode.

  • Page 154: Updating The Demand Zero Setting (Demand Zero)

    Press and release POWER/ENTER. The IR Auto Range Screen appears. AIR or SHIFT (PANIC) to move the cursor in front of the desired setting. Press and release POWER/ENTER to save the setting and return to the main menu. 154 • Appendix A: Maintenance Mode GX-6000 Operator’s Manual...

  • Page 155: Updating The Confirmation Alert Setting (Confirmation)

    Updating the Confirmation Alert Setting (CONFIRMATION) ON: The GX-6000 periodically double beeps and double flashes the LED arrays to verify that it is operating. The interval between the confirmation alert can be defined once you set CONFIRMATION to ON. The interval can be 1 - 60 minutes. The factory setting is 5 minutes.

  • Page 156: Updating The Leak Check/Bar Hole Mode Setting (L./B. Mode)

    Press and release POWER/ENTER. The Bar Hole Measuring Time Screen appears. AIR or SHIFT (PANIC) to display the desired setting. Press and release POWER/ENTER to save the setting and return to the main menu. 156 • Appendix A: Maintenance Mode GX-6000 Operator’s Manual...

  • Page 157: Updating The Co Display Setting (Co Display)

    If any snap logs are taken while CO DISPLAY is set to ON, the CO reading is saved but will not be displayed during the snap log and cannot be seen by viewing snap log data at the instrument. However, the CO reading(s) can be viewed using the GX-6000 Datalogging Program.
  • Page 158 Press and release POWER/ENTER. The Alarm Time Screen appears. AIR or SHIFT (PANIC) to display the desired setting. Press and release POWER/ENTER to save the setting and return to the MAN DOWN MENU screen. 158 • Appendix A: Maintenance Mode GX-6000 Operator’s Manual...

  • Page 159: Updating The Datalogging Parameters (Log Setting)

    Press and release POWER/ENTER. The LOG SETTING menu appears. Updating the Data Log Interval Setting (LOG INTERVAL) This setting indicates how often the GX-6000 saves readings to the data logger. The following interval times can be selected: 10 minutes, 5 minutes (factory setting), 3 minutes, 2 minutes, 1 minute, 30 seconds, 20 seconds, or 10 seconds.

  • Page 160: Turning Sensor Life Warning On Or Off (Sen Life Alert)

    ON (factory setting): The GX-6000 writes over the oldest data with new data when the data logger memory is full. OFF: The GX-6000 stops saving data to the data logger when the data logger memory is full. From the LOG SETTING screen, place the cursor next to LOG OVER WRITE.

  • Page 161: Adjusting The Low Flow Setpoint (Flow Adjust)

    Connect a flow meter with a valve to the inlet of the instrument and adjust it to 0.2 LPM ± 0.1 LPM. This will be the low flow setpoint. You do not need to adjust anything at the instrument. GX-6000 Operator’s Manual Appendix A: Maintenance Mode • 161...

  • Page 162: Viewing The Rom/Sum Of The Instrument (Rom/Sum)

    Press and release the POWER/ENTER button again to return to the main menu. Turning the Password Function On or Off (PASSWORD) ON (factory setting): The GX-6000 prompts you for a password when you enter Maintenance Mode. The factory set password is 0006.

  • Page 163: Restoring The Default Settings (Restore Default)

    Maintenance Mode, the default settings are the same as the standard factory settings. If you want to return the GX-6000 to its default configuration, it is possible to do so by using the Default Settings menu item in Maintenance Mode. Returning the GX-6000 to its...

  • Page 164: Exiting Maintenance Mode (Start Measure)

    Exiting Maintenance Mode (START MEASURE) From the main menu, place the cursor in front of START MEASURE at the bottom of the menu. Press and release POWER/ENTER. The unit will begin its start-up sequence. 164 • Appendix A: Maintenance Mode GX-6000 Operator’s Manual...

  • Page 165: Appendix B: Maintenance Mode 2 • 165

    WARNING: The GX-6000 is not in operation as a gas detector while in Maintenance Mode 2. Take the GX-6000 to a non-hazardous location and turn it off if it is on. Press and hold the AIR and SHIFT (PANIC) buttons, then press and hold the POWER/ENTER button.
  • Page 166 (PANIC) buttons to select each password number and then pressing and releasing the POWER/ENTER button to enter it and move on to the next number until all of the numbers are entered. The password for Maintenance Mode 2 is 2014. 166 • Appendix B: Maintenance Mode 2 GX-6000 Operator’s Manual...

