Summary of Contents for tronical Newcomer

  • Page 2 Headstock RoboHead Tuner Neck Single Fret Body Sound Hole Pickguard Bridge String Pin...

  • Page 3: Quick Start

    QUICK START Starting up from scratch 1. Make sure NEWCOMER is turned off. 2. Bring the strings to tension by manually turning on the keys: Use the key to turn the RoboHead in order to bring every string to tension until the string cannot be pulled away from the body/neck more than 1.2 inch / 2.5 mm.

  • Page 4: Inserting The Battery

    INSERTING THE BATTERY The Battery is held by a push-push. Please insert the battery carefully with the tip-side. There is also a GREEN ARROW on the cover of the battery showing which way it should be inserted. Please pay attention to the raising on the battery cover matching the guidance of the base for insertion.
  • Page 5 USAGE AND TIPPS ● Push the ON-button to activate multi-string-tuning mode. ● Strum all strings and let them ring. The LED’s show the status of the strings by different colors: GREEN = string is in tune. YELLOW = pitch of the string is being measured. BLUE = RoboHead is moving.
  • Page 6 You can choose multi- or single-string mode. ● MULTI STRING MODE If you push the ON-button briefly, NEWCOMER will turn on in mutli-string mode. As all LEDs will be lighted you can just strum all strings evenly close to the neck and the NEWCOMER will start tuning the strings.

  • Page 7: Charging The Battery

    CHARGING THE BATTERY The “BAT” LED above the ON-button indicates the battery charge status. To ensure perfect performance the battery should be fully charged which is indicated by a green light. GREEN = Battery is fully charged = Battery needs to be charged A fully loaded battery should last for about 150 tunings.

  • Page 8: Changing Strings

    CHANGING STRINGS You should change the strings if you feel or hear a lack of quality. Also, when a string breaks it needs to be replaced. Guitar strings are likely to lose quality after some time because of oxidation and dirt from the fingers sweat. You should regularly change strings in order to maintain the best sound and feel.
  • Page 9 HOW TO CHANGE THE STRINGS: You might need a couple of tools. We suggest the following: ● Side cutting pliers to cut the strings. ● A neck cradle to secure the neck. STEPS: 1. Take off the old strings – Do it one by one to keep the order and the tension. You have to turn the RoboHeads manually in order to loosen the strings.
  • Page 10 ATTACHING THE STRINGS TO THE ROBOHEADS BASS STTINGS (E A D) Make sure the NEWCOMER system is OFF Take off the LockNut and make sure the recess is turned horizontal to the neck (90 degree angle). You can turn the key manually. Wind the string...
  • Page 11 Tighten the Lock Nut with a small coin easily by hand. NOTE: Do not use any tool to fix the Lock Nut and DO NOT OVER TIGHTEN! Use a 1 cent coin to tighten the Lock Nut, otherwise you may damage the RoboHead! Recommended max.
  • Page 12 ATTACHING THE STRINGS TO THE ROBOHEADS TREBLE STTINGS (G B e) Make sure the NEWCOMER system is OFF. Take off the LockNut and make sure the recess is turned horizontal to the neck (90 degree angle). You can turn the key manually. Wind the string...
  • Page 13 Tighten the Lock Nut with a small coin easily by hand. NOTE: Do not use any tool to fix the Lock Nut and DO NOT OVER TIGHTEN! Use a 1 cent coin to tighten the Lock Nut, otherwise you may damage the RoboHead! Recommended max.

  • Page 14: Factory Reset

    To restore factory settings please click the ON button briefly to switch on the device. ● Now hold the on button for about 15 seconds until the device turns on the LED’s start flashing YELLOW. NEWCOMER will turn off and the factory reset is restored. BE AWARE! ●...

  • Page 15: Safety Information

    Taking the system or single components apart will conclude into a breach of the warranty. ● Store NEWCOMER and the guitar in a dry and clean (non-dusty) place without humidity or heat. Take out the Battery if you do not use NEWCOMER for a longer period of time. SPECIFICATIONS: ●...
  • Page 16 Tronical Components GmbH Heselstücken 18 22453 Hamburg...
