Cozeburn Shaker Grate Series Operation And Maintenance Instructions

Shaker Grate
OPERATION AND MAINTENANCE INSTRUCTIONS
1
1. Cozeburn Outdoor Furnace
2. Ash Door
3. External Grate Control
4. Shaker Handle
Figure 1
Shaker Handle
Cozeburn Furnace with
Shaker Grate Option
2
3
Shaker Grates in
Firebox
Shaker Grates in
Ash Compartment

OPERATION

1. To avoid buildup of ashes in the firebox,
4
agitate shaker grates daily to allow ash to fall
into the ash pan.
2. To operate the shaker grates, hook the
shaker handle onto the external grate control
and pump up and down (see Figure 1).
3. Leave grates flat during furnace operation to
prevent large pieces of fuel from falling into
the ash pan.
4. Check ash pan weekly and empty as
necessary to keep ash from building up
under the grates. Excessive ash will cause
warping.
5. Keep ash door closed except when emptying
the ash tray. Leaving the ash door open will
cause the unit to overheat and could result in
warping of the grates.