  • Page 167: Tips For Using Maintenance Mode 2

    Press the DISP/LOCK button while in a screen where you are entering or updating parameters to exit the screen without saving any changes. You can also use the DISP/ LOCK button to back out of submenus and return to the main menu. GX-6000 Operator’s Manual Appendix B: Maintenance Mode 2 • 167...

  • Page 168: Changing The Gas Combination (Gas Comb)

    HC: The catalytic LEL channel can be calibrated to a desired combustible gas. From the main menu, place the cursor next to HC SELECT. Press and release POWER/ENTER. The HC Select Screen appears. 168 • Appendix B: Maintenance Mode 2 GX-6000 Operator’s Manual...

  • Page 169: Changing The Streaming Setting (Streaming Mode)

    ON: The GX-6000 streams real-time data from the IrDA port. Contact RKI Instruments, Inc. to obtain document 71-0486 and to get more information about Streaming Mode. OFF (factory setting): The GX-6000 does not stream real-time data from the IrDA port. From the main menu, place the cursor next to STREAMING MODE.

  • Page 170: Appendix C: Using The Gx-6000 In Leak Check Mode

    DISPLAY is set to ON, your screens may appear different. If a GX-6000 is intended for tracking down leaks, it is shipped with Leak Check Mode or both Leak Check Mode and Bar Hole Mode enabled so that the operator must choose which operational mode to use when the unit is turned on (see pg.156).
  • Page 171 NOTE: If no button is pressed for 20 seconds, the unit will proceed into whichever mode is displayed. See “Turning On the GX-6000” on page 25 for a description of the remainder of the warm-up sequence keeping the following in mind: a.

  • Page 172: Performing A Demand Zero, Leak Check Mode

    AIR and DISP/LOCK buttons for 5 seconds. Performing a Demand Zero, Leak Check Mode Before using the GX-6000, it is recommended to set the fresh air reading for the target gas by performing a demand zero. This will set the CH channel to zero.

  • Page 173: Setting The Display Range Value

    Setting the Display Range Value The GX-6000’s Leak Check Mode has 4 display range ppm values to choose from: 500 ppm, 1000 ppm, 2000 ppm, and 5000 ppm. NOTE: The GX-6000 is always detecting combustible gas up to 5000 ppm. The display range value is only adjusting what part of the detection range is displayed on the LCD.

  • Page 174: Overscale Conditions

    To enter Peak Hold Mode: Turn the GX-6000 on as described in “Turning On the GX-6000, Leak Check Mode” on page 170. Select the desired display range. In the example below, 5000 ppm has been selected.

  • Page 175: Snap Log Mode, Leak Check Mode Operation

    ID that was selected when the data was taken. To enter Snap Log Mode and record snap log data: Turn the GX-6000 on as described in “Turning On the GX-6000, Leak Check Mode” on page 170. Select the desired display range. In the example below, 5000 ppm has been selected.
  • Page 176 If the gas concentration exceeds 5000 ppm in the Peak Reading Screen, the instrument will go into an overscale alarm. The full scale display range value will be displayed and OVER will be recorded when you press POWER/ ENTER. 176 • Appendix C: Using the GX-6000 in Leak Check ModeGX-6000 Operator’s Man-...

  • Page 177: Viewing Snap Log Data In Leak Check Mode

    Snap log data can be viewed while in Leak Check Mode. If snap log data was taken while in Measuring Mode, that data will also appear. Turn the GX-6000 on as described in “Turning On the GX-6000, Leak Check Mode” on page 170.
  • Page 178 NUMBER F . S . TANK 5 SHIFT SHIFT REC DATA REC DATA DATE 20.9 5/20/2015 %LEL MM/DD/YYYY Normal POWER/ 3:40 Mode ENTER Data NUMBER TANK 5 178 • Appendix C: Using the GX-6000 in Leak Check ModeGX-6000 Operator’s Man-...

  • Page 179: Turning Off The Gx-6000, Leak Check Mode

    TURN OFF will appear on the display and the buzzer will pulse for about five seconds. Release the button when TURN OFF disappears from the display. GX-6000 Operator’s Manual Appendix C: Using the GX-6000 in Leak Check Mode • 179...

