Howard LCN2750MV Installation Instructions

INSTALLATION INSTRUCTIONS
LCN2750MV

CAUTIONS

IMPORTANT SAFEGUARDS

When using electrical equipment, basic safety
precautions should always be followed including the
following:
READ AND FOLLOW ALL
SAFETY INSTRUCTIONS
1. DANGER- Risk of shock- Disconnect power before
installation.
2. This luminaire must be installed in accordance with the
NEC or your local electrical code. If you are not familiar
electrician.
3. Suitable for wet locations.
4. Covered ceiling mount only.
5. MIN. 75C SUPPLY CONDUCTORS.
6. Make certain power is OFF before starting installation or
attempting any maintenance.
7.
8.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
DO NOT TOUCH THE LEDs OR WIRES COMING
FROM CIRCUIT BOARD DURING THE INSTALLATION
PROCESS. DAMAGE MAY OCCUR.
Need help? Call 1.800.956.3456 to speak with our installation and product experts.
MOUNTING USING ¾" PLUG IN THE BACK
1.
and set the screws and lens aside.
2.
aside.
3. Remove ¾" plug from back for wiring access.
4.
it to the mounting surface using the appropriate mounting
hardware for the surface. Mounting hardware supplied by others.
When drilling holes do not drill within 1/4" (6mm) from edges of
should be used around all holes to ensure watertight enclosure.
NOTE: Fixture can also be pendant mounted by threading the
customer supplied pendant into the ¾" mounting hole on the top
5. Route the incoming power and ground leads through the hole
opening on the side of the LED mounting pad.
6. Complete the wiring to the incoming power and ground (refer to
"Fixture Wiring" section).
7.
are pinched when replacing parts. Do not overtighten lens screws
to prevent damage to lens.
MOUNTING USING ½" PLUGS ON THE SIDE
1.
and set the screws and lens aside.
2.
aside.
3.
tape should be used on conduit threads to prevent water entry.
NOTE: The (2) screws on either sides of the 1/2" plug should not
be removed during installation. See Figure 1.
4.
it to the mounting surface using the -appropriate mounting
hardware for the surface. Mounting hardware supplied by others.
When drilling holes do not drill within 1/4" (6 mm) from edges of
should be used around all holes to ensure watertight enclosure.
5. Complete the wiring to the incoming power and ground (refer to
"Fixture Wiring" section).
6.
are pinched when replacing parts. Do not overtighten lens screws
to prevent damage to lens.
FIGURE 1
Do NOT Remove These Screws During
