O P E R A T O R ' S

M A N U A L

Riata

Rake

Precision ARENA DRAG

RA1108

RA1110

5RR11XXM00A (6/15/12)

Table of Contents

Need help?

Do you have a question about the Rake RA1108 and is the answer not in the manual?

Questions and answers

Summary of Contents for Riata Rake RA1108

Page 1 O P E R A T O R ' S M A N U A L Riata Rake ® Precision ARENA DRAG RA1108 RA1110 5RR11XXM00A (6/15/12)
Page 2: Introduction
Use only genuine Riata Rake service parts. Substitute parts will void the warranty and may not meet standards required for safe and satisfactory operation. Record the model number and serial number of...
Page 3: Table Of Contents
WARRANTY FOR PARTS ..........28 Purpose The purpose of this manual is to assist you in operating and maintaining your Riata Rake. Read it carefully. It furnishes information and instructions that will help you achieve years of dependable performance.
Page 4: Specifications / General Information
GENERAL INFORMATION SPECIFICATIONS Product Comparison Manufacturer: Riata Ranch Company Riata Riata Models 1108 1110 iMatch Compatible Cat. 2 Quick Couple Compatible Uses Arena Conditioning and repair tool Arena Conditioning and repair tool Operating Speed 4-6 mph 4-6 mph Shipping Single Units...
Page 5: Safety Decals
SAFETY & INSTRUCTIONAL DECALS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH Replace Decals Immediately If Damaged! Check that all safety decals are installed and in good condition. Replace if decals are worn or damaged.
Page 6 SAFETY REFLECTOR DECALS ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED! FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH Replace Decals Immediately If Damaged! 8” RED REFLECTORS 5RR1000DC08A Check that all reflector decals are installed and in good condition. Replace if decals are worn or damaged.
Page 7 Do not estimate. • If you do not understand any part of this manu- TRANSPORTATION al and need assistance, contact Riata or dealer. • Always comply with all state and local laws • Operators must be instructed in and be capa-...
Page 8: Safety Rules
OPERATION never advisable to use powered equipment in areas with livestock. Never operate Riata Rake in • Never go underneath equipment (lowered to an arena while livestock is present. the ground or raised) unless it is properly blocked and secured. Never place any part of •...
Page 9 Safety Rules continued from the previous • Keep all persons away from operator control page area while performing adjustments, service, or maintenance. MAINTENANCE (cont’d) • Tighten all bolts, nuts, and screws to torque • When performing maintenance or repairs chart specifications. Check that all cotter pins make sure the equipment is in the lowered posi- are installed securely to ensure equipment is in tion.
Page 10 This pictorial purchaser assembly guide should be followed sequentially during setup. TIME REQUIRED: 30 Minutes Riata Rake has arrived bolted to a heavy duty pallet. Assemble on level ground with room to move around the implement. Read and follow all instruction.
Page 11 REMOVE PALLET SIDE/CROSS BRACING Removing the side bracing and cross brac- ing will provide access to assemble Riata Rake. DISCARD PALLET BRACING Removing the side bracing and cross brac- ing will provide access to assemble Riata Rake. EXTEND RATCHET JACK Ratchet Jack is attached to tine bar of unit.
Page 12 ATTACH CARRIAGE BOLTS, WASHERS & NUTS TIGHTEN BOLTS ON UPPER MAST Top of Spine—3/4” box wrench required TIGHTEN BOLTS ON LOWER MAST Tighten both carriage bolts and lock nuts TIGHTEN BOLTS ON LOWER DIAGONAL Tighten both carriage bolts and lock nuts REMOVE LAG BOLTS THAT CONNECT REAR COMB TO PALLET Remove lag bolts—left and right side on rear...
Page 13 LOCATE LAG BOLTS THAT CONNECT TINE BAR TO PALLET REMOVE LAG BOLTS THAT CONNECT TINE BAR TO PALLET Remove lag bolts—left and right side on tine bar. ATTACH RATCHET JACK TO THE MAST Attach the top end of the Ratchet Jack us- ing the supplied 1"...
Page 14 OPERATIONAL USE OF LEVELING COMB You can operate the Riata Rake using a float- ing method or fixed method of leveling. It is recommended that the first use of the imple- ment you use it in a floating position with the handle in the up position (as shown).
Page 15 Warning: DO NOT LAY UNDER THE RIATA RAKE. Then install all the tines one at a time attach- ing the provided brass washer and spring clip to the top of each tine.