  • Page 180: Appendix D: Using The Gx-6000 In Bar Hole Mode

    If a GX-6000 is intended for bar hole testing, it is shipped with Bar Hole Mode enabled so that the operator must choose which operational mode to use when the unit is turned on.

  • Page 181: Start Up, Bar Hole Mode

    Start Up, Bar Hole Mode This section explains how to start up the GX-6000 in Bar Hole Mode and get it ready for operation. Turning On the GX-6000, Bar Hole Mode WARNING: Gas alarms are not active when the GX-6000 is in Bar Hole Mode.
  • Page 182 NOTE: If no button is pressed for 20 seconds, the unit will proceed into whichever mode is displayed. See “Turning On the GX-6000” on page 25 for a description of the remainder of the warm-up sequence keeping the following in mind: a.

  • Page 183: Performing A Fresh Air Adjustment, Bar Hole Mode

    The GX-6000 is now operating in Bar Hole Mode. The pump is off and the following screen appears. 4:07 %LEL 20.9 VALVE 3 The combustible gas and oxygen channels are displayed along with the battery charge level and station ID.

  • Page 184: Performing A Bar Hole Test

    Performing a Bar Hole Test Start up the GX-6000 as described in “Start Up, Bar Hole Mode” on page 181. If you wish to change the station ID, press the SHIFT (PANIC) and DISP/LOCK buttons and release when you hear a beep. The current station ID will be displayed and it will be flashing.
  • Page 185 PEAK If a high concentration of combustible gas is encountered, a fresh air purge can be performed to purge the hose, probe and GX-6000 of gas before the next bar hole test. To perform a purge, do the following: •...

  • Page 186: Turning Off The Gx-6000, Bar Hole Mode

    The buzzer will pulse for about three seconds and TURN OFF will appear at the bottom of the screen. Release the button when TURN OFF disappears. 186 • Appendix D: Using the GX-6000 in Bar Hole Mode GX-6000 Operator’s Manual...

  • Page 187: Appendix E: Using The Gx-6000 In Inert Mode

    Alarm Points Menu. ALARM - P ALARM POINTS INERT ESCAPE Select INERT (not O2) in order to view or change Inert Mode’s oxygen alarm points. GX-6000 Operator’s Manual Appendix E: Using the GX-6000 in Inert Mode • 187...

  • Page 188: Start Up And Operation

    Once the warm-up sequence has finished, the instrument will be operating in Inert Mode. Since the oxygen concentration in fresh air is above both Inert Mode oxygen alarm points, the GX-6000 will go into alarm if turned on in a fresh air environment. 4:07...

  • Page 189: Appendix F: Ess-03 Toxic Sensors

    3 months. In addition, you can change an existing ESS-03 channel from one type of ESS-03 sensor to another and the GX-6000 will automatically load all the sensor parameters and configure the ESS-03 channel for the new sensor. See pg.198 for instructions to replace or change an ESS-03 sensor.

  • Page 190: Interference

    Interference Although the GX-6000 can support up to two ESS-03 sensors, many combinations are impractical for various reasons including sensor cross sensitivity to other gases. The table below indicators some of the gases that will cause an increased gas reading for the affected sensor.

  • Page 191: Start Up And Normal Operation

    • If your GX-6000 has more than one ESS-03 sensor installed, it is possible that both sensors will respond to some of the same gases at varying levels. Make sure you understand any issues like this that may exist in your particular instrument.
  • Page 192 NOTE: RKI Instruments, Inc. recommends that you dedicate a regulator for use with chlorine (Cl ) gas and that you do not use that dedicated regulator for any other gases, particularly hydrogen sulfide (H To calibrate the standard 4 sensors and/or the high range PID sensor, follow the instructions outlined on pg.70.
  • Page 193 Leave the tubing connected to the rigid tube on the probe. Continue with Step 6. Use the AIR and SHIFT (PANIC) buttons to move the cursor next to GAS SELECT. AUTO AUTO CAL CONCENTRATION GAS SELECT ESCAPE GX-6000 Operator’s Manual Appendix F: ESS-03 Toxic Sensors • 193...
  • Page 194 10.0 ESCAPE With the ESS-03 channel’s Gas Select Screen displayed, press and release the POWER/ENTER button. If you are calibrating anything other than an HCN sensor, continue to Step 12. 194 • Appendix F: ESS-03 Toxic Sensors GX-6000 Operator’s Manual...
  • Page 195 If you are using an ESS-03 only calibration cylinder: a. Connect the tubing from the regulator to the rigid tube on the probe. Allow the GX-6000 to draw gas for one minute. b. Press and release the POWER/ENTER button to set the span adjustment for the ESS-03 channel to the programmed value.
  • Page 196 16 . If the ESS-03 channel passed calibration and if no sensors are in a sensor life warning condition or if SEN LIFE ALERT is set to OFF, the following screen sequence occurs. AUTO 4:07 AUTO GAS SELECT PASS ESCAPE 196 • Appendix F: ESS-03 Toxic Sensors GX-6000 Operator’s Manual...
  • Page 197 Press and release POWER/ENTER to acknowledge the sensor life warning and continue to the Gas Select Screen. SEN LIFE WARNING 18 . The ESS-03’s Gas Select Screen displays. AUTO GAS SELECT 10.0 GX-6000 Operator’s Manual Appendix F: ESS-03 Toxic Sensors • 197...

