kincrome K7783 Operation Manual

Operation Manual
Parts List
Keys x 2
Assembly Instructions
1
Removing the Drawers
• Fully extend the empty drawer.
• Push up the right grey release
lever while pushing down the
left grey release lever.
• Pull the drawer outward until
it is released from the drawer
slide.
TOOLS & ASSISTANCE NEEDED
4 x EVA Liners
1
Push up the
right grey release lever
ADD-ON CHEST
3 DRAWER
Top Section 662mm
Deep
Total Weight 14.1kg
MAINTENANCE
• Periodically tighten all hardware
• Lubricate the slides twice a year
• Lubricate the lock with graphite annually
• Use a damp Microfibre cloth to clean all surfaces
2
Re-Inserting The Drawers
• Extend the drawer slides.
• Insert the brackets on each side
of the drawer into the slots on the
slides, being careful that they are
properly positioned.
• Once properly inserted,
completely close the drawer
to set the slides in their proper
positions.
1
K7783
Bunnings Weight Icons (2676) 30/3/04
10 to 16kg
Maintain natural curves of back
- use proper lifting techniques
670mm 320mm 260mm
315mm 10mm
568mm 275mm 38mm
568mm 275mm 62mm
Pull down the
2
left grey release lever
2 People Lift
