Hi Slide 60 Soft Close

Specifications

Item

Hi Slide 60 Soft Close

Al. Profile Track for hi slide 50

(Set of top & bottom tracks in 2.44m &

3.66m for 2 doors)

Fitting Instructions

Hi Slide 60 Soft Close

• Specially Designed for Flush Mounted Sliding Shutter.

• Bottom Dome Track for Smooth Rolling.

• Soft Closing & Soft Opening to prevent it from Banging.

• Special Guide rollers to avoid Voice While Sliding.

• Load Capacity: 60KGS.

• System 32 Compatible.

Code

Finish

HS-60-SC

Black

HS502D-T2

Anodised Silver

HS502D-T3

Need help?

Do you have a question about the Hi Slide 60 Soft Close and is the answer not in the manual?

Page 1 Home » Hi Slide 60 Soft Close Hi Slide 60 Soft Close • Specially Designed for Flush Mounted Sliding Shutter. • Bottom Dome Track for Smooth Rolling. • Soft Closing & Soft Opening to prevent it from Banging. • Special Guide rollers to avoid Voice While Sliding.
Page 2 1. Cut a slot of 2mm wide & 6.5mm deep on bottom of Cabinet & Insert the Dome track into the slot as shown in Fig. 2; for dimensions refer Fig. 1. 2. Drill holes in shutter on both ends using reference Fig. 9 of top brackets for dimensions refer Fig. 1. 3.