  • Page 198: Calibrating The Ess-03 Sensor Using Single Calibration

    When replacing a sensor, you may either replace it with another of the same sensor or you may install a different ESS-03 sensor. If a different one is installed, the GX-6000 will load the sensor parameters and configure the ESS-03 channel for the new sensor.
  • Page 199 See the figure below for the location of the smart sensor 1 and 2 positions. Smart Sensor 1 Position Smart Sensor 2 Position H 2 S Figure 40: Smart Sensor Positions GX-6000 Operator’s Manual Appendix F: ESS-03 Toxic Sensors • 199...
  • Page 200 Verify that the GX-6000 is off. Use a small Phillips screwdriver to unscrew the four screws holding the flow chamber to the rest of the GX-6000’s case. Grasp the sides of the flow chamber and lift it away from the rest of the case. The screws are captive screws and will not come out of the flow chamber.
  • Page 201 17 . To verify that the sensor gasket was inserted properly: a. Plug the inlet with your finger. b. Verify that the GX-6000 goes into low flow alarm. If the GX-6000 does not go into low flow alarm, turn the instrument off and attempt to seat the sensor gasket again.

  • Page 202: Parts List

    , HCN, NO , and SO sensors. Replace “XX” with length in feet. 3 foot hose is standard. Available lengths for the GX-6000 are 3, 5, 10, 15, 20, 25, 30, 35, 40, 45, and 50 feet. 80-0006-XXP-01 Sample hose with integral probe, no particle filter, no scrubber section. For use with Cl sensor.
  • Page 203 Part Number Description ESS-03DH-SO2 Sulfur dioxide sensor, 0 - 99.90 ppm ESS-B332-NH3 Ammonia sensor, 0 - 400 ppm ESS-B335-CL2 Chlorine sensor, 0 - 10.0 ppm GX-6000 Operator’s Manual Appendix F: ESS-03 Toxic Sensors • 203...

  • Page 204: Appendix G: Ir Sensors

    The infrared sensors are used to monitor levels of methane, combustible gas, and carbon dioxide. This appendix describes the GX-6000’s infrared sensors and includes instructions to use a GX-6000 that has one or more infrared sensors installed. It also includes instructions to replace an infrared sensor. The table below lists the available infrared sensors along with their specifications.

  • Page 205: Description

    6 months. In addition, you can change an existing IR channel from one type of IR sensor to another and the GX-6000 will automatically load all the sensor parameters and configure the IR channel for the new sensor. See “Replacing an IR Sensor”...

  • Page 206: Co2 Scrubber

    The filter does not have a preferred flow direction. Filter Tubing Stub Tubing Stub Plug Plug To GX-6000 Figure 44: VOC Zero Filter 206 • Appendix G: Infrared Sensors GX-6000 Operator’s Manual...

  • Page 207: Ir Hc Start Up And Normal Operation

    IR CH Start Up and Normal Operation For instructions to startup and use a GX-6000 that includes an infrared methane sensor, reference “Start Up” on page 25, “Measuring Mode, Normal Operation” on page 33, and “Measuring Mode, Alarms” on page 39.

  • Page 208: Ir Co2 Start Up And Normal Operation

    Remove the tubing from the side of the scrubber that does not have an arrow pointing to it. Connect the tubing to the GX-6000’s inlet fitting. Be sure the arrow on the filter is pointing toward the inlet fitting. CO2 Scrubber...
  • Page 209 Remove both plugs from the tubing stubs on the VOC zero filter. Connect the VOC zero filter to the GX-6000’s inlet fitting. The filter does not have a preferred flow direction.

