- Page 1 Smart Toilet USER MANUAL CLEAN • COMFORT • HYGIENE...
-
Page 2: Safety Notes
2. The socket load should be 1300W and up. 3. The battery for the remote control will be 3 x 1.5V 4. If the power cord is damaged, it must be replaced by special cord from Jade Bath. 1. Don’t stand on the main body, cover, or seat. - Page 3 CAUTION Prohibited Must follow Do not spray water or cleaning Do not use damaged socket or Do not put many plugs on one agent on the product and power plug which may lead to electric patch board which may lead to plug which may lead to electric shock, short out or fire power overload...
- Page 4 OPERATION INSTRUCTIONS Stop / Flush Press this button to flush the toilet, seat sensor will engage automatic flush when you stand. Posterior wash / Moving wash When sit and press this button, the nozzle will clean itself for 2 seconds. Then it begins posterior washing. The whole cycle lasts for 2 minutes.
-
Page 5: Other Functions
OPERATION INSTRUCTIONS OTHER FUNCTIONS Flush automatically when you stand. When nobody is seated on toilet, press “Stop/Flush” button to flush; When there is no electricity, press the side button to flush. When seated on the toilet, press any wash button, nozzle will clean itself for 3 seconds,... -
Page 6: Required Tools
INSTALLATION INSTALLATION INSTALLATION Required Tools: Included: - Monkey Wrench - Phillips screwdriver - Glass glue tape measure - Pencil or marker pen - Glass glue gun Sealing flange Special hose Water input Remote with Manual angle valve 3 batteries Installation steps 1. - Page 7 TRIAL OPERATION AND MAINTENANCE Once finished with connection of water supply, open the angle valve and switch on the power. The magnetic valve will flush the toilet and the nozzle will come out. This is the self-inspection process. The water temperature indicator flashes which means the water tank is getting water and after 40 seconds the indicator will stop flashing, which means finish water input.
-
Page 8: Specification
SPECIFICATION Power voltage 220V-240V 50-60Hz 1650W Water Supply Water input Connect to the water pipe directly Water pressure 0.08 MPa - 0.75 MPa (0.8 kgt/cm² - 7.5 kgt/cm²) Wash device Rear wash water volume 0.5 L/min - 0.9 L/min Front wash water volume 0.5 L/min - 0.9 L/min Tank volume Temperature...