Page 16 CONNECT RIATA RAKE TO YOUR TRACTOR’S 3 POINT HOOKUP Now you are ready to connect your Riata Rake to the tractor. Lower link pins are provided and are pinned in place on your unit. Top links can vary depending on your tractor model and size—we do not provide a top link pin.
Page 17: Dealer Instructions
____ Show customer the safe, proper proce- located in the back of the owners manual. dures to be used when mounting, dismount- Make a copy and email to riata at sales@ ing, and storing equipment. riataranch.com subject "New Warranty Registration".
Page 18: Operation
Owner/Operator (Owner’s/Operator’s after the first hour of operation. The break in Responsibility) Pre-Operation Checklist stage of your new Riata Rake can cause mini- mal loosening of hardware. Please see Bolt ____ Review and follow all safety rules and Torque Chart (page 25) for proper torque infor- safety decal instructions on page 2 through page mation.
Page 19 Rake through the upper, outer set of holes. 2. Slide upper sleeve over the heavy-duty top link 1. Attach the tractor’s lower link arms to the Riata pin supplied with top link. Reinstall retaining pin. Rake through the lower, inner set of holes.
Page 20 ADJUSTING TINE DEPTH Your Riata Rake is equipped with a tine bar array and a single adjustment point (see figure 4 below). One way of determining the depth that is best suited for your arena is to adjust the tine bar by extending the ratchet jack until the tines are in the footing of your arena.
Page 21 The leveling comb is designed to function as a flow control gauge and is adjustable with either the stan- dard top link that came with your Riata Rake or with our Hydraulic Cylinder option (not included). First you will find a fixed or floating control handle directly above the leveling comb.
Page 22 USING RIATA RAKE SCARIFIERS OPTION: The Riata Rake is optionally equipped with scarifiers . Our 1108 Riata Rake option comes with 9 scarifiers (5RR1108A022A). Our 1110 Storage Position Riata Rake option comes with 11 scarifiers (5RR1110A022A).These teeth are used for periodical maintenance.
Page 23 The blade is designed to be level with the footing surface when the Riata Rake mast is vertical. NOTE: be sure to re-level the mast before you condition with the tines after clearing Tighten Wing Bolt your rail.
Page 24 Leveling the frame: Use the top link to set the mast and frame angle. The mast of the Riata Rake should be set at 90 de- grees to the earth in a vertical position. This may vary slightly depending upon arena conditions and during the use of scarifiers.
Page 25 We have developed an excellent arena pattern for you to follow for the first few time you use your Riata or when ever you use the optional scarifiers for maintaining your arena. Note: Scarifiers should be used without the tines in the ground—this will reduce the work for your tractor and provide a superior maintenance.
Page 26: Owner Service
CAUTION Storage The information in this section is written for oper- When storing your Riata Rake make sure the ators who possess basic mechanical skills. If you unit is placed on level ground and clear of any need help, your dealer has trained service techni- obstructions.
Page 27 Parts Catalog Cat. 1 & 2 Hitch 1108 and 1110 *lower hitch bushings for I-Match compatibility sold separately. Additional 11 Series Accessories available for purchase: • Fence Blade Kit: Order # 5RR1108A023A • 1108 Ripper/Scarifier Kit (QTY 9): Order # 5RR1108A022A •...
Page 28: Parts Catalog
Parts Catalog Continued 1108 Component and Replacement Parts Item Part Number Name Qty Description 5RR1108W001A Main frame assembly Weldment 5RR1108W002A Tine bar assembly Weldment 5RR1108W003A Inside comb frame Weldment w/ 2 bolts & washers 5RRCRP0W004A Spine mast Weldment w/ 2 bolts & nuts 5RRCRP0W005A Spine diagonal Weldment w/ 4 bolts &...
Page 29: Bolt Size And Bolt Torque Chart
Bolt Size Chart SAE Torque Chart BOLT SIZE AND TORQUE CHART...
Page 30: Warranty
DELIVERY OF THE PRODUCT TO THE ORIGINAL PURCHASER. The applicable warranty period for commercial or rental use shall be SIX (6) MONTHS from the date of purchase. This Warranty will apply if notified to RIATA within thirty (30) days after such defect is discovered.
Page 31: Warranty For Parts
Under no circumstances will this Warranty apply in the event that the part(s), in the good faith opinion of RIATA, has (have) been subjected to improper operation, improper maintenance, misuse, or accident.