  • Page 210: Ir Calibration

    When replacing a sensor, you may either replace it with another of the same sensor or you may install a different IR sensor. If a different one is installed, the GX-6000 will load the sensor parameters and configure the IR channel for the new sensor.

  • Page 211: Parts List

    Calibration cylinder, 50 %LEL isobutane in air, 103 liter steel 81-0019RK Calibration cylinder, 10 %vol isobutane in nitrogen, 17 liter steel 81-0071RK-01 Calibration cylinder, 5,000 ppm CO in nitrogen, 34 liter GX-6000 Operator’s Manual Appendix G: Infrared Sensors • 211...
  • Page 212 Infrared HC sensor, 0 - 100 %LEL/2.0 - 30.0 %vol autoranging DES-3311-3 Infrared CH sensor, 0 - 100 %LEL/5.0 - 100 %vol autoranging DES-3311-4 Infrared CO sensor, 0 - 10,000 ppm 212 • Appendix G: Infrared Sensors GX-6000 Operator’s Manual...

  • Page 213: Appendix H: 10.0 Ev/Benzene Pid Sensor

    It is installed in a white housing that has three sockets on the bottom that mate with the GX-6000 instrument. The PID sensor must always be installed in the first smart sensor position which is located in the top left corner of the sensor block.

  • Page 214: Tube And Tube Holder

    The tube holder attaches to the GX-6000’s inlet fitting. It has a breakaway feature ensuring that the GX-6000 will not be damaged by hitting the tube holder on something when it is installed. The tube holder should only be used in Benzene Select Mode or when performing a calibration in TUBE CAL.

  • Page 215: Start Up

    Start Up The instructions for starting up a GX-6000 with a 10.0 eV/benzene PID sensor installed are the same as described in “Start Up” on page 25 with the exception of the screens shown in Step 8. Those screens appear as shown below.

  • Page 216: Measuring Mode

    48 but is factory set up for and calibrated to benzene and appears as shown below. If there are 2 PID sensors installed in your GX-6000, the PID Gas Name Screens will appear in Display Mode in the following order regardless of their position in the flow system: 10.0 eV/benzene, 10.6 eV, 11.7 eV.

  • Page 217: Benzene Select Mode

    WARNING: If you take the GX-6000 to an area that is 10 or 15 degrees different than the previous area, allow the instrument 45 minutes to acclimate before taking any readings. Failure to do so may cause the reading to be inaccurate.
  • Page 218 The number to the left of the countdown (“5” in the example below) is the temperature code. TUBE 0.00 MEASURING EXIT :RESET 45SEC 218 • Appendix H: 10.0 eV/Benzene PID Sensor GX-6000 Operator’s Manual...
  • Page 219 To repeat a measurement, continue to Step 11. • To not repeat a measurement and return to Measuring Mode, continue to Step 12. • To start a STEL measurement, continue to Step 13. GX-6000 Operator’s Manual Appendix H: 10.0 eV/Benzene PID Sensor • 219...
  • Page 220 11 . To start another measurement, press and release the POWER/ENTER button. WARNING: If you take the GX-6000 to an area that is 10 or 15 degrees different than the previous area, allow the instrument 45 minutes to acclimate before taking any readings. Failure to do so may cause the reading to be inaccurate.
  • Page 221 To cancel the STEL measurement, press and release the RESET button. Then press and release the POWER/ENTER button. TUBE BNZ STEL 0.00 0.00 CANCEL ? YES :ENTER NO :DISP GX-6000 Operator’s Manual Appendix H: 10.0 eV/Benzene PID Sensor • 221...
  • Page 222 TUBE REMOVE HOLDER YES :ENTER NO :DISP h. Remove the tube holder from the GX-6000’s inlet fitting. i. Press and release the POWER/ENTER button. 222 • Appendix H: 10.0 eV/Benzene PID Sensor GX-6000 Operator’s Manual...

  • Page 223: Viewing Benzene Select Mode Data

    The last line of the screen indicates the Station ID that was used for the snap log. Use the AIR and SHIFT (PANIC) buttons to scroll through different snap log IDs. GX-6000 Operator’s Manual Appendix H: 10.0 eV/Benzene PID Sensor • 223...
  • Page 224 3:45 Standard Data ENTER BENZENE SELECT NUMBER TANK 5 SHIFT SHIFT REC DATA REC DATA DATE 20.9 5/20/2015 %LEL MM/DD/YYYY Measuring POWER/ 3:40 Mode ENTER Data NUMBER TANK 5 224 • Appendix H: 10.0 eV/Benzene PID Sensor GX-6000 Operator’s Manual...

  • Page 225: Calibrating The 10.0 Ev/Benzene Pid Sensor

    * Even though it is possible to use the 10.0 eV/benzene PID sensor for general VOC detection, RKI Instruments, Inc. recommends using the low range or high range 10.6 eV sensor instead. ** In order to calibrate to a gas other than benzene or isobutylene, you must select that other gas for the 10.0 eV/benzene sensor in the PID Gas Name Screen in Display Mode as described in “PID Gas Name Screen”...

  • Page 226: Performing An Auto Cal

    Display Mode, both channels will appear as “VOC”. In that case, the channel that appears first will be based on the following sensor priority. Be sure to select the correct PID sensor for calibration. 226 • Appendix H: 10.0 eV/Benzene PID Sensor GX-6000 Operator’s Manual...

  • Page 227: Performing A Tube Cal

    TUBE CAL operation using one of the tubes from the new box. WARNING: If you take the GX-6000 to an area that is 10 or 15 degrees different than the previous area, allow the instrument 45 minutes to acclimate before taking any readings.
  • Page 228 Press and release the POWER/ENTER button to enter the TUBE CAL Menu. TUBE CAL GAS CALIBRATION AUTO CAL SINGLE CAL ESCAPE Use the SHIFT (PANIC) button to place the cursor next to AUTO CAL. 228 • Appendix H: 10.0 eV/Benzene PID Sensor GX-6000 Operator’s Manual...
  • Page 229 11 . Attach the other end of the calibration tubing to the tube holder’s inlet fitting. 12 . Use the SHIFT (PANIC) button to place the cursor next to START CAL. GX-6000 Operator’s Manual Appendix H: 10.0 eV/Benzene PID Sensor • 229...
  • Page 230 Auto Calibration Menu. See “Troubleshooting” on page 102. 16 . Use the SHIFT (PANIC) button to place the cursor next to ESCAPE, then press and release the POWER/ENTER button to return to the TUBE CAL Menu. 230 • Appendix H: 10.0 eV/Benzene PID Sensor GX-6000 Operator’s Manual...
  • Page 231 TUBE CAL REMOVE HOLDER YES :ENTER NO :DISP 18 . Remove the tube holder from the GX-6000’s inlet fitting. 19 . Press and release the POWER/ENTER button. You will return to the Calibration Mode Menu. 20 . Use the SHIFT...
  • Page 232 Attach the other end of the calibration tubing to the tube holder’s inlet fitting. Use the SHIFT (PANIC) button to place the cursor next to SINGLE CAL. 10 . Press and release the POWER/ENTER button. 232 • Appendix H: 10.0 eV/Benzene PID Sensor GX-6000 Operator’s Manual...
  • Page 233 TUBE CAL REMOVE HOLDER YES :ENTER NO :DISP 16 . Remove the tube holder from the GX-6000’s inlet fitting. 17 . Press and release the POWER/ENTER button. You will return to the Calibration Mode Menu. 18 . Use the SHIFT...

  • Page 234: Entering A Cal Code

    (PANIC) button to place the cursor next to CAL CODE. Press and release the POWER/ENTER button. The current calibration code will be displayed and it will be flashing. CAL CODE INPUT CAL CODE : C 234 • Appendix H: 10.0 eV/Benzene PID Sensor GX-6000 Operator’s Manual...

  • Page 235: Maintenance

    Even though discoloration can be a measure of when to replace the tube, not all gases cause the filter material to discolor which is why RKI Instruments, Inc. recommends that the tube be replaced before starting a new measurement in Benzene Select Mode.
  • Page 236 Line up the locking feature in the front half with its mate in the back half and insert the front half/tube assembly into the back half making sure the locking feature engages. Back Half Tube Front Half Locking Feature Figure 51: Reassembling Tube Holder 236 • Appendix H: 10.0 eV/Benzene PID Sensor GX-6000 Operator’s Manual...

  • Page 237: Parts List

    Calibration kit: 34 liter 5 ppm benzene in air cylinder, demand flow regulator, calibration tubing 82-0300RK Aluminum oxide powder PID lamp cleaning kit, with electrode stack removal tool, for 10.0 eV and 10.6 eV PID sensors’ lamps ONLY GX-6000 Operator’s Manual Appendix H: 10.0 eV/Benzene PID Sensor • 237...
  • Page 238 Part Number Description PID-003L PID sensor, 10.0 eV/benzene 238 • Appendix H: 10.0 eV/Benzene PID Sensor GX-6000 Operator’s Manual...

  • Page 239: Appendix I: 11.7 Ev Pid Sensor

    The PID-004 11.7 eV PID sensor’s lamp (RKI P/N 51-1504) is susceptible to humidity and its service life is not as long as lamps in other PID sensors sold by RKI Instruments, Inc. For this reason, the PID-004 11.7 eV sensor’s lamp is warranted for 2 months from the date of shipment.

  • Page 240: Description

    Description Instrument A GX-6000 that contains an 11.7 eV PID sensor is shipped with a black rubber cap plugging the inlet fitting. This rubber cap helps prolong the life of the 11.7 eV PID sensor by preventing ambient moisture from entering the flow system. This rubber cap should be installed back onto the inlet fitting before storing the GX-6000.

  • Page 241: Start Up

    Start Up The instructions for starting up a GX-6000 with a 11.7 eV PID sensor installed are the same as described in “Start Up” on page 25 with the following exceptions: • Remove the black cap from the inlet fitting before turning on the instrument.

  • Page 242: Measuring Mode

    Eliminating as much moisture from the flow system as possible before turning off the GX-6000 will help prolong the life of the 11.7 eV PID sensor’s lamp. Remove the tubing from one end of the dehumidifier filter. It does not matter which end you remove.

  • Page 243: Calibrating The 11.7 Ev Pid Sensor

    CONFIGURE CH menu item in User Mode, the order of displayed sensors may be different and you will need to remember how you set your instrument • When turning off the GX-6000 after performing a calibration, follow the instructions on pg.242. GX-6000 Operator’s Manual...

  • Page 244: Performing A Single Cal

    CONFIGURE CH menu item in User Mode, the order of displayed sensors may be different and you will need to remember how you set your instrument • When turning off the GX-6000 after performing a calibration, follow the instructions on pg.242. Maintenance Replacing the Dehumidifier Filter RKI Instruments, Inc.

  • Page 245: Cleaning The 11.7 Ev Pid Sensor's Lamp

    Using the anhydrous methanol more than 3 months after opening it or after the cap has been off for an extended period of time may damage the 11.7 eV lamp. GX-6000 Operator’s Manual Appendix I: 11.7 eV PID Sensor • 245...

  • Page 246: Parts List For 11.7 Ev Pid Instruments

    Parts List for 11.7 eV PID Instruments Table 31: Spare Parts List for 11.7 eV PID Instruments Part Number Description 07-0220 Rubber cap, black, for dehumidifier filter and GX-6000 inlet fitting 33-0564 PID sensor electrode stack, 11.7 eV sensor 33-2125-01 Dehumidifier filter with tubing 51-1504 PID sensor replacement lamp, 11.7 eV sensor...

  • Page 247: Appendix J: Creating A Pid User List

    Appendix J: Creating a PID User List Overview This appendix explains how to set up a User List for the GX-6000’s PID sensor(s). This User List appears in the PID Gas Name Screen in the GX-6000’s Display Mode. The PID User List is not related to the GX-6000’s User ID list.

  • Page 248: Editing The User List

    Select the gas in the Complete Gas List. b. Click Add. To remove a gas from the PID User List: a. Select the gas in the PID User List. b. Click Remove. 248 • Appendix J: Creating a PID User List GX-6000 Operator’s Manual...
  • Page 249 (10.6 eV, 10.0 eV, or 11.7 eV), each PID User List must be saved separately. Click Upload to save the PID User List to the GX-6000. If necessary, repeat Step 3 - Step 8 to edit the PID User Lists for the other PID sensor types (10.6 eV, 10.0 eV, or 11.7 eV).
  • Page 250 Warranty RKI Instruments, Inc. warrants the GX-6000 sold by us to be free from defects in materials, workmanship, and performance for a period of two years from the date of shipment from RKI Instruments, Inc. This includes the instrument and the original sensors.
